Introduction
Last updated: 1月 19, 2023 01:59. Revision #8438
Thank you for purchasing these Cambridge Audio EVO S bookshelf loudspeakers. We hope that you enjoy many years of listening pleasure from
them. Your loudspeakers can only be as good as the system it is connected to. Please do not compromise on your amplifier or cabling. Naturally we
particularly recommend amplification from the Cambridge Audio range, which has been designed to the same exacting standards as our
loudspeakers. Your dealer can also supply excellent quality speaker cable to ensure your system realises its full potential.
Thank you for taking the time to read this manual; we do recommend you keep it for future reference.
© Copyright Cambridge Audio Ltd .
For upcoming news on future products, software updates and exclusive offers, make sure you register your product at
http://www.cambridgeaudio.com/register
5
What's included with the EVO S?
Last updated: 1月 19, 2023 01:59. Revision #8439
1. 2 x EVO S bookshelf speakers.
2. 2 x magnetic speaker grille.
3. 2 x bass plug.
4. 2 x 3m speaker cable (terminated).
5. Quick start guide.
6
Front panel
Last updated: 1月 19, 2023 01:59. Revision #8440
1. 1” (25mm) Silk Dome Tweeter.
2. 6.5”(165mm) Anodized Aluminium Mid/Bass Driver.
7
Rear panel
Last updated: 1月 19, 2023 01:59. Revision #8441
1. Rear bass port.
2. +/- Speaker connection terminals.
8
Installation instructions
Last updated: 1月 19, 2023 02:00. Revision #8442
1. Firstly, using high quality speaker cable connect the EVO S speakers to the speaker terminals on your amplifier. Ensure that you pay close attention
to match the polarity of each connection.
2. If placed on a desk, or close to a wall you may benefit from using the included foam bass tuning bungs. These can be placed into the rear port of
each speaker to reduce the low frequency output.
3. Finally, when positioning, we would suggest that the distance between speakers and the listening position is equal. However, we would encourage
experimentation until you find a solution that works for your space.
9
10
Technical specifications
Last updated: 1月 19, 2023 02:00. Revision #8443
Sensitivity (SPL)
88dB
Frequency Response
50Hz - 40kHz
Impedance
8 Ohms
Drivers
1 x 6.5” (165mm) anodized aluminium cone mid/bass.
1 x 1” (25mm) silk dome tweeter.
Crossover
2 Way
Recommended Amplifier Power
25 - 200 watts
Porting
1 Rear
Speaker Dimensions (H x W x D)
200 x 284 x 216mm.
Weight
7.1kg (16.9lbs)
