Data Sheet

Cisco Model EPC3925 8x4 EuroDOCSIS 3.0 Wireless

Residential Gateway with Embedded Digital Voice Adapter

The Cisco® Model EPC3925 8x4 EuroDOCSIS 3.0 Wireless Residential Gateway with

Embedded Digital Voice Adapter (EPC3925) is a high-performance home gateway that

combines a cable modem, two-line digital voice adapter, router and wireless access point

in a single device providing a cost-effective voice and networking solution for both the

home and small office. The EPC3925 provides a faster connection to the Internet by

incorporating eight bonded downstream channels along with four bonded upstream

channels. These bonded channels can deliver downstream data rates in excess of 440

Mbps and upstream data rates in excess of 120 Mbps. That’s up to eight times faster

downloads than conventional single-channel EuroDOCSIS™ 2.0 cable modems.

The EPC3925 is designed to meet EuroPacketCable™ 1.5 and EuroDOCSIS 3.0 specifications, as

well as offering backward compatibility for operation in EuroPacketCable 1.0 and EuroDOCSIS 2.0,

1.1, and 1.0 networks.

Figure 1. Cisco Model EPC3925 8x4 EuroDOCSIS 3.0 Wireless Residential Gateway with Embedded Digital

Voice Adapter (image may vary from actual product and specification)

The EPC3925 integrated router features a Dynamic Host Configuration Protocol (DHCP) server,

Network Address and Port Translation (NAT/NAPT) and a Stateful Packet Inspection (SPI) firewall.

These features allow the user to share a single high-speed public Internet connection as well as

share files and folders between devices in the home network by attaching multiple wired and

wireless devices in the active home or office to the wireless residential gateway.

Consumer-friendly features like Wireless Protected Setup (WPS) and user-configured Parental

Control can protect the home network from unwelcome intruders and family members from access

to undesirable websites.

Data Sheet

Features

EuroDOCSIS

● Compliant with EuroDOCSIS 3.0, 2.0, 1.1, and 1.0 standards along with EuroPacketCable

specifications to deliver high-end performance and reliability

Connections

● Four 10/100/1000BASE-T Ethernet ports to provide wired connectivity

● High-performance broadband Internet connectivity to energize your online experience

● 802.11n, single band 2.4 GHz 2x2 Wireless Access Point (WAP) with four Service Set

Identifiers (SSIDs) or optional Dual-Band 2.4/5 GHz 2x2 non-concurrent radio

● WPS, including a push-button switch to activate WPS for simplified and secure wireless

setup

● Two RJ-11 telephony ports for connecting to in-home wiring or directly to conventional

telephones or fax machines

Design and Function

● Attractive, compact design and versatile orientation to stand vertically, lie flat on the desktop

or shelf, or mount easily on a wall

● Dual color LED status indicators on the front-panel provide an informative and easy-to-

understand display that indicates the cable modem operational status

● TR-068 compliant color-coded interface ports and corresponding cables simplify installation

and setup

Management

● User-configurable Parental Control blocks access to undesirable Internet sites

● Advanced firewall technology deters hackers and protects the home network from

unauthorized access

● Allows automatic software upgrades by your service provider

Software and Documentation

● CD-ROM containing user guide

Data Sheet

Figure 2. Cisco Model EPC3925 Front Panel (image may vary from actual product and specification)

Table 1. Front Panel Features

Feature

Description

Indicators

Power, DS, US, Online, Ethernet, USB, Wireless Link, Wireless Setup, Tel1, Tel2

Color

Black, black lens, silver text

Branding

Cisco and model number

Figure 3. Cisco Model EPC3925 Back Panel (image may vary from actual product and specification)

Table 2. Back Panel Features

Feature

Description

POWER SWITCH

Switches power to the unit (power switch provided only on products carrying the CE mark)

