Bryant T2--WHS01 Manuale utente

Owner’s Manual

T2--WHS01

Legacy™Line Wi--FirThermostat

TABLE OF CONTENTS

PAGE

GETTING STARTED 1...........................................

LEGACY LINE Wi--Fi THERMOSTAT BASICS 3.....................

What’s on the Home Screen? 3.....................................

Using the Navigation Buttons 4....................................

Idle Screen 6...................................................

About Your Legacy Line Wi--Fi Thermostat 7.........................

CONNECTING TO THE INTERNET 8..............................

Setting up Wi--Fi and Obtaining a Registration Code 8...................

Configuring a Web Portal Account 10................................

Re--Registering the Legacy Line Wi--Fi Thermostat 12...................

USING YOUR LEGACY LINE Wi--Fi THERMOSTAT 13...............

System Mode 13................................................

Fan 14.......................................................

Weather Forecast 15.............................................

Resetting the Thermostat 16.......................................

Rebooting the Thermostat 17......................................

Cleaning the Thermostat 17.......................................

What To Do If You Move 17.......................................

TABLE OF CONTENTS (CONT.)

CONFIGURING YOUR LEGACY LINE THERMOSTAT 18............

Configuring Personal Preferences 19................................

Utility CPP Settings 22...........................................

Set Up Reminders and Alerts 23....................................

Configure Alerts 24..............................................

Wi--Fi 26......................................................

Creating Your Weekly Schedule 27..................................

Using the Weekly Schedule Editor 28................................

Scheduling a Vacation 30.........................................

UNDERSTANDING ALERTS 32....................................

List of Alerts 32................................................

WARRANTY 35..................................................

GETTING STARTED

Safety Considerations

Improper installation, adjustment, alteration, service, maintenance, or use

can cause explosion, fire, electrical shock, or other conditions which may

cause death, personal injury or property damage. Consult a qualified

installer, service agency or your distributor or branch for information or

assistance. The qualified installer or agency must use factory--authorized

kits or accessories when modifying this HVAC system. Refer to the

individual instructions packaged with the kits or accessories when

installing.

Follow all safety codes. Wear safety glasses, protective clothing, and

work gloves. Have a fire extinguisher available. Read these instructions

thoroughly and follow all warnings and cautions included in literature

and attached to the unit. Consult local building codes and the current

edition of the National Electrical Code (NEC) NFPA 70. In Canada, refer

to the current editions of the Canadian Electrical Code CSA C22.1.

Recognize safety information. When you see this symbol on the unit

and in instructions or manuals, be alert to the potential for personal

injury. Understand the signal words DANGER,WARNING,and

CAUTION. These words are used with the safety--alert symbol.

DANGER identifies the most serious hazards, which will result in severe

personal injury or death. WARNING signifies hazards, which could

result in personal injury or death. CAUTION is used to identify unsafe

practices, which may result in minor personal injury or product and

property damage. NOTE is used to highlight suggestions which will

result in enhanced installation, reliability, or operation.

Welcome

The BryantLegacytLine Wi--FiThermostat helps homeowners

conserve energy, save money and reduce their environmental impact.

This thermostat automates energy conservation, making it comfortable

when you are home and saving money when you are not.

A13336

Fig. 1 -- Legacy Line Wi--Fi Thermostat

Key features of the Legacy Line Wi--Fi Thermostat:

dColor display

dPrecision +/-- 1°F(0.5°C) temperature control

dRemote access via the Internet, tablet or smartphone

dVacation programming

dSeven--day programming

dHumidity sensing

dIntelligent algorithms that adapt to your home and preferences

dFan control

COMFORT SERIES Wi--Fi THERMOSTAT

BASICS

The Legacy Line Wi--Fi Thermostat has an easy--to--read color screen

that displays all the information you need to set and manage your

thermostat. Use the navigation buttons on the right to quickly change the

temperature, access features, and configure your settings.

What’s on the Home Screen?

Whenever you press a button, the Home screen is displayed.

A13368

Fig. 2 -- Home Screen

1. Current Temperature and Humidity

The displayed current temperature and humidity is based on the room

where the Legacy Line Wi--Fi Thermostat is installed. You can set the

Legacy Line Wi--Fi Thermostat to display Celsius or Fahrenheit. See

Temperature Display on Pg. 19.

2. System Mode

The current method of temperature control: heat, cool, or auto. See

System Mode on Pg. 13.

3. Current Set Point

The temperature at which the system is programmed to maintain at a

particular point in time.

Press Y(up) or (down) to adjust it manually by increments of 1°F(0.5°

C). If the system is set to Auto, press A(left) or "(right) to switch

between heat and cool set points.

When you manually adjust the set temperature, you put the system into a

Hold mode. See Hold Action on Pg. 20. To return back to the

pre--programmed temperature, press OK.

For maximum savings you should program your Legacy Line Wi--Fi

Thermostat to control the temperature automatically. See Creating Your

Weekly Schedule on Pg. 27.

4. Current Time/Date

Displays the current date and time for your time zone.

5. Internet Access

Indicates the Legacy Line Wi--Fi Thermostat is connected to the Internet.

The more bars, the stronger the signal. A chain link indicates

communication with the Bryant web servers.

Using the Navigation Buttons

The navigation buttons located on the right of the Legacy Line Wi--Fi

Thermostat let you select options and control the thermostat.

A13356

dY(up) On the Home screen, press Yto increase the temperature

set point by 1°F(0.5°C). For menus, press Yto move up.

dB(down) On the Home screen, press Bto decrease the tempera-

ture set point by 1°F(0.5°C). For menus, press Bto move

down.

dA(left) On the Home screen, if Auto mode is enabled, press A

to switch between heat and cool set points. For menus, press Ato

go back to the previous screen.

d"(right) On the Home screen, if Auto mode is enabled, press "

to switch between heat and cool set points. For menus, press "to

choose the currently highlighted option.

dOK On a menu screen, press OK to choose the currently high-

lighted option. If a configuration option is selected, pressing OK

will keep its new value and return back to the previous screen.

dMENU Pressing MENU displays a list of all available options. If

a menu is currently displayed, pressing MENU will cancel any

unsaved changes and return to the Home screen.

A13357

dBACK On a menu screen, press BACK to go back to the previ-

ous screen.

BACK

A13358

On--Screen Keyboard

If you need to type in any information, an on--screen keyboard will

appear. To enter a letter or number, move to the character by pressing the

arrow keys and then press OK to select it.

Select the [Caps] key to enter capital letters; select the [&@#] key to

enter commonly used symbols. If you make a mistake, press the [X]

backspace key to delete the text .

To keep your changes, select Save. To cancel your changes, press

BACK.

Idle Screen

When you are not actively using your Legacy Line Wi--Fi Thermostat,

the screen will dim and display the idle screen.

A13369

Fig. 3 -- Idle Screen

The Idle screen can show the temperature, time and date, humidity,

weather conditions, and operating mode (red for heat, blue for cool).

Snowflake and flame icons indicate if cooling or heating is currently

engaged.
