MakerBot Replicator Z18 Manuale utente

USER MANUAL

1 WELCOME 04

Legal Notices 05

Safety and Compliance 07

About the MakerBot Replicator Z18 10

2GETTING STARTED 14

Accessory Checklist 15

Unpacking the MakerBot Replicator Z18 16

Setting up the MakerBot Replicator Z18 21

3STARTUP 25

The MakerBot Replicator Z18 Control Panel 26

First Steps 27

4MAKERBOT DESKTOP 30

Downloading and Installing MakerBot Desktop 31

Printing from MakerBot Desktop 33

5THE CONTROL PANEL 41

Home Screen 42

Print 43

Filament 47

Preheat 49

Utilities 49

Settings 51

Info 52

VERSION 2

TABLE OF CONTENTS

Welcome.

Let’s get started.

6TROUBLESHOOTING 53

Printing Problems 54

Leveling the Build Plate 57

Updating Firmware 59

Emptying the Filament Waste Bin 59

7REFERENCE 60

Speciﬁcations 61

Glossary 62

Contact 65

TABLE OF CONTENTS

VERSION 1

WELCOME.

Welcome to the User Manual for the MakerBot®

Replicator®Z18 3D Printer. With the MakerBot

Replicator Z18 you can print high-resolution,

industrial-quality prototypes bigger than ever,

but it also requires care and attention, so please

be sure to read this manual all the way through.

LEGAL

The MakerBot®Replicator®Z18 3D Printer is covered by a limited warranty. For terms and

conditions, see makerbot.com/legal.

All information in this user manual (“Manual”) is subject to change at any time without

notice and is provided for convenience purposes only. MakerBot Industries, LLC and our

respective aliates and suppliers (“MakerBot”) reserves the right to modify or revise this

Manual in its sole discretion and at any time and makes no commitment to provide any such

changes, updates, enhancements, or other additions to this Manual in a timely manner or

at all. You agree to be bound by any modiﬁcations and/or revisions. Contact the MakerBot

Support Team for up-to-date information.

In order to protect MakerBot proprietary and conﬁdential information and/or trade secrets,

this document may describe some aspects of MakerBot technology in generalized terms.

PRODUCT WARRANTY

OVERALL PROVISIONS

The design of this Manual and all text, graphics, information, content, and other material are

logos (the “Marks”) used in this Manual are registered and unregistered trademarks, trade

names, and service marks of MakerBot and its aliates. Nothing contained in this Manual

grants or should be construed as granting, by implication, estoppel, or otherwise, any license

or right to use any Marks without the written permission of MakerBot. Any

unauthorized use of any information, materials, or Marks may violate copyright laws,

trademark laws, laws of privacy and publicity, and/or other laws and regulations.

INTELLECTUAL PROPERTY

WELCOME.

LEGAL

MakerBot does not warrant the accuracy or completeness of the information, products,

or services provided by or through this Manual and assumes no assume no responsibility

for any typographical, technical, or other inaccuracies in this Manual, which is provided

“as is” and without any express or implied warranties of any kind, including warranties

of merchantability, ﬁtness for a particular purpose, or non-infringement of intellectual

property. In connection with your use of this Manual, MakerBot shall not be liable to you for

any damages whatsoever, be they direct, economic, commercial, special, consequential,

incidental, exemplary, or indirect damages, even if MakerBot has been advised of the

possibility of such damages, including without limitation, loss of business revenue

or earnings, lost data, or lost proﬁts. MakerBot assumes no responsibility, nor will be

liable, for any damages to, or any viruses or malware that may infect, your computer,

telecommunication equipment, or other property caused by or arising from your downloading

of any information or materials related to this Manual. The foregoing exclusions do not apply

to the extent prohibited by law; please refer to your local laws for any such prohibitions.

MakerBot makes no warranties to those deﬁned as “consumers” in the Magnuson-Moss

Warranty-Federal Trade Commission Improvement Act.

DISCLAIMERS

WELCOME.

