Chevrolet Corvette Navigation System (Includes Mex) - 2012

2012 Chevrolet Corvette Navigation System M

Infotainment System . . . . . . 3

Introduction ................. 3

Overview . . . . . . . . . . . . . . . . . . . . . . . 4

Radio ....................... 13

AM-FM Radio . . . . . . . . . . . . . . . . . 13

Satellite Radio . . . . . . . . . . . . . . . . 22

Audio Players ............. 23

CD Player . . . . . . . . . . . . . . . . . . . . . 23

Auxiliary Devices . . . . . . . . . . . . . . 33

Navigation ................. 34

Using the Navigation

System . . . . . . . . . . . . . . . . . . . . . . 34

Enter Destination . . . . . . . . . . . . . 36

Stored Locations . . . . . . . . . . . . . . 51

Navigation Set Up . . . . . . . . . . . . . 61

Route Options . . . . . . . . . . . . . . . . 67

Maps . . . . . . . . . . . . . . . . . . . . . . . . . . 73

Navigation Symbols . . . . . . . . . . . 76

Navigation Menu . . . . . . . . . . . . . . 81

Global Positioning

System (GPS) . . . . . . . . . . . . . . . 81

Vehicle Positioning . . . . . . . . . . . . 82

Problems with Route

Guidance . . . . . . . . . . . . . . . . . . . . 83

If the System Needs

Service . . . . . . . . . . . . . . . . . . . . . . 83

Ordering Map DVDs . . . . . . . . . . 83

Database Coverage

Explanations . . . . . . . . . . . . . . . . . 84

Voice Recognition . . . . . . . . 84

Index ..................... i-1

Black plate (2,1)

Chevrolet Corvette Navigation System (Includes Mex) - 2012

Black plate (3,1)

Chevrolet Corvette Navigation System (Includes Mex) - 2012

Infotainment System 3

Introduction

The names, logos, emblems,

slogans, vehicle model names,

and vehicle body designs

appearing in this manual

including, but not limited to

GM, the GM logo, CHEVROLET,

the CHEVROLET Emblem,

CORVETTE, the CORVETTE

Emblem, CORVETTE, CORVETTE

GRAND SPORT, ZO6, and ZR1

are registered trademarks and/or

service marks of General Motors

LLC, its subsidiaries, affiliates,

or licensors.

Manufactured under license

under U.S. Patent #'s: 5,451,942;

5,956,674; 5,974,380; 5,978,762;

6,487,535 and other U.S. and

worldwide patents issued and

pending. DTS and the Symbol

are registered trademarks and

DTS Digital Surround and the

DTS logos are trademarks of

Manufactured under license from

Dolby Laboratories. Dolby and the

double-D symbol are trademarks of

Dolby Laboratories.

“Made for iPod”means that an

electronic accessory has been

designed to connect specifically

to iPod and has been certified

by the developer to meet Apple

performance standards.

Litho in U.S.A.

Black plate (4,1)

Chevrolet Corvette Navigation System (Includes Mex) - 2012

4 Infotainment System

iPod is a trademark of Apple

Computer, Inc., registered in the

U.S. and other countries.

The information in this manual

supplements the owner manual.

This manual describes features that

may or may not be on your specific

vehicle either because they are

options that you did not purchase

or due to changes subsequent to

the printing of this owner manual.

Please refer to the purchase

documentation relating to your

specific vehicle to confirm each

of the features found on your

vehicle. For vehicles first sold

in Canada, substitute the name

“General Motors of Canada Limited”

for Chevrolet Motor Division

wherever it appears in this manual.

Keep this manual with the owner

manual in the vehicle for quick

reference.

Canadian Vehicle Owners

Propriétaires Canadiens

A French language copy of this

manual can be obtained from your

dealer or from:

On peut obtenir un exemplaire de

ce guide en français auprès du

concessionnaire ou à l'adresse

Helm, Incorporated

P.O. Box 07130

Detroit, MI 48207

1-800-551-4123

Numéro de poste 6438 de langue

française

www.helminc.com

Overview

Read this manual thoroughly to

become familiar with how the

navigation system operates.

The navigation system includes

navigation and audio functions.

Keeping your eyes on the road

and your mind on the drive

is important for safe driving.

The navigation system has built-in

features intended to help with this

by disabling some features when

driving. A grayed-out function is

not available when the vehicle is

moving.

