Features

The Cisco Firepower 9300 security appliance is a next generation network and content security platform. Its

modular standalone chassis offers high-performance and flexible I/O options, which enable it to run multiple

security services simultaneously.

The Firepower 9300 runs FXOS and can deploy multiple application types. See Cisco Firepower 4100/9300

FXOS Compatibility for more information about software version support for each component in the Firepower

9300. See Product ID Numbers, on page 33 for a list of the component product IDs (PIDs) associated with

the Firepower 9300.

The following figure shows a fully populated Firepower 9300.

Cisco Firepower 9300 Hardware Installation Guide

Figure 1: Firepower 9300

The following table lists the hardware features of the Firepower 9300.

Table 1: Firepower 9300 Features

DescriptionFeature

• Criteria Common Criteria Certification (CC) for the Network Device

Collaborative Protection Profile (NDcPPv2.1) for ASA 9.12.xand FX-OS

2.6.x

• Federal Information Processing Standards (FIPS) 140-2 on ASA 9.12.x,

FTD 6.4.x, and FX-OS 2.6.x

See the "Security Certifications Compliance" chapter in the Cisco

FXOS CLI Configuration Guide or Cisco FXOS Firepower Chassis

Manager Configuration Guide for the procedure to enable security

modes.

Note

Security standards

certifications

3 RUForm factor

Mount rails included (4-post EIA-310-D rack) with span between front and rear

rails of 24 to 36 in.

Rack mount

Front to rear

Cold aisle to hot aisle

Airflow

Cisco Firepower 9300 Supervisor with eight 10-Gigabit Ethernet ports and two

network module slots for I/O expansion

See Chassis Components, on page 4 for more information about the chassis

Supervisor.

Supervisor

ThreeSecurity module slots

Cisco Firepower 9300 Hardware Installation Guide

Overview

Features

DescriptionFeature

• SM-24—24-physical core CPU security module (NEBS ready)

• SM-36—36-physical core CPU high performance security module

• SM-40—40-physical core CPU Crypto security module (NEBS ready)

• SM-44—44-physical core CPU high performance security module (NEBS

ready)

• SM-48—48-physical core CPU Crypto security module (NEBS ready)

• SM-56—56-physical core CPU Crypto security module

See Security Modules, on page 13 for more information about the security

modules.

Supported security

modules

Two

Located in the Supervisor

Network module slots

• 8-port 10-Gigabit Ethernet SFP+

• 4-port 40-Gigabit Ethernet QSFP+

• 2-port 100-Gigabit Ethernet QSFP28 (double-wide, occupies both network

module slots)

• 2-port 100-Gigabit Ethernet QSFP28

• 4-port 100-Gigabit Ethernet QSFP28

• 2-port 40-Gigabit Ethernet QSFP+ (built-in) with hardware bypass

•6-port 10-Gigabit Ethernet SR/LR fiber SFP+ (built-in) with hardware bypass

You can deploy the Firepower 9300 as a dedicated threat sensor with

hardware bypass network modules.

Note

Supported network

modules

256-GB DDR4 DRAM per security moduleMemory

Up to twenty-four 10-Gigabit Ethernet (SFP+) interfaces; up to eight 40-Gigabit

Ethernet (QSFP+) interfaces with two network modules; up to eight 100-Gigabit

Ethernet (SFP+) interfaces

Maximum number of

interfaces

One Gigabit Ethernet port on the Supervisor

Supports 1-Gb fiber and copper SFPs

Management port

One RJ-45 consoleSerial port

One USB 2.0 Type AUSB port

Displays serial numberPullout asset card

On rear panelGrounding lug

Cisco Firepower 9300 Hardware Installation Guide

Overview

Features

DescriptionFeature

On front panelLocator beacon

On rear panel

The initial Firepower 9300 chassis does not have a power switch.

Note

Power switch

Two

On rear panel

Power supply slots

AC, DC, and HVDC

Do not mix power supply types or wattage.

Note

Power supply types

Yes 1 + 1Redundant power

Four (hot-swappable)

On rear panel

Fan slots

SM-24, SM-36, SM-44—Up to 2.4 TB per chassis (1.2 TB per security module

in RAID 1 configuration)

SM-40, SM-48, SM-56—UP to 4.8 TB per chassis (1.6 TB per security module

in RAID 1 Configuration)

Storage

Chassis Components

The Firepower 9300 chassis contains the following components:

• Firepower 9300 Supervisor—Chassis supervisor module

• Management port

• RJ-45 console port

• USB Type A port

• Eight ports for 1- or 10-Gigabit Ethernet small form-factor pluggable (SFP) ports (fiber and copper)

• Firepower 9300 Security Module—Up to three security modules

• Firepower Network Module—Two single-wide network modules or one double-wide network module

• Two power supply modules (AC or DC)

• Four fan modules

Cisco Firepower 9300 Hardware Installation Guide

Overview

Chassis Components

Power Switch

The initial Firepower 9300 AC chassis has no external power switch. You reset the Firepower 9300 using

CLI commands. To physically power cycle the 9300, you must unplug the power cord and then plug the

power cord back in.

Note

After removing power from the chassis either by moving the power switch to OFF or unplugging the

power cord, wait at least 10 seconds before turning power back ON.

Note

The Firepower 9300 chassis has a standby power switch at the rear of the chassis. It controls both power

supply modules. You must shut down the software applications gracefully before turning the switch to

OFF.

Turning the switch to OFF turns off the main power to the Supervisor and the security modules regardless

of the software status, which can result in the loss of any data in transit and the corruption of data on the

SSDs. You must shut down the software applications gracefully before turning the switch to OFF.

