Canon PIXMA TS300 series Manuale utente

Baca Keamanan dan Informasi Penting

(lampiran) terlebih dahulu.

Trưc tiên đc Thông tin an ton v quan trng

(ph lc).

Hưng dn bt đu





Read Safety and Important Information

(addendum) rst.

Mari Memulai



Getting Started

Lp đt My in......................................................................................... trang 1

Kt ni vi my tnh v smartphone/my tnh bng................................ trang 4

Memasang Pencetak......................................................................... halaman 1

Menghubungkan dengan Komputer dan Ponsel Pintar/Tablet .......... halaman 4

Cara Memegang Pencetak Video Penjelasan

.....................................................................................

/ ......................................  4

 

Installing the Printer................................................................................. page 1

Connecting with Computer and Smartphone/Tablet................................ page 4

How to Hold Printer Explanatory Movies

Cch gi My in Đon phim gii thch

ENGLISH

1. Unpack Box

□ Power cord □ FINE cartridge

□ Safety and Important Information

□ Getting Started (this manual)□ Setup CD-ROM for

Windows PC

2. Remove Tape and Turn on

1 Stand the printer on its back and remove the

orange tape stuck to the bottom of it. Return the

printer to its original position.

2 Remove the packing materials (such as orange

tape) from outside the printer.

3 Open the cover.

4 Remove the orange tape and the protective

material and discard them both.

5 Close the cover.

6 Connect the power cord.

Do not connect any cables except the power cord

yet.

7 Press the ON/Stop button.

The ON lamp lights.

Lit

• If the Alarm lamp (A) ashes 9 times at a time,

press the ON/Stop button to turn off the power,

and then try again from step 3 of chapter 2

"Remove Tape and Turn on".

• If the Alarm lamp (A) ashes 4 times at a time,

proceed to the next step as it is.

(A)

Flashing

3. Install Inks

1 Open the cover.

2 aTake out the Color FINE cartridge from the

package.

bRemove the protective tape.

Do not touch.

Be careful of ink on the protective tape.

3 aInsert the Color FINE cartridge into the FINE

cartridge holder on the left at a slight upward

angle.

bPush the FINE cartridge in and up rmly until it

snaps into place.

Make sure that the FINE cartridge is installed

horizontally.

Do not bump it against

the surrounding parts.

Click!

ENGLISH

4 Repeat steps 2 to 4 and install the Black FINE

cartridge as well, on the right.

5 Close the cover.

If the Alarm lamp ashes 4 times at a time, go

back to step 3 of chapter 3 "Install Inks" and check

whether the FINE cartridges for Color and Black are

installed correctly.

4. Load Paper

1 Open the paper support.

2 Slide the paper guide to the left.

3 Load plain LTR or A4 size paper against the right

edge with the print side facing up.

4 Slide the paper guide to align it with the side of the

paper stack.

5 Pull out the paper output tray and output tray

extension.

5. Preparing for Connection

From here on, the procedure differs depending on the device used to connect to the printer.

First, after checking that the Wireless lamp is ashing 2 times at a time, proceed to the following operations.

In the following description, smartphones and tablet devices are collectively described as smartphone.

When the Wireless lamp does not ash, try again

from chapter 2 "Remove Tape and Turn on".

Wireless

Flashing

• To use the printer by connecting only to a computer or both to a computer and smartphone

"6-A. Connecting to Computer"

• To use the printer by connecting only to a smartphone

"6-B. Connecting to Smartphone" on page 6

6-A. Connecting to Computer

macOS

Windows

You need a connection setup for each computer. Proceed with the setup from step 1 for each computer.

1 Start the setup le for either method or method .

aOpen a web browser ( etc.) on your computer.

bInput the following URL and access the Canon

website.

cSelect Set Up.

dInput the model name of your printer and click OK.

You can select a model name from the list.

eClick Setup.

The procedures for Windows and macOS are shown

below. If you are using a computer with an OS other

than Windows or macOS, such as a Chrome OS, do

the setup according to the on-screen instructions.

fClick Download and download the setup le.

gExecute the downloaded le.

Proceed to step on the next page to

continue.

Downloading from the Internet

ENGLISH

The connection with your computer is now complete. You can print from your

computer.

If the following screen appears, click Exit.

Follow the on-screen

instructions to proceed

with the setup.

Using Setup CD-ROM (Windows Only)

aLoad the Setup CD-ROM in your computer.

■ When using Windows 10 or Windows 8.1:

bWhen the following message appears on the right

side of your computer screen, click it.

cIf the following screen appears, click Run

Msetup4.exe.

dIf the User Account Control dialog box appears,

click Yes.

