Chocolate3 Choc mate 2 Manuale utente
by
User manual
EN
© 2021 | November 19th 2021 | Version 0.6
Page 02
Welcome
Thank you for choosing a
choc mate 2 by chocolate³.
We wish you lots of fun and creativity
while using it!
Satised?
Share your experiences with
colleagues, friends and
customers. Also, become part
of our growing community and
share your results on
social media
#chocmated
Problems?
Visit our
help pages at
https://choc-mate.de/******
or
contact the support
Page 03
As a supplement to these instructions, please also
take a look at our videos at
https://www.choc-mate.de/quick-start/
Page 04
1. Basic information
1.1. Use of these operating instructions 08
1.2. General description of the product 08
1.3. Disclaimer 09
1.4. Hazard warnings 09
1.5. Declaration of conformity from **.**.2021 10
2. Safety instructions
2.1. Intended use of the machine 12
2.2. Suitability for food 13
2.3. General information on safety 13
2.4. Electrical safety 14
2.5. Mechanical safety 14
2.6. Risk of burns 15
2.7. Possible misuse 15
2.8. Cleaning 16
2.9. Mains voltage 16
2.10. Risk of injury 16
2.11. Liabilty 17
3. Components overview
3.1. Overview 20
3.2. Scope of delivery 22
4. First commissioning
4.1. Location 24
4.2. Unpack 26
4.3. Structure 28
4.3.1. Guide attachment 28
4.3.2. Preparing and attaching the printing plate 28
4.3.3. Power supply 28
4.4. Switch on 29
4.5. Levelling the print bed 29
4.6. Switch o 29
4.7. Connection between printer and computer 30
4.7.1. Connection via USB stick 30
4.7.2. Wired via router 30
4.7.3. Wireless (Wlan) via router 31
4.7.4. Wireless direct connection (hotspot) 32
5. Operating the printer
5.1. Important terms 34
5.2. Switch-on routine 34
5.3. Preparations for printing 36
5.3.1. Attaching a nozzle element 36
5.3.2. Preparing and attaching the printing plate 36
5.3.3. Preparing and applying the piston 37
5.4. Inserting a cartridge 38
5.5. Homing 39
Inhaltsverzeichnis
Page 05
5.6. Pre-dosing 40
5.7. Using the preheater 41
5.8. Print 42
5.8.1. Start 43
5.8.2. Babysteppping 44
5.8.3. Pause / Cancel 44
5.8.4. Removing the print objects 45
5.9. Changing the cartridge, piston and nozzle 46
5.9.1. Changing / relling the cartridge 46
5.9.2. Changing the piston 47
5.9.3. Changing the nozzle 48
5.10. Copying print les 50
5.10.1. Web Interface 50
5.10.2. USB 52
6. Printer menu
6.1. Navigation 56
6.2. Status 57
6.3. Move 58
6.4. Extrude 59
6.5. Pre-dose 60
6.6. Babysteppping 60
6.7. Quick Actions 61
6.8. Temperatures 62
6.9. Help 62
6.10. Settings 63
6.10.1. Console 63
6.10.2. Netzwork 64
6.10.3. WLAN Settings 64
6.10.4. Time setting 65
6.10.5. Language 66
6.10.6. Hardware Information 66
6.10.7. Information 66
7. Maintenance and cleaning
7.1. Levelling the print bed 68
7.2. Cleaning the individual parts 70
7.3. Aligning the buildplate 71
7.4. Cleaning the printhead 72
7.5. Cleaning the printer 74
7.6. Maintenance 74
7.6.1. Lubricating the linear guides 75
7.6.2. Cleaning the extruder spindle 76
7.6.3. Checking the belt tension 77
8. Creating print les (choc OS)
9. Additional information
9.1. Technical data / Product data sheet 84
9.2. Decommissioning 85
9.3. Disposal 86
9.4. Important notes 86
9.5. Legal notice 87
9.6. Contact 87
1. Basic information
Page 08
1.1. Use of these operating instructions
1.2. General description of the product
Caution: Before using the choc mate 2 for the
be read carefully and observed. Non-obser-
vance of individual points listed in the ope-
rating instructions can cause personal injury
and / or damage to property!
No part of this operating manual may be
any form without the prior written consent
of chocolate³. chocolate³ reserves the right
and software described in these operating
instructions at any time and without prior no-
tice.
Please ensure that you have the latest version
of the operating instructions. Also check after
a software update whether a new version of
these instructions is available.
The latest version of the operating instruc-
tions can be found at:
https://choc-mate.de/***
-
tions in your national language if these are
not enclosed, although the German instruc-
tions should always be regarded as the ori-
ginal.
Please keep the operating manual for future
reference.
Chocolate 3D printer for commercial use.
The choc mate 2 is a 3D printer for cho-
colate or couverture with a print area of
340x232x160mm.
It has a heatable print head with two tempe-
rature control circuits. The printer also has a
heated preheater for preparing another car-
tridge. In the Z direction, the minimum layer
structures and very smooth surfaces can also
be printed. In the X-Y direction, a resolution of
approx. 0.1 mm is achieved. The actual accu-
racy when printing chocolate depends largely
on the chocolate used, the temperature and
the ambient conditions.
An integrated print server with a 4.3“ touch
display makes it possible to operate the prin-
ter independently. Due to the network inter-
faces, the printer can also be operated with
the help of a browser.
We clearly point out that the system must not
be operated unattended.
Any additional devices must be matched to
the main unit (if you have any queries, please
contact the manufacturer).
Page 09
1.3. Disclaimer
This user manual must be read carefully as it
contains all the necessary information for the
user to operate the choc mate 2 safely and
correctly. The operator must ensure that each
user of the 3D printer has access to a copy of
this manual and has read and understood it.
The requirements or procedures for the as-
sembly, handling, storage, use or disposal of
the device are beyond our control and know-
ledge. Therefore, for this reason and others,
we expressly disclaim any liability for loss or
injury, damage or expense arising out of or
in connection with the installation, handling,
storage, use or disposal of this product. The
information contained in this document has
been obtained from what we believe to be re-
liable sources. However, no warranty, express
or implied, is made as to its accuracy.
-
propriate place in the manual:
1.4. Hazard warnings
Danger of burns from hot machine parts such as print head and preheater
switch and distance sensor.
• Keep devices and objects away that can be damaged by strong magne-
• We ask people with pacemakers not to come too close to the device.
Danger to life due to electric shock
Danger of crushing due to moving parts such as print bed, print head,
Z-axis and extruder
General warnings
Page 10
1.5. Declaration of conformity from **.**.2021
