Champion DH-1000 Manuale utente

SPECIFIER STATEMENT

Specified unit will be Champion model DH-1000 high

temperature door-type dishwashing machine.

Constructed of Type 304 stainless steel. Features 1 Hp TEFC

pump motor, top mounted controls, balanced door lift

system, common utility connections and interchangeable

upper and lower spray arms.

(1M) 4/08 Printed in U.S.A.

CH080

Door-type

High Temperature

Dishwashing Machine

DH1000

DH1000 DOORTYPE

STANDARD FEATURES

• Straight-throughorcornerapplication–simple

conversion in a matter of minutes

• Partscompatibilitywithothermachines

• Superiorwashresults–uniquesumpdesignandthe

verticalmount,self-drainingpumpprovidesquick

wash water flow and an ample 55-second wash time

thatproducessparklingcleanwares.

• Directreplacement–theDH-1000isadirect

replacement for most competitor’s models

without table modification.

• Machinefullyassembled,readytoinstall

• 1Hppump,TEFCmotor,verticallymounted,

self-draining

• Doorsafetyswitch

• Interchangeableupperandlowersprayarms

• Airgapdesignfeatureeliminatesvacuumbreaker

• Built-in40°Frisestainlesssteelelectricbooster

• RinseSentry–extendsthecycletimetoensure

180°Ffinalrinse

• Commonutilityconnections

• Pumpedrinseensuresconsistentrinseresults

ChampionIndustries,Inc.

P.O.Box4149,Winston-Salem,NC27115

Tel:336/661-1556Fax:336/661-1979

www.championindustries.com

Project

ItemNo.

Quantity

OPTIONS & ACCESSORIES

70°Fbuilt-inrisestainlesssteelelectricbooster

Detergent pump and rinse pump

20”x20”PegRack(notincluded)

20”x20”FlatBottomRack(notincluded)

E N E R G Y S T A R

PA R T N E R

WASH PUMP 1HP Front View

5" [127]

15-3/8" [390]

8-5/8" [220]

3" [76]

5-3/4" [145]

11-5/8" [295]

4" [101] MINIMUM CLEARANCE

FRONT

20-1/4"[514]

INSIDE TRACKS

67"[1702]

HEIGHT LOAD

HEIGHT

MACH.

DOORS

34"[864]

CLEARANCE

75"[1905]

17"[432]

REMOVAL

84"[2134]

DOOR

9-1/2" [241]

Side View

58-1/2"[1485]

60-1/2" [1536]

25-1/4" [642]

25-7/8" [657]

Plan View

2-7/8"

[73]

1-1/8"

2-1/8"

7-1/4"

1-1/4" ROLL

20-7/8"

24-1/4"

Plan View

Side View Front View

Typical Table Construction

Door-type

High Temperature

Dishwashing Machine

DH1000

DH1000 DOORTYPE

Due to an ongoing value analysis program at Champion, specifications contained in this catalog are subject to change without notice.

‘USGBC’andrelatedlogoisatrademarkownedbytheU.S.GreenBuildingCouncilandisusedbypermission.

ChampionIndustries,Inc.,P.O.Box4149,Winston-Salem,NC27115•336/661-1556•Fax:336/661-1979•www.championindustries.com

Dimensions shown in inches

Warning: Plumbing and electrical connection

shouldbemadebyqualifiedpersonnelwhowill

observe all the applicable plumbing, sanitary and

safetycodesandtheNationalElectricalCode.

Plumbing Notes:Becauseofthevariationin

house-supplied water, a pressure regulating valve

(PRV)forincomingwatersupplyisneeded.The

PRVcanbepurchasedfromChampionorobtained

locally.Itisalsorecommendedthatapressure

gauge 0-60 psi (supplied by others) be installed in

the water supply line as close to the dishwasher

as possible.

Note: WaterHammerArrestor(meeting

ASSE-1010standardorequivalent)tobe

supplied (by others) in common water supply

line at service connection.

Volumecrated: 45 cu. ft.

Shipping weight crated: 242 lbs.

Distance between tables: 25-3/8”

Utilities

1 Electrical (seebox)

2 Hot Water

3/4”NPT140°Fhotwaterconnection

(40°Frisebooster);3/4”NPT110°Fhotwater

connection;(70°Frisebooster)

Flowpressure20±5psi

3 Drain

1-7/8”connection.

SPECIFICATIONS

Capacities

 Racksperhr. 37

Motor horsepower

 Wash 1Hp

Water consumption

 U.S.Gal.perrack 1.7

Temperatures °F

 Wash 150

 Rinse 180

Time Cycle in Seconds

 Wash 55

 Drain/Fill/Dwell 12

 Rinse 23

 Totalcycle 90

Straight Through

Corner Configuration

DH1000 Electrical (40°F Rise) 9 kW

Minimum Maximum

Supply Ckt. Overcurrent

Elec. Rated Conductor Protective

Specs. Amps Ampacity Device

208/60/1 47 60 60

230/60/1 50 60 60

208/60/3 25 35 35

230/60/3 27 35 35

DH1000 Electrical (70°F Rise) 12 kW

Minimum Maximum

Supply Ckt. Overcurrent

Elec. Rated Conductor Protective

Specs. Amps Ampacity Device

208/60/3 38 50 50

230/60/3 41 50 50
