MakerBot Replicator Manuale utente
USER MANUAL
1 WELCOME 04
Safety and Compliance 05
About the MakerBot Replicator 07
2GETTING STARTED 10
Accessory Checklist 11
Unpacking the MakerBot Replicator 12
Setting up the MakerBot Replicator 14
3STARTUP 18
The MakerBot Replicator Control Panel 19
First Steps 20
4MAKERBOT DESKTOP 24
Downloading and Installing MakerBot Desktop 25
Printing from MakerBot Desktop 26
5THE CONTROL PANEL 34
Home Screen 35
Print 36
Filament 40
Preheat 41
Utilities 41
Settings 43
Info 44
VERSION 1
TABLE OF CONTENTS
Welcome.
Let’s get started.
VERSION 1
6TROUBLESHOOTING 45
Printing Problems 46
Connectivity Problems 48
Update Firmware 50
7REFERENCE 51
Specifications 52
Glossary 53
How to use MakerBot Support 56
Contact 57
8TERMS 58
TABLE OF CONTENTS
WELCOME.
Let’s Get started.
Welcome to the User Manual for the MakerBot®
Replicator®Desktop 3D Printer (Fih Generation
Model). The fih generation MakerBot Replicator
is super easy to use, but it’s also packed with
brand-new features, so even if you’ve used a
MakerBot Desktop 3D Printer before, be sure to
read this manual all the way through.
1
Welcome, let’s get started5
SAFETY AND COMPLIANCE
RADIO AND TELEVISION INTERFERENCE
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant
to Part 15 of the Federal Communications Commission (FCC) rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not installed and used in accordance
with the instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment o and on,
the user is encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and the receiver.
• Connect the equipment to an outlet on a circuit dierent from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
You may also find helpful the following booklet, prepared by the FCC: “How to Identify and Resolve
Radio-TV Interference Problems.” This booklet is available from the U.S. Government Printing Oce,
Washington, D.C. 20402.
Changes and modifications not expressly approved by the manufacturer or registrant of this equipment
can void your authority to operate this equipment under FCC rules.
MANUFACTURER
MakerBot Industries, LLC
One MetroTech Center, 21st Floor
Brooklyn, NY 11201
347.334.6800
Now, before we get going, let’s review some important safety information.
Welcome, let’s get started6
SAFETY AND COMPLIANCE
Safety alert symbols precede each safety message in this manual. These symbols indicate
potential safety hazards that could harm you or others or cause product or property damage.
Warning: The MakerBot Replicator generates high temperatures. Always allow the
MakerBot Replicator to cool down before you reach inside.
Warning: The MakerBot Replicator includes moving parts that can cause injury.
Never reach inside the MakerBot Replicator while it is in operation.
Warning: There is a risk of shock. This product is not user serviceable.
Warning: Do not leave the MakerBot Replicator unattended during operation.
Caution: Do not print using materials that have not been approved by MakerBot for
use with the MakerBot Replicator. Refer to the Specifications section on page 52 for
more information.
Caution: The socket outlet must be located near the equipment and must be
easily accessible.
Caution: In case of emergency disconnect the MakerBot Replicator from the
wall socket.
Caution: The MakerBot Replicator melts plastic during printing. Plastic odors are
emitted during this operation. Make sure to set up the MakerBot Replicator in a well-
ventilated area.
Welcome, let’s get started7
ABOUT THE MAKERBOT REPLICATOR
The MakerBot Replicator makes solid, three-dimensional objects out of melted MakerBot
PLA Filament. First, use MakerBot Desktop to translate 3D design files into instructions for the
MakerBot Replicator. Then transfer those instructions to the MakerBot Replicator via USB drive,
USB cable, or your local network. The MakerBot Replicator will melt MakerBot PLA Filament
and squeeze it out onto the build plate in thin lines to build your object layer by layer. This
method of 3D printing is called fused deposition modeling.
HOW IT WORKS
Welcome, let’s get started8
ABOUT THE MAKERBOT REPLICATOR
3
1
7
MAKERBOT REPLICATOR DIAGRAMS
4
6
5
2
6. Filament Drawer
7. Filament Spindle
Welcome, let’s get started9
ABOUT THE MAKERBOT REPLICATOR
1614 15
1413121110
GettinG started
When you set up your MakerBot®Replicator®
Desktop 3D Printer, remember that it was built
and packaged very carefully at the MakerBot
factory. We hope you’ll take your time and be
just as careful unpacking it and getting it set up.
2
