Bushnell 190125 Manuale utente

Model# 190125 / 07-13

ED WB

See what this new Legend is made of.

e new generation of Bushnell’s Legend binoculars has

been redesigned with even higher-performance optics and

a lighter, tougher body design-no wonder we call them

“Ultra•HD.” For the ultimate in detailed resolution and

color delity, they’re engineered with high density ED

Prime Glass. e razor-sharp optics are fully multicoated-

in fact, each lens is individually custom treated with our

new Ultra Wide Band Coating that optimizes brightness

and contrast. New Rainguard® HD forces moisture

to “bead up” tighter than ever, and even boosts light

transmission while ensuring foul weather or your own

breath will never cost you a view. We cut the weight by

adding a magnesium chassis. With class-leading eld of

view and extra-long eye relief, the latest chapter of the

Legend covers more country with less eort than ever

before.

ED Prime Glass. ED Prime Extra-Low

Dispersion uorite glass delivers

amazing color resolution and contrast,

and virtually eliminates chromatic

aberration and color-fringing to bring

out the most distinct details possible in

low-light conditions.

Ultra Wide Band Coating. An anti-

reection coating process that is

customized for every lens element in

the optical path, in order to allow the

best possible light from the front glass

all the way back to the eyepiece. The

result? Optimum brightness and true

color across the light spectrum.

Rainguard® HD. This patented*,

permanent, water-repellent coating

causes moisture from rain, snow, sleet

or condensation to bead up and scatter

less light, so you get a clear, bright view

when other optics would be rendered

useless.

*U.S. Patents # 6,906,862 , 6,816,310 and 6,542,302

ank you for purchasing your new Bushnell Legend Ultra HD™ Binoculars.

is manual will help you optimize your viewing experience by explaining how you can adjust the

binocular to your eyes, and how to care for this instrument. Read the instructions carefully before using

your binocular.

EYE ADJUSTMENTS

How to Adjust for Distance Between Your Eyes

e distance between the eyes, called “interpupillary distance,”

varies from person to person.

To achieve perfect alignment of lens to eyes, follow these simple

steps:

1. Hold your binocular in the normal viewing position.

2. Grasp each barrel rmly. Move the barrels closer

together or further apart (Fig. 1) until you see a single

circular eld. Always re-set your binocular to this

position before using it.

How to Adjust for Individual Eye Strength

As individual eyesight varies from one person to another, your

Bushnell Legend Ultra HD binocular has a diopter setting

feature which allows you to ne-tune the binocular to your

vision. Follow the focusing instructions on the next page. Fig. 1-Interpupillary

Distance Adjustment

FOCUSING

1. Adjust the interpupillary distance (Fig. 1) until you see a single circular

image.

2. e diopter adjustment ring is located directly below the right eyecup.

Make sure the diopter adjustment is set to “zero” (small vertical mark

on diopter ring is lined up with vertical index mark on right side of

binocular). (Fig. 2) Keep both eyes open at all times.

3. Using the attached lens cap or your hand, cover the objective (front) lens

on the right side of the binocular as you look into the eyepieces.

4. Using the center focus knob (Fig. 3), focus on a distant object with ne

detail (e.g., brick wall, tree branches, etc) until it appears as sharp as

possible on the left side.

5. Uncover the objective lens on the right side, and cover the left objective

lens while continuing to view the same object.

6. Rotate the diopter adjustment ring to bring the object into focus in the

right side of the binocular. Avoid over-turning or forcing the diopter

mechanism. If you are unable to bring the object into focus in the right

side by adjusting the diopter ring, make sure the left side is still focused

and that the center focus knob was not moved from its original setting.

e diopter adjustment only aects the right side.

7. Your binocular should now be adjusted for your eyes. Focusing for any

distance can now be done simply by turning the center focus knob.

Make a note of the diopter setting you made (which small mark on the

Fig. 3-Center

Focus Knob

Fig. 2-Diopter

Adjustment Ring

Index Mark

diopter ring scale is opposite the vertical index mark on the

binocular) for future reference.

EYECUP ADJUSTMENT:

Your Bushnell Legend Ultra HD binocular is tted with twist-

up eyecups designed for your comfort and to exclude extraneous

light. For users without eyeglasses, twist the eyecups up, rotating

the eyecups counter-clockwise until they lock into the fully “up”

position (Fig. 4). If you wear glasses, make sure the eyecups are in

the down position- this will bring your eyes closer to the binocular

lens, allowing you to see the full eld of view. To lower the

eyecups from the full “up” position, rotate them clockwise (Fig.