POWER

Connector Color: Black

Connects modem to the DC output of the AC power adapter

MAC ADDRESS LABEL

Displays the MAC address of the cable modem

TELEPHONE 1 and 2

Color: Gray

RJ-11 telephone ports connect to home telephone wiring and to conventional telephones or fax

machines

USB

Color: Blue

Type 2 USB 2.0 port connects to a USB port on a printer or another USB device

ETHERNET (1 – 4)

Connector Color: Yellow

Four RJ-45 Ethernet ports connect to the Ethernet port on your PC or your home network

CABLE

Connector Color: White

F-connector connects to an active cable signal from your service provider

RESET

Power cycles the EPC3925

WIRELESS SETUP

Activates WPS, which allows you to add wireless devices to the wireless network of the

residential gateway

ANTENNA (internal)

(2) internal antennas provide a communication connection for the built-in 802.11n wireless

Data Sheet

Product Specifications

Table 3. Product Specifications

Specification

Value

Voice

Call Signaling Protocol

● MGCP/NCS including configurable IPsec encryption

● Configurable to support RFC 2833 event signaling

● Supports Bell103 detection: Improves alarm panel and Point of Sale (POS) interoperability

by optimizing DSP for Bell103 protocol

● Software upgradeable to support Session Initiation Protocol (SIP)

● The following SIP standards are supported

◦ RFC 2617 HTTP Authentication: Basic and Digest Access Authentication

◦ RFC 2833 RTP Payload for DTMF Digits, Telephony Tones and Telephony Signals

◦ RFC 2976 The SIP INFO Method

◦ RFC 3261 SIP: Session Initiation Protocol

◦ RFC 3262 Reliability of Provisional Responses in Session Initiation Protocol

◦ RFC 3263 Session Initiation Protocol: Offer / Answer Model with the Session Description

Protocol (SDP)

◦ RFC 3264 Session Initiation Protocol (SIP): Locating SIP Servers

◦ RFC 3265 Session Initiation Protocol (SIP) - Specific Event Notification

◦ RFC 3420 Internet Media Type message/sipfrag

◦ RFC 3428 Session Initiation Protocol (SIP) for Instant Messaging

◦ RFC 3489 STUN - Simple Traversal of User Datagram Protocol (UDP) Through Network

Address Translators (NATs)

◦ RFC 3515 The Session Initiation Protocol (SIP) Refer Method

◦ RFC 3842 A Message Summary and Message Waiting Indication Event Package for the

Session Initiation Protocol (SIP)

◦ RFC 3892 The Session Initiation Protocol (SIP) Referred-By Mechanism

◦ RFC 3903 Session Initiation Protocol Extension for Event State Publication

◦ Draft-ietf-mmusic-sdescription-09 Session Description Protocol Security Descriptions for

Media Streams

◦ Draft-ietf-mmusic-sdp-new-24 SDP: Session Description Protocol Replacement for RFC

2327

◦ Draft-ietf-sip-replaces-02 The Session Initiation Protocol (SIP) "Replaces" Header

◦ Draft-ietf-sip-session-timer-08 The SIP Session Timer

◦ Draft-ietf-sipping-cc-transfer-01 Session Initiation Protocol Call Control – Transfer

◦ Draft-ietf-sipping-realtimefax-01 SIP Support for Real-time Fax: Call Flow Examples and

Best Current Practices

◦ Draft-johnston-sipping-rtcp-summary-07 SIP Service Quality Reporting Event

◦ Draft-rosenberg-sipping-acr-code-00 Rejecting Anonymous Requests in the Session

Initiation Protocol (SIP)

Basic Configuration

(per line)

● SIP Signaling Port (local receive and source port)

● SIP Registrar

● SIP Proxy

● SIP Outbound Proxy

● Username

● Password

● Authentication name

Provisioning Modes

● Basic, Secure, Hybrid provisioning

● Full EuroPacketCable secure provisioning

● Kerberos support with NVRAM ticket caching

● Configurable EuroPacketCable-lite (MTA config file provisioning without security)

● Configurable for non-EuroPacketCable (MTA configuration using EuroDOCSIS config file)

Data Sheet

Specification

Value

Voice (continued)