Black plate (5,1)

Chevrolet Corvette Navigation System (Includes Mex) - 2012

Infotainment System 5

All functions are available when the

vehicle is parked. Do the following

before driving:

.Become familiar with the

navigation system operation,

buttons on the faceplate, and

touch-sensitive screen buttons.

.Set up the audio by presetting

favorite stations, setting the

tone, and adjusting the

speakers.

.Set up the navigation features,

such as entering an address or

a preset destination.

.Set up phone numbers in

advance so they can be

called easily by pressing a

single button or a single voice

command for navigation systems

equipped with phone capability.

{WARNING

Taking your eyes off the road too

long or too often while using the

navigation system could cause

a crash and you or others could

be injured or killed. Focus your

attention on driving and limit

glances at the moving map on

the navigation screen. Use voice

guidance whenever possible.

Use the navigation system to:

.Plan a route.

.Select a destination using

various methods and choices.

.Follow turn-by-turn route

and map guidance with voice

prompts, only if permitted

by traffic laws, controls,

and conditions.

.Receive RDS broadcast

announcements.

Always be alert and obey traffic

and roadway laws and instructions,

regardless of the guidance from

the navigation system. Because

the navigation system uses street

map information that does not

include all traffic restrictions or

the latest road changes, it may

suggest using a road that is now

closed for construction or a turn

that is prohibited by signs at the

intersection. Always evaluate

whether following the system's

directions is safe and legal for

the current conditions.

When the navigation system is

turned on, a screen may appear

with information that must be read

and acknowledged before accessing

some navigation features.

Black plate (6,1)

Chevrolet Corvette Navigation System (Includes Mex) - 2012

6 Infotainment System

After acknowledging the start up

information, the NAV (Navigation)

and DEST (Destination) functions

are accessible. Information

can now be entered or deleted,

and other functions accessed.

See instructions later in this section.

Every 50 times the vehicle is

started and the navigation system

is turned on, the Caution screen

appears. After reading the caution,

select Agree to load the map

DVD information. If Agree is not

selected, all control buttons except

for NAV (Navigation) and DEST

(Destination) can be accessed.

You can also press NAV to have

this Caution screen appear.

When getting started, set your

preferences or delete information in

the navigation system using various

options.

A. NAV (Navigation) Key

B. SRCE (Source) Key

C. g(Voice Recognition)

D. XDVD (DVD Map Database

Eject)

E. XB(CD Eject)

F. CD Slot

G. DVD Map Database Slot

H. Power/Volume Knob

I. rOSEEK q(Seek/Tune)

J. e/z(Audio/Adjust) Key

K. X(Open/Close Faceplate)

L. Navigation System Screen

Black plate (7,1)

Chevrolet Corvette Navigation System (Includes Mex) - 2012

Infotainment System 7

Language

To change the language of the

prompts that appear on the

navigation screens, see “Driver

Information Center (DIC)”in the

Index of the vehicle's owner manual.

Deleting Personal Information

This navigation system can record

and store destinations. You may

want to delete stored destinations

when the vehicle is sold or the lease

has expired. Refer to the following

sections to delete the destination

information that has been stored.

See “Memory Points,” “Home,”

“Previous Destination,”and “Preset

Destination”under Stored Locations

on page 51 for deleting stored

destinations.

Storing Radio Station Presets

To set preset radio stations:

1. Press the power/volume knob to

turn the system on.

2. Press SRCE and select the

desired band (AM, FM1, FM2,

XM1, or XM2 (if equipped)).

3. Use rOSEEK qto tune to

the desired station.

4. Press and hold one of the

six preset screen buttons,

at the bottom of the screen,

until a beep is heard or the

station is displayed on the

selected preset button.

5. Repeat the steps for each

preset.

See “Preset Station Menu”under

AM-FM Radio on page 13 for more

information.

Setting the Clock

To set the time:

1. Press the power/volume knob to

turn the system on.

2. Press and hold the time display

in the upper right corner of any

screen.

3. Select the 12H or 24H screen

button to display the time in

standard or military time.

4. Press and hold the Hour and

Min. (minute) arrow buttons to

increase or to decrease the time.

5. Select the correct time zone

screen button.

6. Select the Daylight Saving Time

screen button, if necessary.

The radio uses the GPS satellite to

set the time. The vehicle needs to

be in an open area to receive the

signal. See “Clock”under AM-FM

Radio on page 13 for more

information.

