4” TABLE SAW

WITH 2 BLADES

93211

ASSEMBLY AND OPERATING INSTRUCTIONS

Visit our website at: http://www.harborfreight.com

Read this material before using this product.

Failure to do so can result in serious injury.

SAVE THIS MANUAL.

manual or any artwork contained herein may be reproduced in any shape or form

without the express written consent of Harbor Freight Tools. Diagrams within this

manual may not be drawn proportionally. Due to continuing improvements, actual

product may differ slightly from the product described herein. Tools required for

assembly and service may not be included.

For technical questions or replacement parts, please call 1-800-444-3353.

Revised Manual 11e

Page 2SKU 93211 For technical questions, please call 1-800-444-3353.

Motor 120 Volts AC /60 Hz / 90 Watts / 1/8HP / 14,000 no load RPM

14,000 RPM Minimum Accessory Rating

Depth of Cut 3/4”

Table Two miter slots, 3/8” each with miter gauge;

7-1/2” L x 5-1/2” W

Arbor Diameter 1/2”

Power Cord 5’, 18 Gauge, 3-prong plug

Blades 4” Dry Diamond Blade

4” x 40 T Manganese Steel Saw Blade

Net Weight 6.8 Lbs.

Save This Manual

You will need the manual for the safety warnings and precautions, assembly instruc-

tions, operating and maintenance procedures, parts list and diagram. Keep your

invoice with this manual. Write the invoice number on the inside of the front cover.

Keep the manual and invoice in a safe and dry place for future reference.

Safety Warnings and Precautions

WARNING: When using this tool, basic safety precautions should always be

followed to reduce the risk of personal injury and damage to equipment.

Read all instructions before using this tool!

1. Keep work area clean. Cluttered areas invite injuries.

2. Observe work area conditions. Do not use machines or power tools in damp

or wet locations. Don’t expose to rain. Keep work area well lighted. Do not

use electrically powered tools in the presence of ammable gases or liquids.

3. Keep children away. Children must never be allowed in the work area. Do

not let them handle machines, tools, or extension cords.

4. Store idle equipment. When not in use, tools must be stored in a dry location

to inhibit rust. Always lock up tools and keep out of reach of children.

5. Do not force tool. It will do the job better and more safely at the rate for which

it was intended. Do not use inappropriate attachments in an attempt to exceed

the tool capacity.

6. Use the right tool for the job. Do not attempt to force a small tool or attach-

ment to do the work of a larger industrial tool. There are certain applications

for which this tool was designed. Do not modify this tool and do not use this

tool for a purpose for which it was not intended. REV 06c

Specications

Page 3SKU 93211 For technical questions, please call 1-800-444-3353.

7. Dress properly. Do not wear loose clothing or jewelry as they can be caught

in moving parts. Protective, electrically nonconductive clothes and nonskid

footwear are recommended when working. Wear restrictive hair covering to

contain long hair.

8. Use eye and ear protection. Always wear ANSI-approved impact safety

goggles. Wear a full face shield if you are producing metal lings or wood chips.

Wear an ANSI-approved dust mask or respirator when working around metal,

wood, and chemical dusts and mists. The included eye guard is intended to

supplement eye protection, NOT replace it.

9. Do not overreach. Keep proper footing and balance at all times. Do not reach

over or across running machines.

10. Maintain tools with care. Keep tools sharp and clean for better and safer per-

formance. Follow instructions for lubricating and changing accessories. Inspect

tool cords periodically and, if damaged, have them repaired by an authorized

technician. The handles must be kept clean, dry, and free from oil and grease

at all times.

11. Disconnect power. Unplug tool when not in use.

12. Remove adjusting keys and wrenches. Check that adjusting wrenches are

removed from the tool or machine work surface before plugging it in.

13. Avoid unintentional starting. Be sure the switch is in the Off position when

not in use and before plugging in.

14. Stay alert. Watch what you are doing, use common sense. Do not operate any

tool when you are tired.

15. Check for damaged parts. Before using any tool, any part that appears

damaged should be carefully checked to determine that it will operate properly

and perform its intended function. Check for alignment and binding of moving

parts; any broken parts or mounting xtures; and any other condition that may

affect proper operation. Any part that is damaged should be properly repaired

or replaced by a qualied technician. Do not use the tool if any switch does not

turn On and Off properly.

