You must follow steps 1to 5to complete the setup.

Quick Setup Guide

Read the Product Safety Guide first, then read this guide for the correct installation procedure.

Keep this guide next to your machine for quick reference.

In this guide, the illustrations of the DCP-T420W are used unless otherwise specified.

Remove the protective tape and the film covering the machine.

1Unpack the machine and check the components

DCP-T220 / DCP-T226

DCP-T420W / DCP-T425W

DCP-T426W / DCP-T428W

NOTE

• Save all packing materials and the box in case you must ship your

machine.

• We recommend using a USB 2.0 cable (Type A/B) that is no more than

2 meters long.

2Fill the ink tanks with inbox ink

IMPORTANT

Check the ink bottle model name on the

label. Using the incorrect ink may cause

damage to the machine.

Open the ink tank cover a, remove the cap

b, and place it on the back of the cover c.Remove the film and tighten the cap firmly.

Remove the nozzle cap and insert the bottle nozzle firmly into the ink tank so

that the ink does not spill.

The bottle is self-standing and the ink fills automatically until the bottle is empty.

To fill the ink tank faster, squeeze the bottle on both sides.

When finished, remove the bottle,

pointing the nozzle upward so the ink

does not spill.

Replace the ink tank cap. Repeat

step 2for the other ink tanks, and

then close the ink tank cover.

BTD60BK

BT5009CMY1

CHN-ENG

Version A

3Load plain A4 paper in the paper tray

Fan the paper well.

Operation Videos

www.95105369.com Installation

& Using

Videos

Inbox Ink Bottles*4

Setup Complete

4Start the initial cleaning

The machine prints the Print Quality

Check Sheet.

Check the Print Quality Check Sheet.

To improve the print quality, clean the

print head. See Improve Print Quality

in this guide.

Good Poor

Lit

Blinking

5Connect your computer or mobile device Connect your Brother machine and computer/mobile device to

the same network.

Install Brother software to use your machine. Visit one of the following websites:

For Computers:

For Windows only, CD installation is also

available.

For Mobile Devices:

(DCP-T420W/DCP-T425W/

DCP-T426W/DCP-T428W)

Install the Brother iPrint&Scan

application.

Follow the on-screen instructions.

For USB Connection:

Use the USB port inside the machine, as shown.

setup.brother.com

Initial cleaning begins

Blinking

Press and hold for

3 seconds

Your machine can print through an applet of WeChat, which is called "兄弟畅享印".

"兄弟畅享印" lets you wirelessly print photos and documents without the need to install an app or a driver.

Binding your printer before using WeChat print function for the first time.

Please scan the QR code on the right for operation instructions.

Connect with WeChat (DCP-T420W / DCP-T425W / DCP-T426W)

brother.com/apps

LED Indications

Copy

1 Power / Stop button 5 Color Start button

2Power LED 6Mono Start button

3Warning LED 7

• Copy Shortcut button

(DCP-T220/DCP-T226/DCP-T420W/

DCP-T425W/DCP-T426W)

• Upload button (DCP-T428W)

4 Ink LED 8

Wi-Fi button / LED

(DCP-T420W/DCP-T425W/DCP-T426W/

DCP-T428W)

• Standby • Busy (blinking)

• Sleep (blinking slowly and faintly)

• See Check Ink Volume in this guide. When finished, press Stop.• Paper jam (blinking simultaneously): See Remove Jammed Paper in

this guide.

• No paper loaded: Load paper in the tray, and then press Mono Start or Color Start.

• Tray not detected: Slowly push the paper tray completely into the machine. • Wrong paper size

• Out of memory • Machine error For solutions, see the Online User's Guide:

www.95105369.com

Wi-Fi

(DCP-T420W/DCP-T425W/

DCP-T426W/DCP-T428W)

• Off • Connecting • Connected

Normal Copy

1. Load the paper in the paper tray.

2. Place the document in the lower right

corner of the scanner glass.

3. Press Mono Start or Color Start.

n Multiple Copy

Press Mono Start or Color Start once for each additional copy.

n Best Quality Copy

Press and hold Mono Start or Color Start for two seconds.

n Other Copy

Use the Brother iPrint&Scan application on a computer or mobile device. See the Online User’s Guide.

Machine Settings

The machine's settings are set from the application (Brother iPrint&Scan or Brother Utilities) on your computer or mobile device.

Important Notice for Network Security: The default password to manage this machine’s settings is located on the back of the machine and marked “Pwd”. We

recommend immediately changing the default password to protect your machine from unauthorized access. See the Online User’s Guide.

Lit Blinking

For detailed machine operation including scanning and

troubleshooting tips, see the Online User’s Guide:

Reference Guide

Press to turn the machine on. Press and hold to turn the machine off.

Control Panel Overview

www.95105369.com

Using &

Troubleshooting

Place in the

lower right

LED Indications

Copy

Check Ink Volume

Improve Print Quality

Remove Jammed Paper

Clean the print head.

Press simultaneously Blinking Clean black only

Good Poor

After cleaning, the machine prints the Print

Quality Check Sheet.

If the print quality does not improve with normal cleaning, try the Special cleaning (Note that this operation will consume a large amount of ink).

1. Make sure all ink tanks are at least half-full.

2. Use the procedure above, but hold Mono Start and Color Start simultaneously for five seconds while the Ink LED is blinking.

You can set one specific copy function for the Copy

Shortcut button (see the Online User’s Guide). The

default is 2 in 1 ID Copy.

DO NOT fill the ink tank past the maximum fill mark.

When the ink level reaches the lower line, refill the ink tank as soon as possible.

Avoid getting ink on your

hands.

Blinks slowly after scanning is complete

2 in 1 ID Copy (DCP-T220 / DCP-T226 / DCP-T420W / DCP-T425W / DCP-T426W)

Clean all colors

(DCP-T428W: Upload)
