Type 2933, 2934, 2935, 2973, 2974, 2975
Manually operated diaphragm valves
We reserve the right to make technical changes without notice.
Technische Änderungen vorbehalten.
Sous réserve de modifications techniques.
© Bürkert Werke GmbH & Co. KG, 2023
Operating Instructions 2304/00_EU-ML_00815442 / Original DE
3
Table of contents
1 OPERATING INSTRUCTIONS............................................... 4
1.1 Symbols....................................................................... 4
1.2 Denitionofterms ....................................................... 4
2 INTENDED USE .................................................................... 5
3 BASIC SAFETY INSTRUCTIONS.......................................... 5
4 GENERAL NOTES................................................................. 7
4.1 Contact addresses ...................................................... 7
4.2 Warranty ...................................................................... 7
4.3 InformationontheInternet.......................................... 7
5 PRODUCT DESCRIPTION .................................................... 7
5.1 Structure and description............................................ 7
5.2 Variants........................................................................ 7
5.3 Function....................................................................... 8
5.4 Productidentication .................................................. 9
6 TECHNICAL DATA............................................................... 11
6.1 Standards and directives........................................... 11
6.2 Mechanical data ........................................................ 11
6.3 Port connections valve body..................................... 12
6.4 Operating conditions ................................................. 12
6.5 Flow values................................................................ 14
7 INSTALLATION .................................................................... 16
7.1 Informationforthecorrectinstallationposition......... 17
7.2 Preparatory work ....................................................... 18
7.3 Install device.............................................................. 19
7.4 Set stroke limit........................................................... 20
7.5 Lock handwheel ........................................................ 21
8 MAINTENANCE................................................................... 22
8.1 Cleaning .................................................................... 22
8.2 Maintenance work ..................................................... 23
8.3 Replacing the diaphragm .......................................... 23
9 REPLACEMENT PARTS, ACCESSORIES .......................... 25
9.1 Replacement diaphragms ......................................... 26
10 TRANSPORTATION, STORAGE, DISPOSAL ...................... 27
english
Type 2933, 2934, 2935, 2973,
2974, 2975
4
Operating instructions
1 OPERATING INSTRUCTIONS
Theoperatinginstructionsdescribetheentirelifecycleofthedevice.
Keep these instructions ready to hand at the operating site.
Important safety information.
▶Readtheseinstructionscarefully.
▶Aboveall,observethesafetyinstructions, intendeduseand
operating conditions.
▶Persons who work on the device must read and understand
these instructions.
1.1 Symbols
DANGER
Warning of an immediate danger.
▶Failure to comply will result in death or serious injury.
WARNING
Warns of a potential danger.
▶Failure to observe these warnings may result in serious injuries
or death.
CAUTION
Warns of a potential hazard.
▶Failure to comply with these instructions may result in moderate
or minor injury.
NOTE
Warns of damage.
Important tips and recommendations.
Referstoinformationintheseoperatinginstructionsorin
other documentation.
▶Highlights instructions to avoid a danger.
→Designates a procedure which you must carry out.
1.2 Denition of terms
Term Denition for these instructions
Device Diaphragm valve type 2933, 2934, 2935,
2973, 2974 and 2975
Ex area Potentially explosive atmosphere
Explosion protection
approval
Approval in potentially explosive
atmosphere
english
Type 2933, 2934, 2935, 2973,
2974, 2975
5
Intended use
2 INTENDED USE
The diaphragm valve type 2933, 2934, 2935, 2973, 2974 and
2975 is designed to control the ow of media. The authorised
media are listed in chapter “Technical data”.
▶Use the device only as intended. Non-intended use of the
device may be dangerous to people, nearby equipment and
the environment.
▶Prerequisites for safe and trouble-free operation are correct
transportation, correct storage, installation, start-up, operation
and maintenance.
▶To use the device, observe the permitted data, operating con-
ditionsandapplicationconditions. Thesespecications can
befoundinthecontractdocuments,theoperatinginstructions
and on the Type label.
▶Use the device only in conjunction with third-party devices and
components recommended or approved by Bürkert.
▶Onlyuseequipmentthatisapprovedforthistypeofpotentially
explosivearea.Thesedevicesareidentiedbyaseparate“Ex”
typelabel.Beforeuse,notetheinformationontheseparateEx
type label and the Ex additional instructions or the separate Ex
operating Instructions.
▶Protectdevicefromenvironmentalinuences(e.g.radiation,
airhumidity,fumes).Ifyouhaveanyquestions,contactyour
Bürkert sales department.
3 BASIC SAFETY INSTRUCTIONS
Thesesafetyinstructionsdonottakeintoaccountanyunforeseen
circumstances or events that occur during installation, operation
and maintenance. The operator is responsible for observing
the location-specic safety regulations, also with reference to
personnel.