Black plate (8,1)

Chevrolet Corvette Navigation System (Includes Mex) - 2012

8 Infotainment System

Setting the Region, Entering

an Address and Point of

Interest, and Storing a Home

Destination and Preset

Destinations

Before entering an Address,

Point of Interest, Home, or Preset

Destination, select the correct

region that contains the final

destination. The vehicle must

be stopped to do this operation.

Setting the Region

To set the region:

1. If the radio is already on with

a map disc inserted, skip to

Step 5.

2. Press the power/volume knob to

turn the system on.

3. Insert the DVD map disc.

See “Installing the DVD Map

Disc”under Maps on page 73

for more information.

4. A Caution may appear.

Press Agree to proceed.

5. Press NAV.

6. Press MENU, located on the

screen.

7. Press A(Enter Destination).

8. Press the Region screen button.

9. Select the correct numbered

region that contains your final

destination.

The system returns to the Enter

Destination menu. See Enter

Destination on page 36 for

more information.

Entering an Address

To set a destination by entering a

street address:

1. If the radio is already on with

a map disc inserted, skip to

Step 5.

2. Press the power/volume knob to

turn the system on.

3. Insert the DVD map disc.

See “Installing the DVD Map

Disc”under Maps on page 73

for more information.

4. A Caution may appear.

Press Agree to proceed.

5. Press NAV.

6. Press MENU, located on the

screen.

7. Press A. Verify that the selected

Region is correct.

8. Press 2(Address).

9. Enter the street name using the

alpha keypad on the screen.

Do not enter street direction

(i.e. N, S.E., or W) information

or type of street (i.e. road,

lane, or court) to the address.

Use the space symbol screen

button (U) between street or

city names. Use the backspace

(V) screen button if an incorrect

character has been entered.

10. Select the type of street

(Dr., Ln., St., etc.) if it applies,

from the list.

Black plate (9,1)

Chevrolet Corvette Navigation System (Includes Mex) - 2012

Infotainment System 9

11. If there is more than one city,

the system displays the list of

cities that have a street with

that name. Select a city from

the list or select the Input

Name screen button to enter

the city name.

12. Enter the house number using

the numeric keypad on the

screen and press OK.

A map screen appears with the

destination marked.

13. Select h(Destination).

14. Select the Guide screen

button.

15. Once driving begins, an

audio prompt “Proceed to

the highlighted route”is heard.

The vehicle is now in route

guidance mode.

See “Address”under Enter

Destination on page 36 for

more information.

Entering a Point of Interest (POI)

To set a destination by entering a

Point of Interest (POI):

1. If the radio is already on with

a map disc inserted, skip to

Step 5.

2. Press the power/volume knob to

turn the system on.

3. Insert the DVD map disc.

See “Installing the Map DVD”

under Maps on page 73 for

more information.

4. A Caution may appear.

Press Agree to proceed.

5. Press NAV.

6. Press the MENU screen button.

7. Press A. Verify that the selected

Region is correct.

8. Press K(Point of Interest).

9. Enter the specific title of the POI

in the Name space using the

alpha keypad on the screen.

10. Select the POI from the list.

11. If there is more than one city,

the system displays the list of

cities that have a street with

that name. Select a city from

the list or select the Input

Name screen button to input

the city name.

A map screen appears with the

destination marked.

12. Select h(Destination).

13. Select the Guide screen

button.

14. Once driving begins an

audio prompt “Proceed to

the highlighted route”is heard.

The vehicle is now in route

guidance mode.

Using the Category or City

selections to help find the POI

by limiting the search options.

See “Point of Interest (POI)”under

Enter Destination on page 36 for

more information.

Black plate (10,1)

Chevrolet Corvette Navigation System (Includes Mex) - 2012

10 Infotainment System

Storing a Home Destination

1. If the radio is already on with

a map disc inserted, skip to

Step 5.

2. Press the power/volume knob to

turn the system on.

3. Insert the DVD map disc.

See “Installing the DVD Map

Disc”under Maps on page 73

for more information.

4. A Caution may appear.

Press Agree to proceed.

5. Press NAV.

6. Press the MENU screen button.

7. Press N(Stored Locations).

8. Press L(Home).

9. Press the Add screen button.

10. Press Address and enter all

address information.

11. Press OK.

A map screen appears with the

destination marked.

