1ZoomBrowser EX Software User Guide

2ZoomBrowser EX Software User Guide

Table of Contents (1/2)

Starting ZoomBrowser EX ........................................................ 4

Downloading Images to a Computer ....................................... 8

Printing Images ....................................................................... 12

Supplementary Information ....................................................18

Creating Folders ...................................................................... 44

Selecting Images ...................................................................... 45

Moving or Copying Images .....................................................46

Deleting Images ...................................................................... 50

Rotating Images ...................................................................... 52

Renaming Images .................................................................... 53

Sorting Images ........................................................................ 54

Searching Images .................................................................... 55

Refreshing Folders ...................................................................58

Deleting Folders ...................................................................... 59

Renaming Folders .................................................................... 60

Finding Folder Locations ......................................................... 61

Viewing Image Properties .......................................................62

Chapter 1 Try It! ZoomBrowser EX

Chapter 2 What is ZoomBrowser EX?

What Can ZoomBrowser EX Do? .............................................19

Finding Images and Folders .....................................................21

Main Window ......................................................................... 23

Camera Window ..................................................................... 28

Using the Right-Click in Operations .........................................30

Selecting Folders - Folder Area ................................................ 31

Selecting Folders - Browsing Area ........................................... 32

Opening Images ...................................................................... 37

Zooming .................................................................................. 38

Editing Images ......................................................................... 39

Editing Images with Other Programs ......................................43

Chapter 3 Viewing Images

Chapter 4 Organizing Images

Opening the Camera Window ................................................64

Downloading Images .............................................................. 66

Deleting Images in the Camera ...............................................69

Rotating Images in the Camera ............................................... 70

Adding Computer Images to the Camera ................................71

Using the Task Buttons ............................................................73

Other Functions of the Camera Window .................................75

Chapter 5 Using the Camera Window

3ZoomBrowser EX Software User Guide

Table of Contents (2/2)

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

NOTE

•This manual uses Windows XP screen shots and procedures in

the explanations. The screen shots and procedures may appear

slightly different if you are using another version of Windows.

•In this manual, the term “memory card” is used for CF cards, SD

cards and PC cards.

Sending Images by E-mail ........................................................76

Adding Computer Images to the Camera ................................78

Exporting Images .................................................................... 80

Running a Slide Show ..............................................................82

Adding Sounds to Images ........................................................84

Checking and Changing Camera Settings ...............................85

Saving the “My Camera Settings” to the Camera ....................86

Creating a My Camera Sound ..................................................93

Playing Movies ........................................................................ 95

Editing Movies ......................................................................... 96

Exporting Movies .................................................................. 100

Converting RAW Images ....................................................... 102

Operating the Camera Shutter from the Computer .............. 107

Stitching Panoramic Images - PhotoStitch ............................. 111

Saving Images to CD-R/RW Disks (Windows XP Only) ............ 112

Supported File Formats ......................................................... 113

Auto-Download Settings ....................................................... 114

Customizing Preferences ....................................................... 117

Customizing Menus ............................................................... 120

Setting up Slide Shows on the Camera .................................. 121

Print Settings ......................................................................... 122

Troubleshooting .................................................................... 124

Chapter 6 Using Supplementary Features Appendices

Index ..................................................................................... 128

Index

4ZoomBrowser EX Software User Guide

Chapter 1

Try It! ZoomBrowser EX

Starting ZoomBrowser EX (1/4)

This chapter covers the ZoomBrowser EX basics, such as starting the

program, downloading images from the camera and printing them. It

begins with the procedures for starting the program.

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

IMPORTANT

•This guide assumes that all the relevant software programs and

drivers have been correctly installed on your computer. If they

have not been installed yet, read the guides that accompanied

your camera and install them before proceeding further.

Starting Methods

There are two ways to start ZoomBrowser EX: “Starting by

Connecting the Camera to the Computer” and “Starting by

Clicking an Icon or Menu.”

It is generally easier and more convenient to start it by

connecting the camera to the computer.

However, you may wish to click an icon or menu to start it

under the following circumstances.

•When you are using a memory card reader.

•When you wish to use ZoomBrowser EX without connecting a

camera.

•When you are restarting ZoomBrowser EX with the camera

still connected after the program has been closed once.

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

IMPORTANT

•With some versions of Windows, you may not be able to use

the “Starting by Connecting the Camera to the Computer”

method the very first time the camera is connected to the

computer after it is booted up (owing to a limitation of Win-

dows). In this case, start ZoomBrowser EX with the “Starting by

Clicking an Icon or Menu” method. You may use the camera

connection method from the second time onward.

