Bryant TSTATBBPS101 Guida
1 Day Programmable
4 Time Periods per Day
Auto Changeover
Easy To Read Display
Thermoglow Backlight
No Batteries Required
67
70
HEAT
COOL
AUTO
o
o
Am
6:03
68
Su
Heat Pump & Heat Cool
USERS INFORMATION MANUAL
MODEL TSTATBBPS101
PROGRAMMABLE DIGITAL
THERMOSTAT
NOTE TO INSTALLER:
This manual must be left with the equipment user.
Heating & Cooling Systems
Meets California Title 24 Residential
Table Of Contents
FRONT PANEL
DISPLAY
QUICK START Set the clock and go
BASIC OPERATION
PROGRAMMING 4 Time Periods
ADVANCED SETUP
ABOUT ADVANCED OPERATION
WARRANTY
Page 1
CAUTION
Follow Installation Instructions before proceeding.
SET THERMOSTAT TO MODE “OFF” PRIOR TO
CHANGING SETTINGS IN SETUP OR RESTORING
FACTORY DEFAULTS.
TSTATBBPS101
2
3
5
6
8
11
14
18
Residential Light Commerical Systems Carrier Corporation 4/01
Front Panel
Page 2
Backlit LCD Display
Warmer or + Button
Cooler or - Button
Mode Button
Heat or Cool Indicator
Red = Heat, Green = Cool
67
70
HEAT
COOL
AUTO
o
o
Am
6:03
68
S
SET CLOCK
PROGRAMVACATIONOUTSIDEFAN MODE
Programmable
Thermostat
FAN PROGRAM
BACKLIGHT SET CLOCK
EMERGENCY HEAT
67
70
HEAT
COOL
AUTO
o
o
Am
6:03
68
Su
1
2
4
3
Mode Indicators
Selects the operation mode of the equipment.
HEAT - indicates the heat mode.
COOL - indicates the air conditioning mode.
AUTO - indicates the system will automatically
changeover between heat and cool modes
as the temperature varies.
OFF - indicates the entire system is turned off.
PROGRAM ON - indicates the stored program
is enabled to run. Page 6.
Time Clock
Indicates the current time of day. This clock is
also used to program the timer periods. Page 8.
Room Temperature Display
Indicates the current room temperature.
Desired Set Temperature
Indicates desired room temperature(s). Page 6
Display
Page 3
1
1
1
1
2
3
4
4
6
5
7
8
9
88
88
HEAT
COOL
OFF
AUTO
Fan On
Program
Locked
Setup
On
Start
o
o
Am
Pm
12:00
88
:
Day
Night
Evening
Morning
5
6
7
8
9
Morning, Day, Evening & Night Indication
Indicates the program time period. Page 8-10.
Setup Indication
Indicates the thermostat is in the programming
mode. Page 6.
Fan Operation Indication
Fan On - indicates constant, continuous fan
operation.
When Fan On is not lit - indicates the fan will
only operate when necessary to heat or
to cool. Page 7.
Locked Indication
Locked appears after the right combination of
buttons are pressed, rendering the buttons
inoperative. Page 16.
Start Indication
Start appears when programming
timer functions. Page 8
Display
Page 4
During Setup & Programming:
Pressing the Mode button
selects different flashing items.
(Represented in dark black)
Pressing the Up and Down
buttons will modify the flashing
selection.
Press the Set Clock
button to enter Setup
screens.
Press the SET CLOCK
button to return to
normal operation.
Quick Start Set the Clock and Go
Page 5
The thermostat is preprogrammed from the
factory to operate 1 stage of cooling or 2 Stages
of heating equipment* without the need for further
programming. To optimize the installation of this
thermostat follow the instructions in the Advanced
Setup section.
* The thermostat is not preprogrammed from the
factory to operate electric heat or heat pump systems.
To control these systems, follow the steps in the
Advanced Setup section, pages 11 & 12.
Press
buttons.
To adjust the
clock or Day use
SET CLOCK
MODE
SET CLOCK
Setup
AM
I2:00
I
Setup
2
Mo
The HEAT setting indicates the
temperature the room has to
reach before the furnace will
turn on to heat the room.
The COOL setting indicates the
temperature the room has to
reach before the air conditioner
will turn on to cool the room.
OFF indicates both heating
and air conditioning
systems are turned off.
AUTO will automatically select
heat or cool based on room
temperature demand.
Program On will activate the
stored timer operation.
(Morning, Day, Evening
& Night Periods)
Select Mode
Basic Operation
Page 6
Press
Press
Press
Press
MODE
MODE
MODE
MODE
69
HEAT
o
Pm
12:00
70
:
72
COOL
o
Pm
12:00
70
:
69
72
HEAT
COOL
AUTO
o
o
Pm
12:00
70
:
OFF
Pm
12:00
70
:
70
73
HEAT
COOL
ProgramOn
o
o
Pm
12:00
70
Day
:
buttons.
In any mode, adjust the
desired Set Temperature
with
Pressing the Up or Down buttons in Auto mode will adjust both the heat and cool
set temperatures simultaneously.
Pressing the Up or Down buttons in Heat or Cool modes will adjust only the
heat or cool set temperature.
Select Desired Temperature
Fan
Operation
Page 7
Basic Operation
69
72
HEAT
COOL
AUTO
o
o
Pm
12:00
70
:
Fan On indicates constant fan operation.
This feature is active even if the thermostat
is set to Off.
55
85
HEAT
COOL
o
o
Pm
12:00
65
:
Fan On
Press
FAN
Programming 4 Time Periods
Page 8
Press the PROGRAM button to enter time period programming.
Continued
Adjust the start time
for Morning.
Adjust the heating
setpoint for Morning.
Adjust the cooling
setpoint for Morning.
(35 - 99 )
(35 - 99 )
Start
Am
7 30
Morning
:
74
COOL
o
Am
7 30
Morning
:
72
74
HEAT
COOL
o
o
Am
7 30
Morning
:
Use the back cover Programming Worksheet to help with this section.
Press
PROGRAM
Press
MODE
Press
MODE
Press
MODE
Programming 4 Time Periods
Page 9
Continued
Adjust the start time
for Evening.
Adjust the cooling
setpoint for Evening.
Adjust the start time
for Day.
Adjust the heating
setpoint for Day.
Adjust the cooling
setpoint for Day.
(35 - 99 )
(35 - 99 )
(35 - 99 )
Start
Am
I0 30
Day
:
Start
Pm
5 30
Evening
:
Day
75
COOL
o
Am
I0 30
:
Evening
75
COOL
o
Pm
5 30
:
Day
73
75
HEAT
COOL
o
o
Am
I0 30
:
Press
MODE
Press
MODE
Press
MODE
Press
MODE
Press
MODE