Risk of injury due to high pressure and escaping medium.
▶Switchothepressurebeforeworkingonthedeviceorsystem.
Vent or empty the lines.
Electric shock due to installed electrical component.
▶Beforeworkingonthedeviceorsystem,switchothepower
supply. Secure against reactivation.
▶Observe any applicable accident prevention regulations and
safetyregulationsforelectricaldevices.
Danger of bursting in case of overpressure.
Ifthedevicebursts, themediummaycauseinjuries, burnsor
scalds.
▶Do not exceed the maximum medium pressure. Observe spec-
icationsonthetypelabel.
▶Observe allowable temperatures.
Danger of burns and risk of re.
Quicklyswitchingactuatorsorhotmediummaycausethesurface
ofthedevicetobecomehot.
▶Only touch the device when wearing protective gloves.
▶Keepthedeviceawayfromhighlyammablesubstancesand
media.
english
Type 2933, 2934, 2935, 2973,
2974, 2975
6
Basic safety instructions
Medium may leak out if the diaphragm is worn.
▶Inspectreliefboreforanymediumleakages.
▶Changethediaphragmifmediumleaks.
▶Ifthemediumishazardous,securetheareaaroundtheleakage
to prevent risks.
Danger of crushing due to mechanically moving parts.
Thereisariskofcrushingduetotheupanddownmovement
ofthedevicewhenitisactuated.
▶Donotreachintotheopeningsofthevalvebody.
Danger due to loud noises.
Depending on the operating conditions, the device may generate
loudnoises.Moredetailedinformationonthelikelihoodofloud
noisesisavailablefromtherelevantsalesoce.
▶Wearhearingprotectionwheninthevicinityofthedevice.
To avoid injury, observe the following:
▶Do not make any changes to the device and do not subject it
to mechanical stress.
▶Onlytrainedtechniciansmayperforminstallation andmain-
tenance work.
▶Onlyusesuitabletoolstoperforminstallationandmaintenance
work.
▶Heavy equipment must only be transported, assembled and
disassembledwiththehelpofasecondpersonasappropriate
and using suitable apparatus.
▶Only hand-tighten the valve when closing. Too much tightening
may damage the diaphragm.
▶Theprocessmustberestartedinadenedorcontrolledmanner
afteraninterruptioninthepowersupplyorpneumaticsupply.
▶Thedevicemaybeoperatedonlywheninperfectconditionand
inconsiderationoftheoperatinginstructions.
▶Forapplicationsplanningandoperationofthedevice,observe
theplant-specicsafetyregulations.
▶Only the media listed in chapter “Technicaldata”shouldbefed
into the medium ports.
▶Observethegeneralrulesoftechnicalequipment.
▶Theplantownerisresponsibleforthesafeoperationandhan-
dlingoftheplant.
english
Type 2933, 2934, 2935, 2973,
2974, 2975
7
General notes
4 GENERAL NOTES
4.1 Contact addresses
Germany
Bürkert Fluid Control Systems
Sales Centre
Christian-Bürkert-Str.13–17
D-74653Ingelngen
Tel.+49(0)7940-1091111
Fax+49(0)7940-1091448
E-mail:[email protected]
International
Thecontactaddressescanbefoundonthebackpagesofthe
printed operating instructions.
They are also available online at: country.burkert.com
4.2 Warranty
Apreconditionforthewarrantyisthatthediaphragmvalveisused
asintendedinconsiderationofthespeciedoperatingconditions.
4.3 Information on the Internet
Operatinginstructionsanddatasheetsfortype2933,2934,
2935,2973,2974,2975canbefoundonlineat:
country.burkert.com
5 PRODUCT DESCRIPTION
5.1 Structure and description
The device is a manually controlled diaphragm valve with diaphragm
seal.Thevalveconsistsofamanualactuatorandavalvebody.
5.2 Variants
Types293xand297xaredierentiatedbytheactuator.
Thexisdierenttothevalvebody.
5.2.1 Type 2933
Handwheel
Diaphragm
Valve body
Attachment with scale
Port connection
Fig. 1: Example of 2/2-way valve, type 2933
english
Type 2933, 2934, 2935, 2973,
2974, 2975
8
Product description
5.2.2 Type 2934 with T-valve body
Handwheel
Attachment with scale
Diaphragm
T-Valve body
Port connection
Fig. 2: Example of valve with T-valve body, type 2934
5.2.3 Type 2935 with tank bottom body
Handwheel
Attachment with scale
Diaphragm
Tank bottom body
Port connection
Fig. 3: Example of valve with tank bottom body, type 2935
5.2.4 Type 2973, 2974, 2975
Handwheel with lock
(optional)
Valve body
Diaphragm
Attachment with scale
Port connection
Fig. 4: Example of 2/2-way valve, type 2973
5.3 Function
Bymanuallyactivatingthehandwheel,theforceistransmittedviaa
spindle and the valve is opened or closed. The medium in the valve
bodyisreleasedorshuto.Turningthehandwheelanticlockwise
opens the valve, turning it clockwise closes the valve.
