Canon PIXMA G5000 Series Manuale utente

Guía de inicio

Lea primero Información de seguridad

e información importante (apéndice).

Conﬁguración en línea

Hay vídeos e instrucciones detalladas en

el sitio web de Canon.

Conﬁgurar un ordenador

Conﬁgurar un teléfono inteligente

Getting Started

Read Safety and Important Information

(addendum) ﬁrst.

Online Setup

Detailed instructions and videos are

available on the Canon website.

Setup a Computer

Setup a Smartphone

Instalación de la impresora ...............................................................................................página 1

Conexión con un ordenador, teléfono inteligente o tableta.......................página 4

Vídeos instructivos

Cómo sujetar la impresora

Installing the Printer...................................................................................................................page 1

Connecting to a Computer, Smartphone or Tablet...............................................page 4

Holding the Printer

Instructional Videos

ENGLISH

Setting Up the Printer Online Setup

1. Box Contents

•

Print heads •

Ink bottles

•

Power cord

•

Setup CD-ROM

•

Safety and Important Information

•

Getting Started (this manual)

2. Removing Packing Materials

1 Remove and dispose of any packing materials

and orange tape.

2 Open the top cover, remove and dispose of the

orange tape and protective material inside.

3. Installing the Print Heads

1 Open the print head locking cover.

2 Take out each print head from the package and

remove the label.

3 Remove the protective tape.

4 Insert the C (color) print head on the left and the

B (black) print head on the right.

5 Close the print head locking cover and press

down until it clicks.

6 Press down both joint buttons completely until

they click.

Check!

Setting Up the Printer

4. Pouring Ink

Important

This product requires careful handling of ink. Ink may splatter

when the ink tanks are ﬁlled with ink. If ink gets on your clothes or

belongings, it may not come oﬀ.

1 Open the ink tank cover and tank cap on the left

of the printer.

2 Hold the ink bottle upright and gently twist the

bottle cap to remove.

Check!

PGBK

3 Align the nozzle of the ink bottle with the inlet.

4 Slowly stand the ink bottle upside down and

push down to pour the ink.

• If the ink does not pour, gently remove the ink bottle

and try again.

5 Gently remove the ink bottle from the inlet.

• Be careful not to spill the ink.

6 Replace the tank cap securely, and then close

the ink tank cover.

7 Repeat steps 1 through 6 to pour all ink into the

corresponding ink tanks on the right.

Check!

CMY

8 Close the top cover.

5. Turning on the Printer

1 Connect the power cord.

Back

Important

At this time, do not connect any other cables.

2 Press the ON button.

ENGLISH

3 When the following screen appears, use the [

and ]buttons to select a language, and then

press the OK button.

Important

If an error appears on the screen, see "If an error message

(support code) appears on the screen" on page 3 and

follow the instructions.

6. Loading Paper

1 When the following screen appears, use the [

and ]buttons to select Yes , and then press the

OK button.

2 Remove the cassette from the printer.

3 Slide apart the paper guides.

• Slide the right paper guide to the right edge. Align

the front paper guide with the Letter or A4 mark.

4 Load paper.

• Load 2 or more sheets of Letter or A4 sized plain

paper with the print side facing down.

• Place the paper against the front paper guide, and

align the right paper guide to the width of the paper.

5 Replace the cassette.

6 Pull out the paper output tray.

7 Follow the on-screen instructions, and then

press the OK button.

• Check that Ready to connect appears on the

printer's screen.

Check the support code, and then follow the

instructions if the displayed code is written below.

• 1890

The protective materials are not removed.

"2. Removing Packing Materials" on page 1

• 1470

The print heads are not installed correctly.

"3. Installing the Print Heads" on page 1

• 1471

No print heads are installed.

"3. Installing the Print Heads" on page 1

• 1642

There may be insuﬃcient ink.

"4. Pouring Ink" on page 2

For all other cases, refer to the Online Manual.

If an error message (support code) appears on

the screen

Support code

7-b

page 6

7-a

Setting Up the Printer

Press the Stop button,

and then select Do not

connect > Yes, in this

order.

Computer Computer and

smartphone

Smartphone

No device

Connecting to a Computer

If you are using multiple computers, perform these steps on each computer. There are

two methods, " Online Setup" and " Using the Setup CD-ROM (Windows Only)

Provided".