Voice CODEC support

Negotiate CODEC to use based on ordered list

CODECs

Standard: G.711, T.38 Fax Relay, iLBC and BV16

Software upgradeable to support other CODEC combinations including:

● G.711 and G.728

● G.711 and G.729

● G.711 and G.729 a/e

● G.711 and BV16 and BV32 (High fidelity – near CD quality)

● G.711 and G.723

● G.711 and G.726

Line Diagnostics

GR-909

CODEC Packetization

Levels

10, 20, or 30 mS

CODEC Synchronization

CODEC synchronization to UGS time clock allows slip-free end-to-end sync to PSTN clock

(minimizes frame slips that can cause Fax/Analog Modem call failures)

CODEC Encryption

Configurable to support AES-128 encryption or no encryption modes

Hearing Impaired Services

Support

TDD support including detection of V.18 including Annex A

Fax and Analog Modem

support

DSP based Modem/Fax Tone detection and support for Voice Band Data Mode with

auto-CODEC negotiation and auto-control of echo canceller, jitter buffer, and voice activated

detection (VAD)

Jitter Buffer Support

Adaptive dynamically controlled

Latency Control

Configurable min / max jitter buffer size

Audio Gain Levels

Independently configurable transmit and receive audio gains

Silence Suppression

Configurable VAD with comfort noise generation

Packet Loss Concealment

ANSI T1.521-1999

Call Connection Quality

Monitoring

RTCP, RFC 1889, RFC 1890, SNMP MIB for last call quality statistics

Dialing Modes

DTMF and configurable pulse dial support

DTMF Relay

RFC 2833 including fast (40mS) DTMF Relay for alarm system signaling compatibility

Layer 2 Quality of Service

● Full EuroPacketCable secure DQOS with GateID including UGS and UGS/AD

● DQOS Lite support including UGS and UGS/AD

Layer 3 Quality of Service

Configurable DiffServe/TOS support for Signaling, RTP, and RTCP flows

Payload Header

Suppression (PHS)

● Supported for RTP and RTCP packet flows to reduce per-call network bandwidth

● Advanced support for Dynamic Payload Header Suppression using Propane Technology

Management

SNMPv3, SNMPv2, Telnet with configurable user ID and password, internal log, and external

Syslog support

Echo Cancellation

● G.168 with extended echo tail support

● 32 mS max tail length

VAD

Voice activity detection

CNG

Comfort noise generation

Voice band data

Machine tone detection used to auto switch to data optimized CODEC configuration

T.38 Fax

Supports V.29 and V.17 Modem

Data Sheet

Specification

Value

Voice (continued)

Call Feature Support

● Caller ID

● Call Waiting with Caller ID

● Cancel Call Waiting

● Call Conferencing (3-way calls)

● Configurable Hook-Flash Support

● Distinctive Ringing (Configurable for up to 11 ring patterns per phone line)

● Ring Splash

● Stutter Dial Tone

● Off hook Warning Tone

● Open Switch Interval support to enhance answering machine compatibility

● Configurable Star Codes

● Euro/US Hook-Flash Type

● Call Transfer

● Message Waiting Indicator

● Warm Line

● Call Forwarding Unconditional

● Call Forwarding on Busy

● Call Forwarding No Answer

● Call Return

● Redial Call

● Automatic Redial

● Other call features available with compliant CMS or gateway

Networking (non-call)

Services

● Known Good Proxy

● Proxy Failover

● Registration Control

● UDP, TCP

● TLS

● DNS

● DQoS-lite

● STUN

● Static NAT

● NAT Keep Alive

SIP Header Control

● User-Agent Header Control

● Server Header Control

● Accept Language Header Control

● Proxy Require Header Control

● FQDN in URI Control

● To-tag Matching Control

● Escape Star Character in URI Field

Administrative Features

● Call Data Record

● Call Statistics Agent

● Debug Console Logging

● Debug Logger

Telephone Ring Loading

Full 5 REN support on each phone line (10 REN total)