12. Press OK.

13. Press the back arrow screen

button.

The Lis highlighted on the

Enter Destination screen.

See “Using Your Home or

Preset Destinations”later

in this section for more

information.

Storing a Preset Destination

1. If the radio is already on with

a map disc inserted, skip to

Step 5.

2. Press the power/volume knob to

turn the system on.

3. Insert the DVD map disc.

See “Installing the DVD Map

Disc”under Maps on page 73

for more information.

4. A Caution may appear.

Press Agree to proceed.

5. Press NAV.

6. Press the MENU screen button.

7. Press N.

8. Press B(Previous Dest.).

9. Press the Add screen button,

then select the numbered preset

button for the destination to

appear as.

10. Press Address and enter all

address information.

11. Press OK.

A map screen appears with the

destination marked.

12. Press OK.

13. Press the back arrow screen

button.

The numbered preset

destination is highlighted

on the Enter Destination

screen. See “Using Your

Home or Preset Destinations”

next in this section for more

information.

Altri manuali per 2012 Corvette

Indice

Altri manuali Chevrolet Sistema di navigazione per auto

Chevrolet

Chevrolet VOLT 2012 Manuale utente

Chevrolet

Chevrolet Acadia 2012 Manuale utente

Chevrolet

Chevrolet ACADIA - NAVIGATION SYSTEM 2008 Manuale utente

Chevrolet

Chevrolet 2012 Equinox Manuale utente

Chevrolet

Chevrolet 2006 Tahoe Manuale utente

Chevrolet

Chevrolet 2005 Corvette Manuale utente

Chevrolet

Chevrolet EQUINOX GMC TERRAIN NAVIGATION SYSTEM - 2011 Manuale di riferimento

Chevrolet

Chevrolet 2012 Full-Size Truck Manuale utente

Chevrolet

Chevrolet 2013 Corvette Manuale utente

Chevrolet

Chevrolet 2008 Corvette Navigation System Manuale utente

Chevrolet

Chevrolet Chevrolet 2015 Manuale utente

Chevrolet

Chevrolet ACADIA - 2011 Manuale elenco delle parti

Chevrolet

Chevrolet TAHOE - TRUCK NAVIGATION SYSTEM 2010 Manuale utente

Chevrolet

Chevrolet Avalanche 2005 Manuale utente

Chevrolet

Chevrolet Buick Rendezvous 2005 Manuale utente

Chevrolet

Chevrolet CORVETTE COUPE - NAVIGATION SYSTEM 2010 Manuale utente

Chevrolet

Chevrolet GMC Yukon 2005 Manuale utente

Chevrolet

Chevrolet 2011 Corvette Manuale elenco delle parti

Chevrolet

Chevrolet 2013 Full-Size Truck Manuale utente

Chevrolet

Chevrolet 2012 Corvette Manuale utente

Chevrolet

Chevrolet 2004 Tahoe Manuale utente

Chevrolet

Chevrolet Cruze Infotainment system Manuale utente

Chevrolet

Chevrolet 2009 Corvette Manuale utente

Chevrolet

Chevrolet 2006 Corvette Manuale utente

Manuali Sistema di navigazione per auto popolari di altre marche

Clarion

Clarion Navigation In-Car Entertainment Manuale utente

Rosen

Rosen DP-1001 Manuale utente

Alpine

Alpine INE-W970HD Manuale utente

Skoda

Skoda AMUNDSEN+ Manuale utente

Blaupunkt

Blaupunkt TravelPilot DX-N Manuale utente

Pioneer

Pioneer MZ360500EX Manuale utente

Sanyo

Sanyo NVM-4030 - Easy Street - Automotive GPS... Manuale utente

Kenwood

Kenwood DNN991HD Manuale utente

AvMap

AvMap Geosat 2C Manuale utente

Eonon

Eonon GE01B Manuale utente

Pioneer

Pioneer AVIC-Z920DAB Manuale utente

Nextar

Nextar M3-MX - Automotive GPS Receiver Manuale utente

Furrion

Furrion NV2200 Manuale utente

Mio

Mio MOOV 200-Series Manuale utente

Prestigio

Prestigio GeoVision 5150 Manuale utente

Hummer

Hummer 2006 H3 Manuale utente

Magellan

Magellan Maestro 4210 - Automotive GPS Receiver Guida alla configurazione

Garmin

Garmin StreetPilot c510 Manuale utente