5.3.1 Position indicator actuator
5.3.1.1 Actuator DN8
When turning the handwheel anticlockwise, a yellow marking
becomes visible between the attachment and the handwheel.
english
Type 2933, 2934, 2935, 2973,
2974, 2975
9
Product description
Thevisibilityoftheyellowmarkingisnotdirectlyrelated
totheclosedpositionofthevalve.Dependingonthecon-
structionofthevalve,themarkingmay:
- not be visible when the valve is open, or
- visible when the valve is closed.
5.3.1.2 Actuator DN15 to DN50
Reproducible stroke scale
Handwheel with scale
Fig. 5: Position indicator
When turning the handwheel anticlockwise, a reproducible
stroke scale becomes visible between the attachment and the
handwheel.
Thevisibilityofthestrokescaleisnotdirectlyrelatedto
theclosedpositionofthevalve.Dependingonthecon-
structionofthevalve,thereproduciblestrokescalemay:
- not be visible when the valve is open, or
- visible when the valve is closed.
Thescaleon the handwheel determinesthe rotationposition of
thehandwheel(type293x:30positions,type297x:50positions).
Thereproduciblestrokescale showstherelativepositionofthe
valve and serves as a xed point for determining the rotational
position.
5.4 Product identication
5.4.1 Type label
Typ 2933 DN15 ER
00123456
S/N: 1001 W22MN
Tmed:
-10...+145°C
NO01 NO17
D-74653
Ingelfingen
1
2
5
34
6
7
8
Fig. 6: Description of the type label (example)
Item Description Item Description
1Manufacturer 5 Medium temperature
2 Type 6 Valvebodysurface
roughness
3 Nominal diameter 7 Serial number
4 Seal material 8 Order number
english
Type 2933, 2934, 2935, 2973,
2974, 2975
10
Product description
5.4.2 Labelling on forged steel valve body
XXXXXXXXXX
XX F
1.4435/316L(VS)
PN16/CWP150
XXXXXXXX/XXX
XXXXXX
XXXX
1
2
3
4
5
6
7
8
Fig. 7: Labelling on forged steel valve body
Item Description Item Description
1 Company logo 5 Production number/
serial number
2 Material 6 Self-drainingangle
3 Nominal pressure
class(PN)
7Customer-specictext
(optional)
4 Batch number 8 Nominal diameter and
pipe dimensions
5.4.3 Labelling on cast valve body
5
6
23
4
1
Fig. 8: Labeling on cast valve body
Item Description Item Description
1 Company logo 4 Nominal diameter
(diaphragmsize)
2 Material 5 Batch number
3 Nominal pressure
class(PN)
6 Nominal diameter and
pipe dimensions
english
Type 2933, 2934, 2935, 2973,
2974, 2975
Questo manuale è adatto per i seguenti modelli
5
Indice
Altri manuali Burkert Unità di controllo
Burkert
Burkert 8695 Series Manuale utente
Burkert
Burkert 2610 Manuale utente
Burkert
Burkert AirLINE 8652 Series Manuale utente
Burkert
Burkert 2103 Series Manuale utente
Burkert
Burkert 6440 Manuale utente
Burkert
Burkert 2100 series Guida
Burkert
Burkert 3360 Manuale utente
Burkert
Burkert 2031 INOX Manuale utente
Burkert
Burkert 6510 Manuale utente
Burkert
Burkert 2712 Series Manuale utente
Burkert
Burkert 8691 REV.2 Manuale utente
Burkert
Burkert 2063 Manuale utente
Burkert
Burkert 6628 Manuale utente
Burkert
Burkert 5281 Manuale utente
Burkert
Burkert 2730 Series Manuale utente
Burkert
Burkert 6014 Manuale utente
Burkert
Burkert 8835 Manuale utente
Burkert
Burkert 2101 Manuale utente
Burkert
Burkert 8690 Manuale utente
Burkert
Burkert 3360 Manuale utente
Manuali Unità di controllo popolari di altre marche
Festo
Festo Compact Performance CP-FB6-E Manuale elenco delle parti
Elo TouchSystems
Elo TouchSystems DMS-SA19P-EXTME Manuale utente
JS Automation
JS Automation MPC3034A Manuale utente
JAUDT
JAUDT SW GII 6406 Series Guida rapida
Spektrum
Spektrum Air Module System Manuale utente
BOC Edwards
BOC Edwards Q Series Manuale utente