1 Access the Canon website from a

computer.

2 Select Set Up.

3 Enter your printer's model name and click

Go.

4 Click Start.

5 Click If you have already prepared your

printer, go to Connect.

Note

The following steps are for Windows (except Windows

10 in S mode) and macOS users. For other operating

systems, continue setup by following the on-screen

instructions instead.

6 Click Download.

• The setup ﬁle is downloaded to your

computer.

7 Run the downloaded ﬁle.

8 Proceed to step 9 on page 5.

Online Setup

What device are you connecting?

Select a device and follow the instructions in the relevant section.

ENGLISH

1 Insert the Setup CD-ROM

into your computer.

2 Follow the instructions for your version of

Windows.

Windows 10/Windows 8.1

aClick on the following message when it

appears on the right-hand side of your

computer screen.

Note

If the message does not appear (or is no longer

visible), click the File Explorer icon in the

taskbar. On the left-hand side of the window, click

This PC. Double click the CD icon that is

displayed on the right-hand side. When the

content of the CD is displayed, double click

Msetup4.exe. Proceed to c.

bClick Run

Msetup4.exe.

cIf the User Account Control dialog box

appears, click Yes .

Windows 7

aClick Run Msetup4.exe.

• When the AutoPlay screen appears, click

Run Msetup4.exe.

Note

If the AutoPlay screen does not appear, in the

Start menu, click Computer. On the right-hand

side of the window, double click the CD icon.

When the content of the CD is displayed, double

click Msetup4.exe.

bIf the User Account Control dialog box

appears, click Continue.

3 Proceed to step 9 below.

Using the Setup CD-ROM (Windows Only) Provided

9 Click Start Setup.

10 Follow the on-screen instructions.

• These operations may take some time.

11 When the following screen appears, click

Exit.

Your printer is now connected to your computer.

To connect to a smartphone as well, see "7-b.

Connecting to a Smartphone" on page 6.

7-b

Setting Up the Printer

1 Install the "Canon PRINT Inkjet/SELPHY" app on your smartphone.

• Scan the QR code shown on the right to access the Canon website, and then download

the app.

2 Check the printer's screen and proceed to each step.

If the following screen is displayed,

Ready to connect

For details on how to continue, refer to

"Getting Started"

If the following screen is displayed

• If or is displayed,

• If or is not displayed,

Note

• The printer's screen turns oﬀ when the printer is idle for 10 minutes. Press any button (except the ON button) on the operation

panel to turn on the screen.

• If appears, the printer cannot communicate by Wi-Fi connection. For details, refer to "Frequently Asked Questions" at

"https://ij.start.canon".

Connecting to a Smartphone

If you are using multiple smartphones, perform these steps on each smartphone.

Prepare the following before starting.

aEnable the Wi-Fi setting on your smartphone.

bConnect your smartphone to the wireless router (if you have a wireless router).

Refer to your smartphone and wireless router manuals for more details.

3 Open the installed app. 4 Follow the on-screen instructions to add

your printer.

Once you have added your printer, you can

print from the smartphone. To print photos, see

"Loading Photo Paper" on page 8.

ENGLISH

3 Tap Settings on your smartphone's home

screen, and tap Canon_ij_XXXX in the

Wi-Fi settings.

Note

If Canon_ij_XXXX does not appear, follow the

procedure in , and then search for Canon_ij_XXXX

again.

4 Open the installed app, and then

follow the on-screen instructions

to add your printer.

• The printer is added with the most

appropriate connection method for

the environment you are using.

3 Open the installed app, and then

follow the on-screen instructions

to add your printer.

• The printer is added with the most

appropriate connection method for

the environment you are using.

Note

If a message saying "No printer has been added.

Perform printer setup?" does not appear after

starting the application, follow the procedure in ,

and then return to smartphone operations.

Procedures vary for iOS and Android. Follow the instructions for your operating system.

3 Press and hold the Wireless connect

button for about 3 seconds. 4 When Follow the instructions on the

PC or smartphone, etc. appears on the

printer's screen, proceed to .

Once you have added your printer, you can print from the smartphone. To print photos, see "Loading Photo

Paper" on page 8.