Ring Signal

Configurable balanced ring with configurable DC offset

Max Phone Line Distance

Supports up to 1000 ft of AWG26 wire (0.4mm) on each phone line. Supports operation with

typical in-home telephone wiring

Country-Specific

Telephone Parameters

Supported

Australia, United States, Japan, United Kingdom, Germany, France, Belgium, Netherlands,

Finland, Italy, Switzerland, Sweden, Denmark, Brazil, Poland, Czech, Hungary, Romania, ETSI

101 909-18

IPV6

dual IPV4/IPV6

CM and EMTA

Data Sheet

Specification

Value

Residential Gateway

Gateway Configuration

Management

● TR-069 and subset of TR-098 data model (optional)

● Extensive custom SNMP MIB for the Gateway

● Provisioning with XML and/or with SNMP

● HNAP server 1.2+

ICSA (Independent

Computer Security

Association) Firewall

Compliant

● Web filtering: Pop-ups, Cookies, Java & ActiveX scripts

● Intrusion detection/prevention: WAN ping blocking, IP fragment blocking, Port scan

detection, TCP Port Probe, UDP Port Probe

● DoS Protection: inbound, outbound, WAN interface, LAN interface, SYN flood, Ping of

Death, Smurf, Bonk, Jolt, Land, Nestea, Newtear, Syndrop, Teardrop, WinNuke/OOBNuke

(Invalid TCP urgent pointer), x1234, Saihyousen , Oshare, ARP flood, TCP Hijacking,

Christmas Tree, SYN/FIN (jackal), BackOffice (UDP 32337), NetBus, ICMP Flowding,

● IP Address, Port Number, MAC address filtering

● TCP flags, ICMP types fragmentation

● Connection Creation and Teardown

● Timestamps and Payload Modification

Parental Controls

● Per-User Policies

● Keyword blocking

● Domain name blocking

● Time of day filters

● MAC Address Filtering

Advanced Event Logging

● Filtering Activity

● Session Tracking

● User Notification via E-mail Alert and SNMP Traps

Routing Features

● NAPT, NAT, and Pass-through (layer 2) Operational Modes

● RFC3489 (STUN) "Port-restricted cone NAT" behavior

● RIP v1/v2, with MD5

● Static Routes

● Port Forwarding

● Port Triggering

● UPnP IGD 1.0

● IPSec Pass-through

● L2TP Pass-through

● PPTP Pass-through

● ALG support: mIRC, PIRCH, MS NetMeeting, Net2phone, AOL and MSN Messenger,

Yahoo Messenger, Go2Call, Hotline Server, Visual IRC, CuSeeme, AT&T Instant,

Messenger Anywhere, Active Worlds, Buddy Phone Calista IP Phone, Delta Three PC to

Phone, Dial Pad, Dwyco Video Conferencing, OrbitRC, Xircon, Netscape Chat, FTP,

H.323, ICQ

Wireless Access Point

802.11 b/g/n

● 2x2 2.4 GHz or optional 2x2 2.4 GHz/5 GHz Dual-Band, non-concurrent, wireless access

point

● (2) Internal Antennas

● Wi-Fi Compliant Security (WPA2-Enterprise, WPA2-PSK, WPA-Enterprise, WPA-PSK,

WEP)

● WMM-QoS (Wireless Multi Media - Quality of Service)

● WMM Power Save

● WPS

● Wireless Bridging - WDS (Wireless Distribution System) – allows connection to “Range

Extender Products”

● RADIUS Authentication (Client, EAP-TLS, EAP-TTLS, EAP-PEAP, EAP-MD5)

● MBSSID (4 SSIDs with unique NAT scopes)

● Wi-Fi "Hot Spot" support (Static DHCP IP Scope over tunnel)

Data Sheet

Specification

Value

RF Downstream

Operating Frequency

Range

108 to 1002 MHz

Tuner Frequency Range

108 to 1002 MHz

Tuner

(2) Frequency agile block tuners, 32 MHz bandpass each

Demodulation

8 demodulators, 4 per tuner, each demodulator; 64 QAM or 256 QAM

Maximum Data Rate

8 downstream channels, each 8 MHz channel:

● 55.62 Mbps for 256 QAM and 41.71 Mbps for 64 QAM

Bandwidth

8 or 6 MHz

Operating Level Range

+43 to +73 dBµV for 64 QAM

+47 to +77 dBµV for 256 QAM

Input Impedance

75 ohms

RF Upstream

Operating Frequency

Range

5 to 65 MHz

Transmitter Frequency

Range

5 to 65 MHz

Upstream Transmission

4 upstream channels

Modulation

QPSK, 8 QAM, 16 QAM, 32 QAM, 64 QAM / ATDMA, 128 QAM / SCDMA

Maximum Data Rate per

channel

Channel Raw

Modulation Bandwidth (MHz) Data Rate (Mbps)

QPSK 1.6 2.56

16 QAM 1.6 5.12

QPSK 3.2 5.12

16 QAM 3.2 10.2

32 QAM 3.2 12.8

64 QAM 3.2 15.4

16 QAM 6.4 20.5

32 QAM 6.4 25.6

64 QAM 6.4 30.7

Bandwidth

200 kHz to 6.4 MHz

Maximum Operating Level

TDMA

SCDMA

Modulation One Channel 2 Channels 3 or 4 Channels

QPSK +121 dBµV +118 dBµV +115 dBµV

8 QAM +118 dBµV +115 dBµV +112 dBµV

16 QAM +118 dBµV +115 dBµV +112 dBµV

32 QAM +117 dBµV +114 dBµV +111 dBµV

64 QAM +117 dBµV +114 dBµV +111 dBµV

QPSK +116 dBµV +113 dBµV +113 dBµV

8 QAM +116 dBµV +113 dBµV +113 dBµV

16 QAM +116 dBµV +113 dBµV +113 dBµV

32 QAM +116 dBµV +113 dBµV +113 dBµV

64 QAM +116 dBµV +113 dBµV +113 dBµV

128 QAM +116 dBµV +113 dBµV +113 dBµV

Electrical

Input Voltage

15 VDC

Power Consumption

(modem module)

~ 17 Watts

Data Ports

GigE (Auto-negotiate with Auto-MDIX): RJ-45 Ethernet (4)

USB 2.0: USB Type 2 (1)

Female F-Type

Output Impedance

75 ohms

Data Sheet

Specification

Value

Mechanical

Dimensions (H x D x W)

4.5 cm x 14.5 cm x 17.6 cm (1.8 in. x 5.7 in. x 6.9 in.)

Weight

0.430 kg (15.17 oz.)

Operating Temperature

-0˚ to 40˚C (32˚ to 104˚F)

Operating Humidity

0 to 95% RH non-condensing

Storage Temperature

-20˚ to 70˚C (-4˚ to 158˚F)

Standards and Approvals

Designed to meet with the

following standards

EuroDOCSIS 3.0, EuroPacketCable 1.5

IEEE 802.11n

WPA2, WPA and WEP

WMM, WPS

Regulatory Compliance

Regulatory and Safety

Approvals

As required per country where the EPC3925 will be used

Ordering Information

Table 4. Ordering Information

Description

Part Number

5-65/88-1002 MHz Diplex Filter

16 MB Flash x 64 MB DRAM Memory Configuration (Standard Configuration)

EPC3925 EuroDOCSIS 3.0 8x4 Wireless Residential Gateway with Embedded Digital Voice Adapter.

Includes:

● 802.11n Wireless Access Point, Single Band, 2x2, 2.4 GHz

● USB 2.0 host port

● 230 VAC / 50-60 Hz, 15 VDC / 1.5 A wall-mount linear-switching power supply, Europe

● Ethernet cable

● CD-ROM containing user guide

Europe

4031761

EPC3925 EuroDOCSIS 3.0 8x4 Wireless Residential Gateway with Embedded Digital Voice Adapter.

