Chevrolet CORVETTE COUPE - NAVIGATION SYSTEM 2010 Manuale utente

Infotainment System ......... 3

Introduction ...................... 3

Overview ....................... 4

Radio ............................. 13

AM-FM Radio ............... 13

Satellite Radio .............. 21

Audio Players ................ 23

CD Player ................... 23

Navigation ...................... 30

Using the Navigation

System .................. 30

Enter Destination .......... 32

Stored Locations ........... 46

Navigation Set Up ........ 55

Route Options .............. 60

Maps .......................... 66

Navigation Symbols ....... 68

Navigation Menu ........... 73

Global Positioning

System (GPS) ......... 73

Vehicle Positioning ........ 74

Problems with Route

Guidance ................ 75

If the System Needs

Service .................. 75

Ordering Map DVDs ...... 76

Database Coverage

Explanations ........... 76

Voice Recognition .......... 76

Index .................................. i-1

2010 Chevrolet Corvette Navigation System M

Introduction

GENERAL MOTORS, GM, the

GM Emblem, CHEVROLET, the

CHEVROLET Emblem, the name

CORVETTE, and the CORVETTE

Emblems are registered trademarks

of General Motors Corporation.

Dolby

is manufactured under

license from Dolby

Laboratories.

Dolby

and the double-D symbol are

trademarks of Dolby

Laboratories.

The information in this manual

supplements the owner manual.

This manual describes features that

may or may not be on your speciﬁc

vehicle either because they are

options that you did not purchase or

due to changes subsequent to the

printing of this owner manual. Please

refer to the purchase documentation

relating to your speciﬁc vehicle to

conﬁrm each of the features found

on your vehicle. For vehicles ﬁrst

sold in Canada, substitute the name

“General Motors of Canada Limited”

for Chevrolet Motor Division

wherever it appears in this manual.

Keep this manual with the owner

manual in the vehicle, so it will

be there if it is needed. If the vehicle

is sold, leave this manual in the

vehicle.

Canadian Vehicle Owners

(Propriétaires des Véhicules

Canadiens)

A French language copy of this

manual can be obtained from your

dealer/retailer or from:

On peut obtenir un exemplaire de

ce guide en français auprès du

concessionnaire ou à l’adresse

Helm, Incorporated

P.O. Box 07130

Detroit, MI 48207

1-800-551-4123

Numéro de poste 6438 de langue

française

www.helminc.com

Litho in U.S.A.

Part No. 25971787 A First Printing

Infotainment System 3

Overview

Read this manual thoroughly to

become familiar with how the

navigation system operates.

The navigation system includes

navigation and audio functions.

While entering the vehicle or when

turning the vehicle off, some

DVD Map Disc noise is normal.

Keeping your eyes on the road and

your mind on the drive is important

for safe driving. The navigation

system has built-in features intended

to help keep your eyes on the road

and mind on the drive. Some

features may be disabled while

driving. Note that these functions will

be grayed-out. A grayed-out function

indicates it is not available when the

vehicle is moving.

All functions are available when the

vehicle is parked. Do the following

before driving:

•Become familiar with the

navigation system operation,

hard keys on the faceplate, and

touch-sensitive screen buttons

of the navigation system.

•Set up the audio by presetting

favorite stations, setting the

tone, and adjusting the speakers.

•Set up the navigation features

before beginning driving, such

as entering an address or a

preset destination.

•Set up your phone numbers in

advance so they can be called

easily with the press of a

single button or a single voice

command (for navigation systems

equipped with phone capability).

{WARNING

Taking your eyes off the road too

long or too often while using the

navigation system could cause a

crash resulting in injury or death

to you or others. Focus your

attention on driving.

{WARNING

Avoid looking too long or too

often at the moving map on the

navigation screen. This could

cause a crash and you or others

can be injured or killed. Use the

turn-by-turn voice guidance

directions whenever possible.

4 Infotainment System

Use the navigation system to:

•Plan a route.

•Select a destination using

various methods and choices.

•Follow turn-by-turn route and

map guidance with voice

prompts, only if permitted by

traffic laws, controls, and

conditions.