5). e eyecups may also be left at positions “in between” fully up

and fully down, which may suit some individuals better.

NEVER LOOK DIRECTLY AT THE SUN WITHYOUR BINOCULAR

AS IT MAY CAUSE SERIOUS DAMAGETO YOUR EYES

Fig. 4-Eyecup in

“Up” Position

Fig. 5-Eyecup in

“Down” Position

NECKSTRAP ATTACHMENT :

To attach the neckstrap:

1. read the narrow black section on one end of the strap

through the small lug on one side of the binocular (below

the eyepiece).

2. Loop the black part of the strap back into the plastic strap

buckle, threading it through the lower part of the buckle

(loosen and push the strap that’s already going through the

top part of the buckle out of the way rst, to make this easier

to do).

3. Repeat this process for the other side of the strap and

binocular.

4. Adjust the length of the strap so the binocular hangs around

your neck in a comfortable position (you may need to loosen

the strap slightly rst, so it pulls easily through the plastic strap

buckles-being careful that the binocular remains supported

so it cannot fall to the oor). Any excess length of black strap

that sticks out after making your nal adjustments can then

be secured in place by sliding the small plastic sleeves over it.

5. Be sure to check that the strap is securely fastened by tugging

on the binocular (keep a grip on it) while wearing the strap

around your neck before you start using your binoculars for

the rst time.

Fig. 6-Strap

rough Lug

Fig. 7-Strap

rough Buckle

WATERPROOF / FOGPROOF

Your Bushnell Legend Ultra HD binocular has been designed and built utilizing the latest waterproof

and fogproof technology. e binoculars are O-ring sealed for complete moisture protection. Fogproof

protection is achieved from dry nitrogen purging that removes all internal moisture.

INSTRUCTIONS FOR CARE

Your Bushnell Legend Ultra HD binocular will provide years of trouble-free service if it receives the

normal care you would give any ne optical instrument.

1. Avoid sharp impacts. Set the binocular down gently on hard surfaces.

2. Tug on the strap after attaching it to make sure it is securely fastened to the binocular before placing

it around your neck.

3. Store your binocular in a cool, dry place whenever possible.

CLEANING

1. Blow away any dust or debris on the lens (or use a soft lens brush).

2. To remove dirt or nger prints, clean with the supplied micro-ber cloth rubbing in a circular

motion. Use of a coarse cloth or unnecessary rubbing may scratch the lens surface and eventually

cause permanent damage. e included, washable“microber”cleaning cloth is ideal for the routine

cleaning of your optics. Simply breathe lightly on the lens to provide a slight amount of moisture,

then gently rub the lens with the microber cloth.

3. For a more thorough cleaning, photographic lens tissue and photographic-type lens cleaning uid

or isopropyl alcohol may be used. Always apply the uid to the cleaning cloth – never directly on

the lens.

WARRANTY/REPAIR

LIFETIME LIMITED WARRANTY

We are so proud of our Bushnell®Legend Ultra HD™ Binoculars that their materials and workmanship are warranted to be free of defects for the life of the

binocular. e warranty is available to any owner of the Legend Ultra HD Binocular. is warranty does not cover damages caused by misuse or improper

handling, installation or maintenance of the binoculars.

At our option, we will repair or replace any defective Legend Ultra HD binocular, which shall be your sole remedy under this warranty. In no event shall

we be liable for transportation costs to us, costs of removal or reinstallation of the binocular, or incidental or consequential damages. Some states do not

allow the exclusion of limitation of incidental or consequential damages, so the above limitation or exclusion may not apply to you.

Any return in the U.S. or Canada made under this warranty must be accompanied by the items listed below:

1) A check/money order in the amount of $10.00 to cover the cost of postage and handling

2) Name and address for product return

3) An explanation of the defect

4) Proof of Purchase

Product should be well packed in a sturdy outside shipping carton, to prevent damage in transit, with return postage prepaid to the address listed below:

IN U.S.A. Send To: IN CANADA Send To:

Bushnell Outdoor Products Bushnell Outdoor Products

Attn.: Repairs Attn.: Repairs

9200 Cody 140 Great Gulf Drive, Unit # B

Overland Park, Kansas 66214 Vaughan, Ontario L4K 5W1

For products purchased outside the United States or Canada please contact your local dealer for applicable warranty information. In Europe you may also

contact Bushnell at: Bushnell Germany GmbH

European Service Centre

Mathias-Brüggen-Str. 80

D-50827 Köln

GERMANY

Tel: +49 221 995568-0

Fax: +49 221 995568-20

is warranty gives you specic legal rights. You may have other rights which vary from country to country.