16. Guard against electric shock. Prevent body contact with grounded surfaces

such as pipes, radiators, ranges, and refrigerator enclosures.

17. Do not operate tool if under the inuence of alcohol or drugs. Read warning

labels on prescriptions to determine if your judgment or reexes are impaired

while taking drugs. If there is any doubt, do not operate the tool.

18. Replacement parts and accessories. When servicing, use only identical

replacement parts. Use of any other parts will void the warranty. Only use ac-

Page 4SKU 93211 For technical questions, please call 1-800-444-3353.

cessories intended for use with this tool. Approved accessories are available

from Harbor Freight Tools.

19. Use proper size and type extension cord. If an extension cord is required,

it must be of the proper size and type to supply the correct current to the tool

without heating up. Otherwise, the extension cord could melt and catch re, or

cause electrical damage to the tool. This tool requires use of an extension cord

of 0 to 10 amps capability (up to 50 feet), with wire size rated at 18 AWG. Longer

extension cords require larger size wire. If you are using the tool outdoors, use

an extension cord rated for outdoor use (signied by “WA” on the jacket).

20. Maintenance. For your safety, service and maintenance should be performed

regularly by a qualied technician.

21. Warning: People with pacemakers should consult their physician(s) before

using this product. Electromagnetic elds in close proximity to a heart pace-

maker could cause interference to or failure of the pacemaker.

22. Take caution as some woods contain preservatives such as copper chro-

mium arsenate (CCA) which can be toxic. When cutting these materials extra

care should be taken to avoid inhalation and minimize skin contact.

23. WARNING: Some dust created by power sanding, sawing, grinding, drilling,

and other construction activities, contains chemicals known [to the State of

California] to cause cancer, birth defects or other reproductive harm. Some

examples of these chemicals are:

*Lead from lead-based paints

*Crystalline silica from bricks and cement or other masonry products

*Arsenic and chromium from chemically treated lumber

Your risk from these exposures varies, depending on how often you do this type

of work. To reduce your exposure to these chemicals: work in a well ventilated

area, and work with approved safety equipment, such as those dust masks that

are specially designed to lter out microscopic particles. (California Health &

Safety Code § 25249.5, et seq.)

Note: Performance of this tool (if powered by line voltage) may vary depending on

variations in local line voltage. Extension cord usage may also affect tool perfor-

mance.

Warning: The warnings, cautions, and instructions discussed in this instruction

manual cannot cover all possible conditions and situations that may occur.

It must be understood by the operator that common sense and caution are

factors which cannot be built into this product, but must be supplied by the

operator.

Page 5SKU 93211 For technical questions, please call 1-800-444-3353.

Important

BEFORE rst use, the Guard (4) and Eye Guard (5) must be properly installed.

1. Remove the Screw (6) at the end of the Guard (4). Align the hole in the center

of the Eye Guard (5) with the hole in the Guard (4).

2. The hole in the Eye Guard (5) is countersunk to accommodate the Screw. Make

sure to install it the right way. Secure using the Screw (6), while being careful

not to overtighten.

3. Swing the Guard Bracket (1) up and remove the top Screw (3). Slide the

Guard (4) over the Bracket, aligning the holes in the Guard with the hole in the

Bracket. Make sure that the Eye Guard is on the top side of the guard and that

the rounded underside of the Guard rests over the blade.

4. Install the Screw (3) to secure the Guard in place.

Changing/Replacing/Installing the Blades

1. Be sure the Table Saw is unplugged before you begin installing or changing the

accessories.

2. You will need two adjustable Wrenches (not included) to install, change or

replace the Blades. Use one wrench to hold the Blade Spindle Lock Nut (14)

in place and the other wrench to turn the Mounting Nut (10). See Assembly

Diagram on Page 7.

3. Remove the Mounting Nut and the Right Blade Bushing (11). Slide the Blade

(12a,b) over the arbor, in line with the Left Blade Bushing (13). Replace the

Right Blade Bushing and the Mounting Nut. Tighten with the wrench.

Unpacking

When unpacking, check to make sure that the product is intact and undamaged. If

any parts are missing or broken, please call Harbor Freight Tools at the number on

the cover of this manual.