You should always be alert and

obey traffic and roadway laws and

instructions, regardless of the

guidance from the navigation

system. Because the navigation

system uses street map information

that does not include all traffic

restrictions or the latest road

changes, it may suggest using a road

that is now closed for construction or

a turn that is prohibited by signs at

the intersection. Because the system

uses limited information, you must

always evaluate whether following

the system’s directions is safe and

legal for the current conditions.

When the navigation system is

turned on, a screen may appear

with the information below, and you

must read and acknowledge the

information it contains.

{WARNING

Taking your eyes off the road for

extended periods could cause a

crash resulting in injury or death

to you or others.

To help avoid a crash in which you

or others could be killed:

•Always concentrate on your

driving ﬁrst by keeping your eyes

and mind on the road, and

your hands on the wheel.

•Follow system directions only if

permitted by traffic laws,

controls, and conditions.

•Before using this system, read

the owner’s manual and learn

how it operates.

•Some system controls cannot

be used the when vehicle

is moving.

After you acknowledge the start up

information you will be able to

access the NAV (navigation) and

DEST (destination) functions.

Once accessed, you can enter or

delete information in the navigation

system or access other functions.

See instructions later in this section.

Every ﬁfty times the vehicle is

started and the navigation system

is turned on, the Caution screen

appears.

Infotainment System 5

After reading the caution, select OK

to load the map DVD information.

If OK is not selected, all hard

keys except for NAV (Navigation)

and DEST (Destination) can

be accessed. You can also press

the NAV hard key to have this

Caution screen appear.

When getting started, set the

navigation system to your preference

or delete information you may have

entered using various options.

A. g(Voice Recognition) Key.

See “Hard Keys” under Using

the Navigation System on

page 30 for more information.

B. SRCE (Source) Key. See “Hard

Keys” under Using the Navigation

System on page 30 for more

information.

C. NAV (Navigation) Key. See

“Hard Keys” under Using

the Navigation System on

page 30 for more information.

D. e/z(Audio/Screen Adjust)

Key. See “Hard Keys” under

Using the Navigation System on

page 30 for more information.

6 Infotainment System

E. QOSEEK R(Seek/Tune)

Key. See “Hard Keys” under

Using the Navigation System on

page 30 for more information.

F. Power Volume Knob. See “Hard

Keys” under Using the Navigation

System on page 30 for more

information.

G. XDVD (DVD Map Database

Eject) Key. See “Installing the

Map DVD” under Maps on

page 66 for more information.

H. XB(CD Eject) Key. See “CD

Player’’ on page 23 for more

information.

I. CD Slot

J. DVD Map Database Slot

K. Navigation System Screen

L. X(Open/Close Faceplate) Key.

See “Hard Keys” under Using

the Navigation System on

page 30 for more information.

Language

To change the language of the

prompts that appear on the

navigation screens, see “DIC

Operation and Displays” in the Index

of the vehicle’s owner manual.

Deleting Personal Information

This navigation system can

record and store destinations.

You may want to delete stored

destinations when the vehicle is

sold or the lease has expired. Refer

to the following sections to delete

the destination information that

has been stored.

See “Memory Points”, “Home”,

“Previous Destination” and “Preset

Destinations”, under Stored

Locations on page 46 for deleting

stored destinations.

Storing Radio Station Presets

To set preset radio stations:

1. Press the power/volume knob to

turn the system on.

2. Press the SRCE hard key and

select the desired band (AM,

FM1, FM2, XM1, or XM2

(if equipped)).

3. Use the TUNE/SEEK arrows to

tune to the desired station.

4. Press and hold one of the

six preset screen buttons, at the

bottom of the screen, until a beep

is heard or the station is displayed

on the selected preset button.

5. Repeat the steps for each preset.

See “Preset Station Menu” under

AM-FM Radio on page 13 or

Satellite Radio on page 21 for more

information.

Infotainment System 7

Setting the Clock

To set the time:

1. Press the power/volume knob to

turn the system on.

2. Press and hold the time display

in the upper right corner of any

screen.

3. Select the 12H or 24H screen

button to display the time in

standard or military time.

4. Press and hold the Hour and

Min. (minute) arrow buttons

to increase or to decrease

the time.

5. Select the correct time zone

screen button.

6. Select the Daylight Saving Time

screen button, if necessary.