When This Message Does Not Appear (or Has

Disappeared)

1. Click File Explorer on the taskbar.

2. Click This PC on the left side of the opened window.

3. Double-click the CD-ROM icon on the right side of

the window.

If the contents of the CD-ROM appear, double-click

Msetup4.exe.

4. Proceed to step d.

■ When using Windows 7:

bWhen the AutoPlay screen appears, click Run

Msetup4.exe.

c If the User Account Control dialog box appears,

click Continue.

When AutoPlay Screen Does Not Appear

1. Click Computer from the start menu.

2. Double-click the CD-ROM icon on the right side of

the opened window.

If the contents of the CD-ROM appear, double-click

Msetup4.exe.

Proceed to step to continue.

2 Click Start Setup.

6-B. Connecting to Smartphone

Android

iOS

You need a connection setup for each smartphone. Proceed with the setup from step 1 for each smartphone.

Preparation

• Turn on Wi-Fi on your smartphone.

• If you have a wireless router, connect your smartphone to the wireless router you want to connect to the printer.

* For operations, refer to manuals of your smartphone and the wireless router or contact those manufacturers.

1 Install the application software Canon PRINT Inkjet/SELPHY in your smartphone.

: Search "Canon PRINT" in App Store.

: Search "Canon PRINT" in Google Play.

Or access the Canon website by scanning the QR code.

* You may not connect your smartphone to the Internet wirelessly during connecting the printer to the smartphone directly.

In that case, you may be charged depending on the contract with your service provider.

* Up to 5 devices can be connected to the printer via wireless LAN connection directly.

2 Check the Wireless lamp, and then proceed to or .

aTap the installed application software.

bFollow the on-screen instructions to register the

printer.

cMake sure that the following screen appears.

The connection with your smartphone is

now complete. You can print from your

smartphone.

To print photos, load photo paper. Proceed to "Loading

Photo Paper" on page 8.

If the Wireless lamp is not lit and the Network

lamp is lit, the printer cannot send transmissions

using a Wireless LAN connection. For details,

access "http://ij.start.canon" to see the

"Frequently Asked Questions".

Wireless

Network

Lit

Off or ashing (continue to )

Lit (continue to )

Wireless

ENGLISH

Procedures below vary depending on iOS or Android. Select your operating system and proceed to its

procedure.

aTap Settings on your smartphone's home screen,

and tap Canon_ij_XXXX in the Wi-Fi settings.

If Canon_ij_XXXX does not appear on the list, see

"Troubleshooting" below to operate the printer, and

then repeat step a.

bTap the installed application software.

cFollow the on-screen instructions to register the

printer.

Follow the on-screen instructions to proceed

with the setup.

If you select Auto Select Conn. Method

(recommended) on the connection method

selecting screen, the appropriate connection

method is selected automatically depending on

your environment.

dMake sure that the following screen appears.

aTap the installed application software.

bFollow the on-screen instructions to register the

printer.

If a message saying "Printer is not registered.

Perform printer setup?" does not appear, see

"Troubleshooting" below to operate the printer, and

then wait for a while until the message appears.

Follow the on-screen instructions to proceed

with the setup.

The appropriate connection method is selected

depending on your environment.

cMake sure that the following screen appears.

The connection with your smartphone is now complete. You can print from your

smartphone.

To print photos, load photo paper. Proceed to "Loading Photo Paper" on page 8.

aPress and hold the Direct button on the printer for about 2 seconds until the Direct lamp starts to ash.

Flashing

bReturn to the operation of your smartphone.

Troubleshooting

Printer is not found from your smartphone.

1 Open the paper support.

2 Slide the paper guide to the left.

3 aLoad photo paper against the right edge with

the print side facing up.

bSlide the paper guide to align it with the side

of the paper stack.

4 Conrm that the Paper lamp that is lit matches

the paper size that is loaded.

LTR/

4"×6"/10×15cm

A4/Hagaki/L

If the Paper lamp that lights does not match the

paper size, press the Paper Select button.

LTR/

4"×6"/10×15cm

A4/Hagaki/L

5 Pull out the paper output tray and output tray

extension.

Loading Photo Paper

Smartphone Copy

You can copy documents by using the Canon PRINT Inkjet/SELPHY application software for

smartphones. To install the application, refer to step 1 on page 6. For the operation procedure, refer

to the Online Manual.

1 Load the document on the

printer.

2 Take a photo of the document

by using Canon PRINT Inkjet/

SELPHY.

3 Send the image data to the

printer and print it.