REV 06c

Page 6SKU 93211 For technical questions, please call 1-800-444-3353.

Operation

1. Place your Table Saw on a at, level surface capable of supporting weight of

Table Saw and material being cut before use. Always wear ANSI-approved

safety goggles when operating this tool and ensure that all guards are in place

and in proper working order.

2. Mark your work pieces with a pencil or other writing instrument before you be-

gin cutting. Loosen the Knob (7) on the Straight Edge Guide (8) and turn the

Guide to the appropriate angle for your specic cutting requirements. Tighten

the Knob to hold the Guide in place.

3. Plug in the Power Cord (24).

4. Lift the Eye Guard (5) and slide the Straight Edge Guide out far enough to allow

you to lay your work piece at on the Table (32). Lower the Eye Guard onto

your work piece. Never remove the Guard (4) or attempt to operate this

tool without the Eye Guard (5) in place.

5. Flip the Power Switch (18) to the On position.

6. Using the Straight Edge Guide to hold your work piece steady, gently feed your

work piece toward the Blade. Keep your ngers and all other body parts

away from the Blade at all times. If your work piece is particularly small, you

may want to use another small piece of wood or other material to push your

work piece toward the Blade. Do not push forcefully against the Blade, or use

materials that are particularly difcult to cut. If the Blade slows down as you

are feeding your work piece toward it, you are pushing too forcefully, or the

material is too hard for this tool to cut.

REV 06c

Page 7SKU 93211 For technical questions, please call 1-800-444-3353.

Parts List

Part Description Qty. Part Description Qty.

1 Guard Bracket 1 17 Motor Base 1

2 Washer 4 18 Power Switch 1

3 Screw 2 19 Screw 1

4 Guard 1 20 Cover 1

5 Eye Guard 1 21 Screw 4

6 Screw 1 23 Foot 4

7 Knob 1 24 Power Cord 1

8 Straightedge Guide 1 25 Screw 2

9 Straightedge Shaft 1 26 Washer 2

10 Mounting Nut 1 27 Cord Strain Relief 1

11 Rt. Blade Bushing 1 28 Vibration Absorption Pad 4

12a Manganese Steel Blade, 40 T 129 Motor 1

12b Diamond-Coated Blade 1 30 Screw 1

13 Lt. Blade Bushing 1 31 Wing Nut 2

14 Blade Spindle Lock Nut 1 32 Table 1

15 Depth Adjustment Handle 134 Switch Plate 1

16 Washer 1 35 Screw 2

REV 06c; 09e

LIMITED 90 DAY WARRANTY

Harbor Freight Tools Co. makes every effort to assure that its products meet high quality and

durability standards, and warrants to the original purchaser that this product is free from defects in materi-

als and workmanship for the period of 90 days from the date of purchase. This warranty does not apply to

damage due directly or indirectly, to misuse, abuse, negligence or accidents, repairs or alterations outside

our facilities, criminal activity, improper installation, normal wear and tear, or to lack of maintenance. We

shall in no event be liable for death, injuries to persons or property, or for incidental, contingent, special

or consequential damages arising from the use of our product. Some states do not allow the exclusion

or limitation of incidental or consequential damages, so the above limitation of exclusion may not apply

to you. THIS WARRANTY IS EXPRESSLY IN LIEU OF ALL OTHER WARRANTIES, EXPRESS OR

IMPLIED, INCLUDING THE WARRANTIES OF MERCHANTABILITY AND FITNESS.

To take advantage of this warranty, the product or part must be returned to us with transpor-

tation charges prepaid. Proof of purchase date and an explanation of the complaint must accompany

the merchandise. If our inspection veries the defect, we will either repair or replace the product at our

election or we may elect to refund the purchase price if we cannot readily and quickly provide you with

a replacement. We will return repaired products at our expense, but if we determine there is no defect,

or that the defect resulted from causes not within the scope of our warranty, then you must bear the cost

of returning the product.

This warranty gives you specic legal rights and you may also have other rights which vary

from state to state.

3491 Mission Oaks Blvd. • PO Box 6009 • Camarillo, CA 93011 • (800) 444-3353

Page 8SKU 93211 For technical questions, please call 1-800-444-3353.

Assembly Drawing

NOTE: Some parts are listed and

shown for illustration purposes

only and are not available

individually as replacement parts.