Loading Photo Paper

1 Open the rear tray cover and extend the paper

support.

2 Open the feed slot cover and slide the right-

hand side paper guide to the far right.

3 Load several sheets of photo paper with the

print side facing up and slide the side paper

guide against the edge of the paper stack.

4 Close the feed slot cover.

5 When Save the rear tray paper information

appears on the printer's screen, press the OK

button.

6 Select the paper size and type, and press the OK

button.

Transporting Your Printer

Photo paper can only be loaded in the rear tray.

When relocating the printer, make sure of the following. Refer to the Online Manual for details.

Check that both joint buttons are pressed down

completely to avoid ink leaks.

Check that the position of the ink valve lever is closed.

Pack the printer in a plastic bag in case ink leaks.

• Pack the printer in a sturdy box so that it is placed with its

bottom facing down, using suﬃcient protective material

to ensure safe transport.

• Do not tilt the printer. Ink may leak.

• Please handle with care and ensure the box remains ﬂat

and NOT turned upside down or on its side, as the printer

may be damaged and ink in the printer may leak.

• When a shipping agent is handling transport of the

printer, have its box marked "THIS SIDE UP" to keep the

printer with its bottom facing down. Mark also with

"FRAGILE" or "HANDLE WITH CARE".

Altri manuali per PIXMA G5000 Series

Indice

Lingue:

Altri manuali Canon Stampante

Canon

Canon PowerShot S330 Digital ELPH Manuale utente

Canon

Canon CLC5100 Series Manuale utente

Canon

Canon PowerShot S300 Digital Elph Manuale utente

Canon

Canon FAXPHONE L75 Guida di sicurezza

Canon

Canon i-SENSYS LBP151dw Manuale utente

Canon

Canon imageRUNNER ADVANCE DX C357P Manuale utente

Canon

Canon BJC-4400 Series Manuale utente

Canon

Canon ZV-223 Manuale utente

Canon

Canon PIXMA MP268 Manuale utente

Canon

Canon iP4500 - PIXMA Color Inkjet Printer Manuale utente

Canon

Canon MB5170 Manuale utente

Canon

Canon DS700 - Selphy Compact Photo Printer Manuale utente

Canon

Canon imagePROGRAF iPF825 MFP Basic Guide No.1 Manuale utente

Canon

Canon iPF720 - imagePROGRAF Color Inkjet Printer Manuale utente

Canon

Canon iR1018 Manuale utente

Canon

Canon iP90 - PIXMA Color Inkjet Printer Manuale utente

Canon

Canon DS700 - Selphy Compact Photo Printer Manuale utente

Canon

Canon Color Bubble Jet BJC-1000 Series Manuale utente

Canon

Canon PIXMA TS8300 Series Guida all'installazione

Canon

Canon Selphy CP730 Guida alla configurazione

Canon

Canon iPF8400S Series Manuale utente

Canon

Canon CX 320 Manuale utente

Canon

Canon PIXMA MX7600 Manuale utente

Canon

Canon i80 Series Manuale utente

Manuali Stampante popolari di altre marche

Lexmark

Lexmark 1400 Series Manuale

Evolis

Evolis Elypso Manuale utente

Kyocera

Kyocera FS-9530DN Manuale utente

Samsung

Samsung BIXOLON SRP-350plusF Manuale utente

Dell

Dell Color Laser Printer 2130cn Manuale utente

Tektronix

Tektronix Phaser 840 Manuale utente

Epson

Epson ET-7750 Istruzioni operative

Eltron

Eltron P210 Guide Manuale utente

Ricoh

Ricoh MD-P1 Manuale utente

Epson

Epson SC-F7100 series Manuale utente

Epson

Epson Stylus C40UX Manuale utente

IRA3D

IRA3D POETRY4 Manuale utente

Ricoh

Ricoh Aficio AP400 Manuale utente

BIXOLON

BIXOLON SRP-352plusV Manuale utente

Epson

Epson Stylus Photo PX700W Istruzioni per il montaggio

Ricoh

Ricoh SP204SF Manuale utente

Star Micronics

Star Micronics futurePRNT TSP100 Manuale utente

Epson

Epson TM-TM88V-i Manuale per l'uso e la cura