Includes:

● 802.11n Wireless Access Point, Single Band, 2x2, 2.4 GHz

● USB 2.0 host port

● 230 VAC / 50-60 Hz, 15 VDC / 1.5 A wall-mount linear-switching power supply, Europe

● Ethernet cable

● CD-ROM containing user guide

Europe (Customer-specific configuration)

4034442

EPC3925 EuroDOCSIS 3.0 8x4 Wireless Residential Gateway with Embedded Digital Voice Adapter.

Includes:

● 802.11n Wireless Access Point, Dual Band, non-current, 2x2, 2.4 GHz or 5 GHz

● USB 2.0 host port

● 230 VAC / 50-60 Hz, 15 VDC / 1.5 A wall-mount linear-switching power supply, Europe

● Ethernet cable

● CD-ROM containing user guide

Europe (Customer-specific configuration)

4038904

EPC3925 EuroDOCSIS 3.0 8x4 Wireless Residential Gateway with Embedded Digital Voice Adapter.

Includes:

● 802.11n Wireless Access Point, Dual Band, non-current, 2x2, 2.4 GHz or 5 GHz

● USB 2.0 host port

● 230 VAC / 50-60 Hz, 15 VDC / 1.5 A wall-mount linear-switching power supply, Europe

● No Ethernet cable

● CD-ROM containing user guide

Europe (Customer-specific configuration)

4040270

Data Sheet

Description

Part Number

5-65/88-1002 MHz Diplex Filter (continued)

16 MB Flash x 64 MB DRAM Memory Configuration (Standard Configuration)

EPC3925 EuroDOCSIS 3.0 8x4 Wireless Residential Gateway with Embedded Digital Voice Adapter.

Includes:

● 802.11n Wireless Access Point, Single Band, 2x2, 2.4 GHz

● USB 2.0 host port

● 230 VAC / 50-60 Hz, 15 VDC / 1.5 A wall-mount linear-switching power supply, Europe

● Ethernet cable

● CD-ROM containing user guide

Europe (Customer-specific configuration)

4038178

EPC3925 EuroDOCSIS 3.0 8x4 Wireless Residential Gateway with Embedded Digital Voice Adapter.

Includes:

● 802.11n Wireless Access Point, Single Band, 2x2, 2.4 GHz

● USB 2.0 host port

● 230 VAC / 50-60 Hz, 15 VDC / 1.5 A wall-mount linear-switching power supply, Europe

● Ethernet cable

● CD-ROM containing user guide

Europe (Customer-specific configuration)

4038015

EPC3925 EuroDOCSIS 3.0 8x4 Wireless Residential Gateway with Embedded Digital Voice Adapter.

Includes:

● 802.11n Wireless Access Point, Single Band, 2x2, 2.4 GHz

● USB 2.0 host port

● 230 VAC / 50-60 Hz, 15 VDC / 1.5 A wall-mount linear-switching power supply, Europe

● Ethernet cable

● CD-ROM containing user guide

Europe (Customer-specific configuration)

4039647

EPC3925 EuroDOCSIS 3.0 8x4 Wireless Residential Gateway with Embedded Digital Voice Adapter.

Includes:

● 802.11n Wireless Access Point, Dual Band, non-current, 2x2, 2.4 GHz or 5 GHz

● USB 2.0 host port

● 230 VAC / 50-60 Hz, 15 VDC / 1.5 A wall-mount linear-switching power supply, Europe

● Ethernet cable

● CD-ROM containing user guide

Europe (Customer-specific configuration)

4040270

EPC3925 EuroDOCSIS 3.0 8x4 Wireless Residential Gateway with Embedded Digital Voice Adapter.

Includes:

● 802.11n Wireless Access Point, Dual Band, non-current, 2x2, 2.4 GHz or 5 GHz

● USB 2.0 host port

● 240 VAC / 50-60 Hz, 15 VDC / 1.5 A wall-mount linear-switching power supply, Australia

● Ethernet cable

● CD-ROM containing user guide

Australia (Customer-specific configuration)

4031762

EPC3925 EuroDOCSIS 3.0 8x4 Wireless Residential Gateway with Embedded Digital Voice Adapter.