Warning

Graceful Shutdown of the Chassis

You can gracefully shut down the chassis from either the CLI or Chassis Manager.

See the "Powering Off the Firepower 4100/9300 Chassis" topic in the System Administration chapter in

the FXOS CLI Configuration Guide for your software version for the procedure to shut down the chassis

from the CLI. The graceful shutdown usually takes as little as a few seconds to as long as three minutes.

When the System Halted message appears, you can move the power switch on the rear of the chassis

to OFF.

See "Powering Off the Firepower 4100/9300 Chassis" topic in the System Administration chapter in the

FXOS Configuration Guide for your software version for the procedure to shut down the chassis from

the Chassis Manager. After the shutdown is completed, you can move the power switch on the rear of

the chassis to OFF.

When you shut down the chassis, the security modules are automatically shut down.

Graceful Shutdown of the Security Modules

You can shut down the security modules individually from the CLI, the Chassis Manager, or you can

use the power switch on the front of each security module. Push the power button briefly on the front

panel of each security module. When the power button changes to amber, you can move the power switch

on the rear of the chassis to OFF.

Shut the security modules down individually when you are replacing a security module.

You must push the power button on each security module installed in the 9300 chassis. You can have

up to three security modules installed in the chassis.

Note

Cisco Firepower 9300 Hardware Installation Guide

Overview

Chassis Components

See the "Power Off/On an Installed Module/Engine" in the Security/Module/Engine Management chapter

of the FXOS CLI Configuration Guide for your software version for the procedure to shut down the

security modules gracefully using CLI commands from the Supervisor. When you see Oper Power: off

for all slots, you can move the power switch on the rear of the chassis to OFF.

See the "Power Off/On an Installed Security Module/Engine" topic in the Security Module/Engine

Management chapter of the FXOS Configuration Guide for your software version for the procedure to

shut down the security module from the Chassis Manager. After the shutdown is complete, you can move

the power switch on the rear of the chassis to OFF.

Deployment Options

Here are some examples of how you can deploy the Firepower 9300:

• At the core/aggregation layer of a three-tier data center in a high availability configuration.

• As a dedicated multifunction security service within converged infrastructure stacks (vBlock, FlexPod,

for example) at the access layer.

• As a high-performance data center security appliance between the WAN edge and data center core in an

high availability configuration.

• As a leaf that exclusively offers security functions in a spine/leaf data center design.

Package Contents

The following figure shows the package contents for the Firepower 9300. Note that the contents are subject

to change and your exact contents might contain additional or fewer items.

Cisco Firepower 9300 Hardware Installation Guide

Overview

Deployment Options

Altri manuali per Firepower 9300

Indice

Altri manuali Cisco Hardware di rete

Cisco

Cisco Nexus 93180LC-EX Manuale utente

Cisco

Cisco TelePresence Manuale di servizio

Cisco

Cisco CVPN3015-NR - VPN Concentrator 3015 Manuale utente

Cisco

Cisco 5400 Manuale utente

Cisco

Cisco ONS 15454 SDH E1-75 Manuale utente

Cisco

Cisco ONS 15327 Manuale dell'operatore

Cisco

Cisco AIR-BR1410A-A-K9 - Aironet 1410 Wireless... Manuale utente

Cisco

Cisco ASR 9000 Series Manuale utente

Cisco

Cisco Cisco ASA Series Manuale utente

Cisco

Cisco NCS 6008 LCC Manuale di istruzioni

Cisco

Cisco PIX Series Manuale

Cisco

Cisco OL-7822-06 Manuale utente

Cisco

Cisco 5500 Series Manuale utente

Cisco

Cisco 1230AG - Aironet - Wireless Access Point Manuale utente

Cisco

Cisco ONS 15454 M12 Manuale utente

Cisco

Cisco ESR-PRE2 Manuale utente

Cisco

Cisco Network Storage System NSS3000 Series Manuale utente

Cisco

Cisco WEC600N Manuale utente

Cisco

Cisco CX-FEIP-1FX= Installation and con?guration Manuale utente

Cisco

Cisco IPS-4260-K9 - IPS Sensor 4260 Manuale utente

Cisco

Cisco NCS 2002 Manuale di istruzioni

Cisco

Cisco Cisco ONS 15600 SDH Manuale utente

Cisco

Cisco 7246 - uBR Router Manuale utente

Cisco

Cisco CE-507 - Content Engine 507 Manuale utente

Manuali Hardware di rete popolari di altre marche

Matrix Switch Corporation

Matrix Switch Corporation MSC-HD161DEL Manuale utente

B&B Electronics

B&B Electronics ZXT9-IO-222R2 Manuale utente

Yudor

Yudor YDS-16 Manuale utente

D-Link

D-Link ShareCenter DNS-320L Manuale utente

Samsung

Samsung ES1642dc Istruzioni per l’uso

Honeywell Home

Honeywell Home LTEM-PV Istruzioni per il montaggio

evertz

evertz 7700 Series Manuale utente

D-Link

D-Link ShareCenter DNS-343 Manuale utente

Asante

Asante AsanteBridge 1012 Manuale utente

FireBrick

FireBrick FB2700 Manuale utente

Audiovox Electronics

Audiovox Electronics ARWH2T Manuale utente

ADC

ADC DSX-1 Manuale

NetComm

NetComm NF2 Manuale utente

Alcatel-Lucent

Alcatel-Lucent 5620 Manuale utente

Dell EMC

Dell EMC XC6420 Series Manuale utente

Lanner

Lanner NCA-1020A Manuale utente

Allied Telesis

Allied Telesis AT-TN121-A Manuale utente

Arista

Arista CCA-ETM-Q12 Manuale utente