REV 06c

PLEASE READ THE FOLLOWING CAREFULLY

THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS DIAGRAM IN THIS

MANUALAS A REFERENCE TOOL ONLY. NEITHER THE MANUFACTURER NOR DISTRIBUTOR

MAKES ANY REPRESENTATION OR WARRANTY OF ANY KIND TO THE BUYER THAT HE OR

SHE IS QUALIFIED TO MAKE ANY REPAIRS TO THE PRODUCT OR THAT HE OR SHE IS QUALI-

FIED TO REPLACE ANY PARTS OF THE PRODUCT. IN FACT, THE MANUFACTURER AND/OR

DISTRIBUTOR EXPRESSLY STATES THAT ALL REPAIRS AND PARTS REPLACEMENTS SHOULD

BE UNDERTAKEN BY CERTIFIED AND LICENSED TECHNICIANS AND NOT BY THE BUYER.

THE BUYER ASSUMES ALL RISK AND LIABILITY ARISING OUT OF HIS OR HER REPAIRS TO

THE ORIGINAL PRODUCT OR REPLACEMENT PARTS THERETO, OR ARISING OUT OF HIS

OR HER INSTALLATION OF REPLACEMENT PARTS THERETO.

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Chicago Electric Sega

Chicago Electric

Chicago Electric 40315 Istruzioni per il montaggio

Chicago Electric

Chicago Electric 91511 Manuale utente

Chicago Electric

Chicago Electric 98089 Manuale di installazione

Chicago Electric

Chicago Electric 91995 Manuale di installazione

Chicago Electric

Chicago Electric 98265 Manuale di installazione

Chicago Electric

Chicago Electric 69480 Istruzioni per il montaggio

Chicago Electric

Chicago Electric 69275 Istruzioni per il montaggio

Chicago Electric

Chicago Electric 93009 Manuale utente

Chicago Electric

Chicago Electric 14 Industrial Cut-off Saw 68104 Istruzioni per l'installazione

Chicago Electric

Chicago Electric 47840 Istruzioni per il montaggio

Chicago Electric

Chicago Electric 97580 Manuale di installazione

Chicago Electric

Chicago Electric 62420 Istruzioni per il montaggio

Chicago Electric

Chicago Electric 98265 Manuale utente

Chicago Electric

Chicago Electric Double Cut Saw 68316 Istruzioni per il montaggio

Chicago Electric

Chicago Electric 4095 Manuale utente

Chicago Electric

Chicago Electric 98058 Manuale di installazione

Chicago Electric

Chicago Electric 91757 Manuale utente

Chicago Electric

Chicago Electric POWER TOOL 94362 Manuale utente

Chicago Electric

Chicago Electric 47003 Manuale utente

Chicago Electric

Chicago Electric 97360 Istruzioni per il montaggio

Chicago Electric

Chicago Electric 68298 Manuale utente

Chicago Electric

Chicago Electric 68849 Manuale utente

Chicago Electric

Chicago Electric 69066 Manuale utente

Chicago Electric

Chicago Electric 69702 Istruzioni per il montaggio

Manuali Sega popolari di altre marche

RIDGID

RIDGID BS1400 Manuale utente

ATIKA

ATIKA BWS 400-2 Manuale utente

RGC

RGC FS20 Manuale utente

Makita

Makita M2300 Manuale utente

IMET Spa

IMET Spa BASIC 300 PLUS SHI Manuale utente

IMET Spa

IMET Spa SIRIO 370 AF-E Manuale utente

Optimum

Optimum OPTisaw CS 275 Manuale utente

Makita

Makita BPB180 Manuale utente

Stihl

Stihl MS 462 C-M Manuale utente

AEG

AEG TS 250 K Manuale utente

Meec tools

Meec tools 004665 Manuale utente

Makita

Makita LS1018L Manuale utente

Ryobi

Ryobi RCS1400 Manuale utente

DeWalt

DeWalt DCS391 Manuale utente

Sealey

Sealey SA72 Manuale utente

skilsaw

skilsaw SPT88 Istruzioni per il montaggio

Urrea

Urrea SI810 Dimensioni e guida di installazione

EINHELL

EINHELL BKG 210/1 Manuale utente
