FILE MANAGEMENT

The file management capabilities of the camera make it

easy to keep track of images. You can protect files against

deletion, and even use its DPOF feature to specify images

for printing.

Folders

Your camera automatically creates a directory of image

storage folders in its built-in Flash memory or on the

memory card.

Memory Folders and Files

An image you record is automatically stored in a folder,

whose name is a serial number. You can have up to 900

folders in memory at the same time. Folder names are

generated as shown below.

Example: Name of the 100th folder.

Each folder can hold files numbered up to 9,999.

Trying to store the 10,000th file in a folder causes the next

serially numbered folder to be created. Folder names are

generated as shown below.

Example: Name of the 26th file

Extension


Serial number (4 digits)

•The actual number of files you will be able to store on a

memory card depends on the image quality settings,

capacity of the card, etc.

•For details about the directory structure, see “Memory

Directory Structure”on page 137.

100CASIO

Serial number (3 digits)

FILE MANAGEMENT

Use [] and [] to

select “On”, and then

press [SET].

•A file that is protected is

indicated by the

mark.

•To unprotect a file, select

“Off”in step 4, and then

press [SET].

Press [MENU] to exit the menu screen.

Protecting Files

Once you protect a file it cannot be deleted (page 93). You

can protect files individually or you can protect all files in

memory with a single operation.

To protect a single file

In the PLAY mode, press [MENU].

Select the “PLAY”tab,

select “Protect”, and

then press [].

Use [] and [] to scroll through files and

display the one you want to protect.

FILE MANAGEMENT

To protect all files in memory

In the PLAY mode, press [MENU].

Select the “PLAY”tab, select “Protect”, and

then press [].

Use [] and [] to select “All Files : On”, and

then press [SET].

•To unprotect all files, press [SET] in step 3 so the

setting shows “All Files : Off”.

Press [MENU] to exit the menu screen.

DPOF

The letters “DPOF”stand for “Digital Print

Order Format”, which is a format for

recording on a memory card or other medium

which digital camera images should be

printed and how many copies of the image

should be printed. Then you can print on a

DPOF-compatible printer or at a professional

print service in accordance with the file name

and number of copies settings recorded on

the card.

With this camera, you should always select images by

viewing them on the monitor screen. Do not specify images

by file name without viewing the file contents.

■DPOF Settings

File Name,

number of copies,

date

FILE MANAGEMENT

Use [] and [] to specify the number of

copies.

•You can specify up to 99 for the number of copies.

Specify 00 if you do not want to have the image

printed.

To turn on date stamping for the prints, press

[DISP] so

is displayed.

•To turn off date stamping for the prints, press [DISP]

is not displayed.

•Repeat steps 4 through 6 if you want to configure

other images for printing.

After all the settings are the way you want,

press [SET] to apply them.

To configure print settings for a single


In the PLAY mode, press [MENU].

Select the “PLAY”tab,

select “DPOF”, and

then press [].

Use [] and [] to select “Select images”,

and then press [].

Use [] and [] to

display the image you

want.

FILE MANAGEMENT

To configure print settings for all images

In the PLAY mode, press [MENU].

Select the “PLAY”tab, select “DPOF”, and

then press [].

Use [] and [] to select “All images”, and

then press [].

Use [] and [] to

specify the number of

copies.

•You can specify up to 99

for the number of copies.

Specify 00 if you do not

want to have the image

printed.

To turn on date stamping for the prints, press

[DISP] so

is displayed.

•To turn off date stamping for the prints, press [DISP]

is not displayed.

After all the settings are the way you want,

press [SET] to apply them.

FILE MANAGEMENT

100

Exif Print

Exif Print is an

internationally supported,

open standard file format

that makes it possible to

capture and display vibrant

digital images with accurate

colors. With Exif 2.2, files

include a wide range of

shooting condition

information that can be

interpreted by an Exif Print

printer to produce better-

looking prints.

IMPORTANT!

•Information about the availability of Exif Print

compatible printer models can be obtained from each

printer manufacturer.

PRINT Image Matching II

Images include PRINT Image Matching

II data (mode setting and other camera

setup information). A printer that

supports PRINT Image Matching II

reads this data and adjusts the printed

image accordingly, so your images

come out just the way you intended

when you recorded them.

*Seiko Epson Corporation holds the

PRINT Image Matching II.

FILE MANAGEMENT

101

Use the DPOF procedure on page 101 to

specify the images in file memory that you

want to print.

Use the USB cable that comes with the

camera to connect the USB cradle to a printer.

USB

DISP

•Also, connect the AC adaptor to the USB cradle and

plug the AC adaptor into an electrical outlet.

Set the camera on the USB cradle.

Turn on the printer.

Load paper for printing the images into the

printer.

Using USB DIRECT-PRINT

Your camera supports USB

DIRECT-PRINT, which was

developed by Seiko Epson

Corporation. When connected

directly to a printer that supports

USB DIRECT-PRINT, you can

select images to be printed and

start the print operation directly

from the camera.

DPOF settings (page 97) are used

to determine which images and how

many copies should be printed.

FILE MANAGEMENT

102

Press the USB cradle

[USB] button.

•This displays the print

menu on the camera’s

monitor screen.

On the camera’s monitor screen, use [] and

[] to select “Print”, and then press [SET].

•This automatically starts printing of the images you

specified with the DPOF procedure.

•If you want to print the same batch of images again,

press the [USB] button on the USB cradle.