The radio uses the GPS satellite to

set the time. The vehicle needs

to be in an open area to receive the

signal. See “Clock” under AM-FM

Radio on page 13 for more

information.

Setting the Region, Entering

an Address and Point of

Interest, and Storing a Home

Destination and Preset

Destinations

Before entering an Address,

Point of Interest, Home, or Preset

Destination, select the correct region

that contains the ﬁnal destination.

The vehicle must be stopped to do

this operation.

Setting the Region

To set the region:

1. If the radio is already on with a

map disc inserted, skip to Step 5.

2. Press the power/volume knob to

turn the system on.

3. Insert the DVD map disc. See

“Installing the Map DVD” under

Maps on page 66 for more

information.

4. A notice may appear. Touch the

Agree screen button to proceed.

5. Press the NAV hard key.

6. Press the MENU screen button.

7. Press the <Enter Destination

screen button.

8. Press the Region screen button.

9. Select the correct numbered

region screen button that

contains your ﬁnal destination.

The system returns to the Enter

Destination menu. See Enter

Destination on page 32 for more

information.

Entering an Address

To set a destination by entering a

street address:

1. If the radio is already on with a

map disc inserted, skip to Step 5.

2. Press the power/volume knob to

turn the system on.

3. Insert the DVD map disc. See

“Installing the Map DVD” under

Maps on page 66 for more

information.

4. A notice may appear. Touch the

Agree screen button to proceed.

8 Infotainment System

5. Press the NAV hard key.

6. Press the MENU screen button.

7. Press the <Enter Destination

screen button. Verify that the

selected Region is correct.

8. Press the 2Address screen

button.

9. Enter the street name using the

alpha keypad on the screen.

Do not enter street direction (ie N,

S.E., or W) information or type of

street (ie road, lane, or court) to

the address. Use the space

symbol screen button (U)

between street or city names.

For example, the street name

N. Royal Oak Rd. should be

entered as royalUoak. Use the

backspace (V) screen button if

an incorrect character has been

entered.

10. Select the type of street

(Dr., Ln., St., etc.) if it applies,

from the list.

11. If there is more than one city, the

system displays the list of cities

that have a street with that

name. Select a city from the list

or select the Input Name screen

button to enter the city name.

12. Enter the house number using

the numeric keypad on the

screen and touch the OK screen

button.

A map screen appears with the

destination marked.

13. Select the h(destination)

symbol screen button.

14. Select the Guide screen button.

15. Once driving begins, an

audio prompt “Proceed to

the highlighted route” is heard.

The vehicle is now in route

guidance mode.

See “Address” under Enter

Destination on page 32 for more

information.

Entering a Point of Interest (POI)

To set a destination by entering

a Point of Interest (POI):

1. If the radio is already on with a

map disc inserted, skip to Step 5.

2. Press the power/volume knob to

turn the system on.

3. Insert the DVD map disc. See

“Installing the Map DVD” under

Maps on page 66 for more

information.

4. A notice may appear. Touch the

Agree screen button to proceed.

5. Press the NAV hard key.

6. Press the MENU screen button.

7. Press the <Enter Destination

screen button. Verify that the

selected Region is correct.

8. Press the KPoint of Interest

screen button.

Infotainment System 9

9. Enter the speciﬁc title of the

POI in the Name space

(i.e. Washington Monument)

using the alpha keypad on the

screen.

10. Select the POI from the list.

11. If there is more than one city, the

system displays the list of cities

that have a street with that

name. Select a city from the list

or select the Input Name screen

button to input the city name.

A map screen appears with the

destination marked.

12. Select the h(destination)

symbol screen button.

13. Select the Guide screen button.

14. Once driving begins an audio

prompt “Proceed to the

highlighted route” is heard.

The vehicle is now in route

guidance mode.

Using the Category or City

selections to help ﬁnd the POI

by limiting the search options.

See “Point of Interest (POI)” under

Enter Destination on page 32

for more information.

Storing a Home Destination

1. If the radio is already on with a

map disc inserted, skip to Step 5.

2. Press the power/volume knob to

turn the system on.

3. Insert the DVD map disc. See

“Installing the Map DVD” under

Maps on page 66 for more

information.