Includes:

● 802.11n Wireless Access Point, Dual Band, non-current, 2x2, 2.4 GHz or 5 GHz

● USB 2.0 host port

● 240 VAC / 50-60 Hz, 15 VDC / 1.5 A wall-mount linear-switching power supply, Australia

● Ethernet cable

● CD-ROM containing user guide

Australia (Customer-specific configuration)

4035200

EPC3925 EuroDOCSIS 3.0 8x4 Wireless Residential Gateway with Embedded Digital Voice Adapter.

Includes:

● 802.11n Wireless Access Point, Single Band, 2x2, 2.4 GHz

● USB 2.0 host port

● 100-240 VAC / 50-60 Hz, 15 VDC / 1.5 A wall-mount linear-switching power supply, UK

● Ethernet cable

● CD-ROM containing user guide

4034440

Altri manuali per EPC3925

Indice

Altri manuali Cisco Portale

Cisco

Cisco DDR2201 Series Istruzioni operative

Cisco

Cisco SPA3000 Manuale utente

Cisco

Cisco Linksys WAG54G2 Manuale utente

Cisco

Cisco LINKSYS RFC 2364 Manuale utente

Cisco

Cisco Linksys SPA3102 Manuale utente

Cisco

Cisco DPC3941 Manuale utente

Cisco

Cisco ASR 5x00 Home eNodeB Manuale di istruzioni

Cisco

Cisco DPC2425 Manuale utente

Cisco

Cisco IG21-VZ-K9 Manuale utente

Cisco

Cisco IG21 Series Manuale utente

Cisco

Cisco Linksys WAG200G Manuale utente

Cisco

Cisco DPC2434 Istruzioni operative

Cisco

Cisco Linksys SPA8000-XU Istruzioni operative originali

Cisco

Cisco DPC2425 Manuale utente

Cisco

Cisco DPC3929CM Manuale utente

Cisco

Cisco ATA 186 Manuale dell'operatore

Cisco

Cisco DPQ2425 Manuale utente

Cisco

Cisco ASR 5x00 Home eNodeB Manuale di istruzioni

Cisco

Cisco 2621XM Manuale utente

Cisco

Cisco DDR2200 Series Istruzioni operative

Cisco

Cisco Small Business SPA8000 Manuale utente

Cisco

Cisco Intelligent Wireless Access Gateway Manuale utente

Cisco

Cisco MERAKI MR66 Manuale utente

Cisco

Cisco ENH900EXT Manuale utente

Manuali Portale popolari di altre marche

LST

LST M500RFE-AS Manuale utente

Kinnex

Kinnex Media Gateway Manuale utente

2N Telekomunikace

2N Telekomunikace 2N StarGate Manuale utente

Mitsubishi Heavy Industries

Mitsubishi Heavy Industries Superlink SC-WBGW256 Manuale utente

ZyXEL Communications

ZyXEL Communications ZYWALL2 ET 2WE Manuale utente

Telsey

Telsey CPVA 500 - SIP Manuale utente

RTA

RTA 460A-NNA4 Scheda tecnica

Shaw

Shaw Gateway HDPVR Manuale utente

ABB

ABB VSN900 Guida rapida

Commander

Commander Pulse Manuale utente

2N Telekomunikace

2N Telekomunikace ATEUS EasyGate 501309E Manuale utente

NETGEAR

NETGEAR C6300BD Manuale utente

Amit

Amit CDW531AM Manuale utente

HMS

HMS Netbiter EasyConnect EC150 Manuale utente

Huawei

Huawei EchoLife HG620 Manuale utente

AT&T

AT&T U-verse 3801 Manuale per l'uso e la cura

Logic IO

Logic IO RTCU MX2 turbo Manuale utente

Suttle

Suttle MediaMAX MXM-521 Manuale utente