•A message appears on the monitor screen, followed

by the DPOF setting screen (page 98), if there are no

DPOF settings currently configured on the camera to

control the printing operation. If this happens,

configure the required DPOF settings and then

perform step 6 of the above procedure again.

•If you want to change the current DPOF settings,

select “DPOF”on the print menu to display the

DPOF setting screen (page 98).

After printing is complete, turn off the camera

and remove it from the USB cradle.

IMPORTANT!

•See the documentation that comes with your printer

for information about print quality and paper settings.

•Contact your printer manufacturer for information

about models that support USB DIRECT-PRINT,

upgrades, etc.

•Never disconnect the USB cable, or perform any

camera or USB cradle operation while printing is in

progress. Doing so causes a printer error.

•To interrupt an ongoing print operation, perform the

required operation on the printer.

•The camera’s monitor screen will go blank after

printing starts. A blank monitor screen does not

necessarily mean that printing is complete. Check

the status of your printer to find out if printing is

complete.

FILE MANAGEMENT

103

Using the FAVORITE Folder

You can copy scenery shots, photos of your family, or other

special images from a file storage folder (page 137) to the

FAVORITE folder in built-in memory (page 137). Images in

the FAVORITE folder are not displayed during normal

playback, so it helps to keep your personal image private

as you carry them around. FAVORITE folder images are

not deleted when you change memory cards, so you can

always keep them on hand.

To copy a file to the FAVORITE folder

In the PLAY mode, press [MENU].

Select the “PLAY”tab,

select “Favorites”, and

then press [].

Use [] and [] to

select “Save”, and

then press [SET].

•This displays the names

of the files in built-in

memory or on the loaded

memory card.

Use [] and [] to select the file you want to

copy to the FAVORITE folder.

Use [] and [] to select “Save”, and then

press [SET].

•This copies the displayed file to the FAVORITE

folder.

After copying all of the files you want, use []

and [] to select “Cancel”, and then press

[SET] to exit.

FILE MANAGEMENT

104

NOTES

•Copying an image file with the above procedure

creates a 320 x 240-pixel QVGA-size image in the

FAVORITE folder.

•A file copied into the FAVORITE folder is

automatically assigned a file name that is a serial

number. Though the serial number starts from 0001

and can go as high as 9999, the actual upper end of

the range depends on built-in memory capacity.

Remember that the maximum number of images that

can be stored in built-in memory depends on the size

of each image and other factors.

To display a file in the FAVORITE folder

In the PLAY mode, press [MENU].

Select the “PLAY”tab, select “Favorites”, and

then press [].

Use [] and [] to select “Show”, and then

press [SET].

•If the FAVORITE folder is empty, the message “No

Favorites file!”appears.

Use [] (forward) and

[] (back) to scroll

through the files in the

FAVORITE folder.

After you are finished viewing files, press

[MENU] twice to exit.

File Name

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Casio Macchina fotografica digitale

Casio

Casio Exilim EX-FH100 Manuale utente

Casio

Casio Exilim EX-H60 Manuale utente

Casio

Casio EXILIM EX-H35 Manuale utente

Casio

Casio EXILIM Exilim EX Z 100 Manuale utente

Casio

Casio QV-200B Guida alla risoluzione dei problemi

Casio

Casio EX-S7 - EXILIM Digital Camera Manuale utente

Casio

Casio EX-S3 - Exilim 3MP Digital Camera Manuale utente

Casio

Casio KX-787 Guida alla risoluzione dei problemi

Casio

Casio QV-5500SX Guida alla risoluzione dei problemi

Casio

Casio Exilim EX-ZS15 Manuale utente

Casio

Casio QV-3000Ir Manuale utente

Casio

Casio EX-Z2200 - EXILIM Digital Camera Manuale utente

Casio

Casio EX-M1 - EXILIM Digital Camera Manuale di istruzioni

Casio

Casio EX-Z650 - EXILIM Digital Camera Manuale utente

Casio

Casio Exilim EX-Z110 Manuale utente

Casio

Casio Exilim EX-FR10CT Guida all'installazione

Casio

Casio EX-S2 - Exilim 2MP Digital Camera Manuale utente

Casio

Casio Exilim EX-FR100 Manuale utente

Casio

Casio EX-FR10 Manuale utente

Casio

Casio EX-Z22 - EXILIM Digital Camera Manuale utente

Casio

Casio EXS20 A EX-M20 Manuale utente

Casio

Casio Exilim EX-FC400S Manuale utente

Casio

Casio QV-R3 Manuale elenco delle parti

Casio

Casio QV-2400UX Manuale utente

Manuali Macchina fotografica digitale popolari di altre marche

Mercury

Mercury 350K Manuale utente

Pentax

Pentax Optio LS 465 Manuale utente

Sanyo

Sanyo VPC-S1085 Manuale utente

GE SMART A1255 Manuale utente

Point Grey

Point Grey Gazelle Manuale utente

Nikon

Nikon COOLPIX A Manuale utente

Pentax

Pentax P-5 Manuale utente

BlazeVideo

BlazeVideo A280 Manuale utente

Sony

Sony MCA-20 Manuale utente

Sony

Sony Alpha DSLR-A290 Manuale utente

ATIK Cameras

ATIK Cameras One Manuale utente

CohuHD Costar

CohuHD Costar 3930 Series Manuale utente

Leica

Leica M10-R Manuale utente

FujiFilm

FujiFilm FinePix A700 Manuale utente

Lorex

Lorex LNZ81P25 Series Manuale utente

GE J1470S Manuale utente

Sony

Sony A6700 Guida utente

Canon

Canon EOS ELAN7 Manuale utente