4. A notice may appear. Touch the

Agree screen button to proceed.

5. Press the NAV hard key.

6. Press the MENU screen button.

7. Press the NStored Locations

screen button.

8. Press the LHome screen button.

9. Press the Add screen button.

10. Press the Address screen

button and enter all address

information.

11. Press the OK screen button.

A map screen appears with

the destination marked.

12. Press the OK screen button.

13. Press the back arrow screen

button.

The LHome icon is highlighted

on the Enter Destination

screen. See “Using Your Home

or Preset Destinations” later

in this section for more

information.

Storing a Preset Destination

1. If the radio is already on with a

map disc inserted, skip to Step 5.

2. Press the power/volume knob to

turn the system on.

3. Insert the DVD map disc. See

“Installing the Map DVD” under

Maps on page 66 for more

information.

4. A notice may appear. Touch the

Agree screen button to proceed.

5. Press the NAV hard key.

10 Infotainment System

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Chevrolet Sistema di navigazione per auto

Chevrolet

Chevrolet 2012 Equinox Manuale utente

Chevrolet

Chevrolet Chevrolet 2015 Manuale utente

Chevrolet

Chevrolet 2012 Cruze Manuale utente

Chevrolet

Chevrolet GMC Yukon 2005 Manuale utente

Chevrolet

Chevrolet 2013 Full-Size Truck Manuale utente

Chevrolet

Chevrolet Avalanche 2005 Manuale utente

Chevrolet

Chevrolet ACADIA - 2011 Manuale elenco delle parti

Chevrolet

Chevrolet TAHOE - TRUCK NAVIGATION SYSTEM 2010 Manuale utente

Chevrolet

Chevrolet 2009 Corvette Manuale utente

Chevrolet

Chevrolet 2006 Corvette Manuale utente

Chevrolet

Chevrolet 2013 Corvette Manuale utente

Chevrolet

Chevrolet VOLT 2012 Manuale utente

Chevrolet

Chevrolet 2005 Corvette Manuale utente

Chevrolet

Chevrolet Acadia 2012 Manuale utente

Chevrolet

Chevrolet EQUINOX GMC TERRAIN NAVIGATION SYSTEM - 2011 Manuale di riferimento

Chevrolet

Chevrolet 2012 Corvette Manuale utente

Chevrolet

Chevrolet Cruze Infotainment system Manuale utente

Chevrolet

Chevrolet 2006 Tahoe Manuale utente

Chevrolet

Chevrolet 2012 Corvette Manuale utente

Chevrolet

Chevrolet Buick Rendezvous 2005 Manuale utente

Chevrolet

Chevrolet 2008 Corvette Navigation System Manuale utente

Chevrolet

Chevrolet 2004 Tahoe Manuale utente

Chevrolet

Chevrolet 2011 Corvette Manuale elenco delle parti

Chevrolet

Chevrolet ACADIA - NAVIGATION SYSTEM 2008 Manuale utente

Manuali Sistema di navigazione per auto popolari di altre marche

Clarion

Clarion Navigation In-Car Entertainment Manuale utente

Rosen

Rosen DP-1001 Manuale utente

Alpine

Alpine INE-W970HD Manuale utente

Skoda

Skoda AMUNDSEN+ Manuale utente

Blaupunkt

Blaupunkt TravelPilot DX-N Manuale utente

Pioneer

Pioneer MZ360500EX Manuale utente

Sanyo

Sanyo NVM-4030 - Easy Street - Automotive GPS... Manuale utente

Kenwood

Kenwood DNN991HD Manuale utente

AvMap

AvMap Geosat 2C Manuale utente

Eonon

Eonon GE01B Manuale utente

Pioneer

Pioneer AVIC-Z920DAB Manuale utente

Nextar

Nextar M3-MX - Automotive GPS Receiver Manuale utente

Furrion

Furrion NV2200 Manuale utente

Mio

Mio MOOV 200-Series Manuale utente

Prestigio

Prestigio GeoVision 5150 Manuale utente

Hummer

Hummer 2006 H3 Manuale utente

Magellan

Magellan Maestro 4210 - Automotive GPS Receiver Guida alla configurazione

Garmin

Garmin StreetPilot c510 Manuale utente