5ZoomBrowser EX Software User Guide

Chapter 1

Try It! ZoomBrowser EX

Starting ZoomBrowser EX (2/4)

Starting by Connecting the Camera to the Computer

You can start ZoomBrowser EX with this method by attaching

the camera to the computer and preparing it to transfer data.

Set the following Auto Start Settings the first time (only) that

you connect the camera to a computer. If you have already set

them, proceed to the steps on the next page.

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

IMPORTANT

•This method can only be used when the camera is connected to

the computer with the interface cable.

■Settings for the First Connection to a Computer

1. Use the interface cable to connect the camera to the

computer.

Please see the manual supplied with your camera for

connection instructions.

With some models, the camera may need to be set to the

playback mode to communicate with a computer. Consult the

manual for these models to set the camera to the correct mode

for communication.

A dialog similar to the following one (Events dialog) will appear.

If it does not, read the Troubleshooting section in the

Appendices.

2. Select [Canon CameraWindow] and click [OK].

3. Click [Set].

Once you click the Set button, this dialog will no longer appear

when the camera is connected.

Your camera model name or

“Canon Camera” will appear here.

The dialog for Step 1 shown on the next page will now appear.

6ZoomBrowser EX Software User Guide

Chapter 1

Try It! ZoomBrowser EX

Starting ZoomBrowser EX (3/4)

■Procedures for Subsequent Connections to a Computer

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

IMPORTANT

•With some versions of Windows, you may not be able to use

this method of starting ZoomBrowser EX the very first time the

camera is connected to the computer after it is booted up. (The

dialog shown to the right will not display even if you connect

the camera to the computer correctly.)

In this case, start the program with the Starting by Clicking an

Icon or Menu method.

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

REFERENCE

•If the Scanners and Cameras Wizard displays, close it and use

the Starting by Clicking an Icon or Menu method to start

ZoomBrowser EX.

•Adevice selection dialog will display if you have both a camera

and a memory card reader connected at the same time. Confirm

that your camera model name or [Canon Camera] appears in

the list box and click [OK].

The procedures from this point onward are described in the

next topic, “Downloading Images to a Computer”.

Click [Browse Images with ZoomBrowser EX] if you wish to

proceed to ZoomBrowser EX’s main window and do not wish to

download images.

The explanation about which method is used to download

images after ZoomBrowser EX starts up automatically is

contained in the “Auto-Download Settings” section of the

Appendices.

1. Use the interface cable to connect the camera to the

computer.

Please see the manual supplied with your camera for

connection instructions.

With some models, the camera may need to be set to the

playback mode to communicate with a computer. Consult the

manual for these models to set the camera to the correct mode

for communication.

A dialog like the ones below will display.

7ZoomBrowser EX Software User Guide

Chapter 1

Try It! ZoomBrowser EX

Starting ZoomBrowser EX (4/4)

Starting by Clicking an Icon or Menu

Use the following methods to start ZoomBrowser EX using its

desktop icon or a menu.

■The Icon Method

1. Double-click the [ZoomBrowser EX] icon on the desktop.

ZoomBrowser EX will start and open its main window.

The procedures for downloading images are described in the

next topic, “Downloading Images to a Computer.”

■The Menu Method

1. Click the [Start] menu and select [All Programs] or

[Programs], followed by [Canon Utilities],

[ZoomBrowser EX] and [ZoomBrowser EX].

ZoomBrowser EX will start and open its main window.

Main Window

The procedures for downloading images are described in the

next topic, “Downloading Images to a Computer.”

Main Window

8ZoomBrowser EX Software User Guide

Chapter 1

Try It! ZoomBrowser EX

Downloading Images to a Computer (1/4)

This section describes two methods for downloading images shot with

a camera to a computer.

■Downloading Images with Computer Commands

This method uses commands entered on the computer to

download images from a memory card in a camera or in a

memory card reader. This method can be used regardless of

whether your camera supports the direct transfer function or not.

■Downloading Images with Camera Commands

You can use this method to download images with cameras

that support the direct transfer function.

Check to ensure that the computer and the camera or memory

card reader are in the correct state for communication.

Using Computer Commands to Download Images

1. Read the dialog that displays.

If a dialog similar to the one below appears, proceed to Step 4.

Proceed to Step 2 if ZoomBrowser EX’s main window displays.

2. Click [Camera & Memory Card].

If you are using a memory card reader, check to ensure that the

card is correctly inserted in the reader.

3. Click [Browse & Download Images].

*The dialog will vary

slightly according to

your camera model.

