Backup Utility

You can use Backup Utility to easily back up onto a computer all the video data on your

camcorder's hard disk or to transfer backed up data back to the camcorder. Making

regular backups allows you to protect your important recordings in case of damage to the

camcorder's hard disk, which may also lead to permanent data loss.

Back Up Data

Back up onto a computer all the video data on your camcorder's hard disk.

Transfer Back Data

Transfer back to the camcorder video data that has already been backed up in order

to play back the recordings. Make sure to initialize the camcorder's hard disk before

transferring data back.

System Requirements

The following table gives the recommended system configuration for the software.

The software may not work correctly depending on the specifications and settings

of your computer and other software already installed.

IMPORTANT

When the camcorder's hard disk contains a large amount of video data, the time required

to back up or transfer back data may be over 30 minutes for each procedure.

Recommended System Configuration for Backup Utility

* Only computers with a preinstalled version of the OS indicated.

Operating System Microsoft Windows XP SP2 Microsoft Windows Vista

(32-bit version only)

CPU Intel Pentium 4, 1.6 GHz Intel Pentium 4, 2.4 GHz

RAM 512 MB 1 GB

Available Hard Disk

Space

Same hard disk space as the amount of data to be backed up

Interface USB 2.0 (Hi-Speed USB)*

Preparing to Use the Software

Turn on the computer and start

Windows. Before you use this

software, copy Backup Utility and

instruction manual to your computer.

1Insert the Backup Utility CD-ROM

into the computer's CD or DVD

drive.

2From Computer (in Windows

Vista) or My Computer (in

Windows XP), double-click the

icon of the drive in which you

inserted the disc.

3Double-click [English].

4Copy the folder [HGBACKUP] to

your computer's desktop.

Connecting the Camcorder to the

Computer

Connect the camcorder to the

computer to back up your video data

or to transfer it back to the camcorder.

1Connect the camcorder to a

power outlet.

Insert a fully charged battery pack

and power the camcorder using the

compact power adapter.

2Turn on the camcorder and set it

in video playback mode.

Refer to the camcorder's instruction

manual.

3Connect the camcorder to the

computer using the USB cable.

IMPORTANT

Do not disconnect the camcorder's

power source or USB cable while using

this software. Doing so may result in

damage to the camcorder's hard disk

and/or permanent data loss. Insert a fully

charged battery pack into the camcorder

in advance and use the compact power

adapter. Do not allow the USB cable to be

inadvertently disconnected. Before

disconnecting the USB cable, use the

"Safely Remove Hardware" icon in the

System Tray to end the connection.

Starting Backup Utility

The first time you use this software,

make sure to read the license

agreement.

1Open the desktop folder

[HGBACKUP].

2Double-click the icon

[HGBACKUP.exe].

If this is the first time you are using

this software, the license agreement

will appear. Continue to step 3. If

you have already agreed to the

license agreement, the main menu

will appear. Skip directly to the

section corresponding to the

desired function in the main menu.

3Read the license agreement and

select [I agree].

The main menu will appear.

Backing Up the Camcorder's Video

Data

Back up onto the computer all of the

movies on the camcorder's built-in

hard disk. We recommend backing up

your movies regularly.

1Start Backup Utility and click

[Back Up Data].

2Select the folder where you want

to back up the data and click

[Start].

Backup will start. A folder is created

whose name reflects the date and

time (in 24-hour format) of the

backup. For example, the folder

name of a backup made around

9 p.m. on October 25 will be:

20071025212030

YYYYMMDDhhmmss

• The required space and available

space are displayed. If there is not

enough available space, [Start] will

be grayed out.

3Once backup is completed, click

[OK].

If movies that do not play back

correctly on the camcorder are backed

up, DVD MovieFactory SE may be able

to read them. If the movies can be

read, you can use DVD MovieFactory

SE to create a high-definition AVCHD

disc or standard definition DVD disc.

1 Start Backup Utility and click

[Back Up Data].

2 Click [Yes] and back up the

camcorder's video data.

3 Start DVD MovieFactory SE.

4 From the Start menu, select

[All Programs] and then [Corel

Applications], and click [Ulead

DVD MovieFactory 5.6 Launcher].

5 Click [Video Disc] and then

[New Project].

BACKING UP MOVIES THAT DO NOT PLAY

BACK CORRECTLY

6 Select the disc type and click

[OK].

7 Click the icon.

8 Select the folder you backed up

the movies to in step 2.

9 Select the files to add to the disc

and click [Open].

• You can preview files by selecting

a file and clicking [Preview].

• You can select multiple files by

pressing and holding the Shift key

or Ctrl key while making

selections.

10 Follow the instructions in the

Corel Application Disc Installation

Guide and User Manual.

Refer to step 10 and subsequent

steps of Creating an AVCHD Disc or

a DVD-Video Disc in the Corel

Application Disc Installation Guide

and User Manual.

Transferring Video Data Back to the

Camcorder

After you have backed up onto the

computer all of the movies on the

camcorder's hard disk, you can

transfer those movies back to the

camcorder. After doing so, the movies

in the camcorder will be the same as

when they were backed up.

1Initialize the camcorder's hard

disk.

Refer to Initializing the Hard Disk in

the camcorder's instruction manual.

2Connect the camcorder to the

computer.

Refer to Connecting the Camcorder

to the Computer (3).

3Start Backup Utility and click

[Transfer Back Data].

4Click [Yes].

5Select the folder that contains the

backup data to transfer back and

click [Start].

Data transfer will start.

6Once transfer is finished, click

[OK].

You can connect the camcorder to a

TV to play back your recordings.

Make sure to initialize the

camcorder's hard disk before

making additional recordings.

CANON INC.

U.S.A.–––––––––––– Canon U.S.A., Inc.

Canon Customer Care Center

Tel (US): 1-800-828-4040

(Mon.-Fri., 9 AM to 8 PM Eastern Time)

CANADA –––––––––– Canon CANADA Inc.

Tel (Canada): 1-800-OK-CANON (1-800-652-2666)

ASIA –––––––––––––– Canon Hongkong Co., Ltd.

19/F., The Metropolis Tower, 10 Metropolis Drive,

Hunghom, Kowloon, Hong Kong

Phone: 852-2170-2828

Fax: 852-2723-9684

Trademark Acknowledgements

• Corel, the Corel logo, Ulead, the Ulead logo, Ulead DVD MovieFactory, InterVideo, the InterVideo logo, WinDVD are trademarks or

registered trademarks of Corel Corporation and its subsidiaries.

• Microsoft, Windows and Windows Vista are trademarks or registered trademarks of Microsoft Corporation in the United States

and/or other countries.

• “AVCHD” and the “AVCHD” logo are trademarks of Matsushita Electric Industrial Co., Ltd. and Sony Corporation.

• Other names and products not mentioned above may be trademarks or registered trademarks of their respective companies.

The information in this manual is verified as of 1 August 2007.

DIE-292 © CANON INC. 2007