WELCOME.7

SAFETY AND COMPLIANCE

RADIO AND TELEVISION INTERFERENCE

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant

to Part 15 of the Federal Communications Commission (FCC) rules. These limits are designed to

provide reasonable protection against harmful interference in a residential installation. This equipment

generates, uses and can radiate radio frequency energy and, if not installed and used in accordance

with the instructions, may cause harmful interference to radio communications. However, there is no

guarantee that interference will not occur in a particular installation. If this equipment does cause harmful

interference to radio or television reception, which can be determined by turning the equipment o and on,

the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and the receiver.

• Connect the equipment to an outlet on a circuit dierent from that to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

You may also ﬁnd helpful the following booklet, prepared by the FCC: “How to Identify and Resolve

Radio-TV Interference Problems.” This booklet is available from the U.S. Government Printing Oce,

Washington, D.C. 20402.

Changes and modiﬁcations not expressly approved by the manufacturer or registrant of this equipment

can void your authority to operate this equipment under FCC rules.

MANUFACTURER

MakerBot Industries, LLC

One MetroTech Center, 21st Floor

Brooklyn, NY 11201

347.334.6800

WIRELESS SPECIFICATIONS

Frequency

WLAN RF

Frequency Range Protocol Antenna Type

Antenna

Speciﬁcations

2.4 GHz 2.412 - 2.472 GHz 802.11 b/g/n

Taoglas, part #

FX831.07.0100C

2.5 dBi in the 2.4

GHz band

WELCOME.8

SAFETY AND COMPLIANCE

Safety alert symbols precede each safety message in this manual. These symbols indicate

potential safety hazards that could harm you or others or cause product or property damage.

Warning: The MakerBot Replicator Z18 generates high temperatures. Always allow

the MakerBot Replicator Z18 to cool down before you reach inside.

Warning: The MakerBot Replicator Z18 includes moving parts that can cause injury.

Never reach inside the MakerBot Replicator Z18 while it is in operation.

Warning: There is a risk of shock. The MakerBot Replicator Z18 is not user serviceable.

Caution: Avoid leaving the MakerBot Replicator Z18 unattended during operation.

If you must leave the MakerBot Replicator Z18 unattended during a print, exercise

caution and follow these guidelines:

• • Verify that the MakerBot Replicator Z18 has started the print and is

operating normally.

• • Ensure that ﬁlament is wound tightly on the spool, free of tangles

• and feeding properly.

• • Monitor your print periodically.

• • If possible, monitor your print via the on-board camera.

•

Caution: Two people are required to li the MakerBot Replicator Z18. Do not li

alone. To prevent injury, li with your legs, not your back.

Caution: Do not print using materials that have not been approved by MakerBot for

use with the MakerBot Replicator Z18. Refer to the Speciﬁcations section on page 61

for more information.

WELCOME.9

Caution: The socket outlet must be located near the machine and must be

easily accessible.

Caution: In case of emergency disconnect the MakerBot Replicator Z18 from

the socket outlet.

Caution: The MakerBot Replicator Z18 melts plastic during printing. Plastic odors

are emitted during this operation. Make sure to set up the MakerBot Replicator Z18

in a well-ventilated area.

Caution: Never remove the Smart Extruder from your MakerBot Replicator Z18 or turn

o the MakerBot Replicator Z18 during or immediately aer printing. Always allow the

Smart Extruder to cool completely before removing it from the MakerBot Replicator

Z18 or turning o your 3D printer.

Caution: Do not look directly at any operating LED component.

SAFETY AND COMPLIANCE

WELCOME.10

ABOUT THE MAKERBOT REPLICATOR Z18

The MakerBot Replicator Z18 makes solid, three-dimensional objects out of melted

MakerBotPLA Filament. First, use MakerBot Desktop to translate 3D design ﬁles into

instructions for theMakerBot Replicator Z18. Then transfer those instructions to the

MakerBot Replicator Z18 via USB drive, USB cable, ethernet, or Wi-Fi.

The MakerBot Replicator Z18 will melt MakerBot PLA Filament and squeeze it out onto

the build plate in thin lines to build your object layer by layer. With the huge build volume

of the MakerBot Replicator Z18, this part of the process can take a long time. The method of 3D

printing used by the MakerBot Replicator Z18 is called fused deposition modeling.

HOW IT WORKS