9ZoomBrowser EX Software User Guide

Chapter 1

Try It! ZoomBrowser EX

Downloading Images to a Computer (2/4)

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

REFERENCE

•Adialog will appear if multiple memory card readers are con-

nected and loaded with memory cards, or if a camera and a

memory card are connected concurrently, to allow you to select

which images are shown from which device. In that case, select

the desired device from the list box and click [OK].

4. Click [Start Image Download].

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

REFERENCE

•You can view information such as the destination folder for

images by clicking [Show Current Settings] in the window.

•By the default setting, the program downloads all the images

that have not yet been downloaded.

The images will begin to download. The downloaded images

will be saved into folders according to their creation dates.

When the download is complete, the downloaded images will

appear in the main window.

Downloaded images

10 ZoomBrowser EX Software User Guide

Chapter 1

Try It! ZoomBrowser EX

Downloading Images to a Computer (3/4)

Using Camera Commands to Download Images

You can download images using camera commands if your

camera supports the direct transfer function (camera has a

Print/Share button ).

1. Read the dialog that displays.

If a dialog similar to the one below appears, proceed to Step 2.

The Print/Share button will light up at this point and a direct

transfer menu like the one shown at the lower right will appear

in the camera’s LCD monitor.

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

IMPORTANT

•The camera’s Print/Share button cannot be used to download

images if it is not lighted.

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

REFERENCE

•The dialog in step 1 will not display if the Camera Window or

RemoteCapture Task window is open. Please close these win-

dows.

•Adialog will appear if a camera and a memory card reader are

connected concurrently to allow you to select the device from

which images are shown. Select the desired device from the list

box and click [OK].

Altri manuali per DIGITAL IXUS vEOS D30

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Canon Software

Canon

Canon PowerShot SD430 DIGITAL ELPH WIRELESS Istruzioni per il montaggio

Canon

Canon Powershot S2 IS - Powershot S2 IS 5MP Digital... Manuale utente

Canon

Canon PowerShot SD430 DIGITAL ELPH WIRELESS Guida di sicurezza

Canon

Canon PowerShot SD100 Istruzioni per il montaggio

Canon

Canon ScanGear CS-S 4.3 Manuale utente

Canon

Canon 2675B001 - SELPHY ES3 Photo Printer Guida di sicurezza

Canon

Canon 3508B001 - PowerShot D10 Digital Camera Guida di sicurezza

Canon

Canon CanoScan FB 1200S Manuale utente

Canon

Canon EOS-1D Mark II Digial Manuale utente

Canon

Canon 2055B001 - DC 50 Camcorder Manuale utente

Canon

Canon Vixia HG21 Manuale utente

Canon

Canon PowerShot A40 Istruzioni per il montaggio

Canon

Canon DR-5060F Manuale utente

Canon

Canon DV Network Manuale utente

Canon

Canon UFR II Driver Manuale di installazione e funzionamento

Canon

Canon PowerShot SD10 Digital ELPH Istruzioni per il montaggio

Canon

Canon Networked Multi-Projection Guida all'installazione

Canon

Canon EOS 10D Digital Manuale utente

Canon

Canon 9320A010 - EOS Rebel XSi Starter Manuale utente

Canon

Canon HV10 - Camcorder - 1080i Manuale utente

Canon

Canon BJC-S330 Guida utente

Canon

Canon EOS 30D - 8.2MP Digital SLR Camera Manuale utente

Canon

Canon EOS 20Da Manuale utente

Canon

Canon 3211B001 - PowerShot E1 Digital Camera Istruzioni per il montaggio

Manuali Software popolari di altre marche

COMPRO

COMPRO COMPROFM Manuale utente

Muratec

Muratec OFFICEBRIDGE ONLINE Manuale utente

Oracle

Oracle Contact Center Anywhere 8.1 Manuale utente

Adobe

Adobe 65007312 - Photoshop Lightroom Manuale

Avaya

Avaya NULL One-X for RIM Blackberry Manuale utente

HP ProLiant BL420c Manuale utente

PS Audio

PS Audio PowerPlay Manuale del proprietario

Brady

Brady LOCKOUT PRO 3.0 Manuale di servizio

Avaya

Avaya Interaction Center Manuale utente

Texas Instruments

Texas Instruments TI-83 Plus Silver Edition Manuale

Novell

Novell GROUPWISE 8 - INTERNET AGENT Manuale utente

Oracle

Oracle Application 9i Manuale utente

Acer

Acer RDM Manuale utente

Samsung

Samsung Auto Backup Manuale utente

Polycom

Polycom Vortex EF2201 Istruzioni per l'installazione e il funzionamento

Brocade Communications Systems

Brocade Communications Systems Brocade 8/12c Manuale utente

Novell

Novell SP2 - S Manuale di istruzioni

Lexmark

Lexmark Apps Manuale di servizio
