Clearaudio Concept MC Manuale tecnico

Operation instruction for tonearm counter weight

(concept MM MC /wood with gimbal-mounted bearing)

With the concept MM / MC (Wood) you received a Plug & Play turntable.

However for security reason you will nd the counter weight for the tonearm separately packed.

1. To install the counter weight, please push it with pressure, but also carefully, on the shaft up to

the black marking ring (see picture 1, 2 and 3). Please hold tight the tonearm tube when you push

the counter weight onto the shaft!

Pic. 1: Delivery condition as supplied to

customer (without installed counter weight) Pic. 2: Installing the counter weight

Pic. 3: Final position of the counter weight

2. Please adjust tracking force with the delivered Smart Stylus gauge

For Clearaudio cartridge Moving Magnet (MM) is the tracking force= 2.4 g

For Clearaudio cartridge Moving Coil (MC) is the tracking force = 2.2 g

Operation instruction Smart Stylus gauge:

To adjust the tracking force of the cartridge, please follow the instructions provided:

✓



tracking force too high! tracking force too low!

This position of the diamond

correlates to a tracking force of

20 mN (2.0g).

concept MM/MC Package

© clearaudio electronic GmbH, 2017/08 Made in Germany

Bedienungshinweise für Tonarm Gegengewicht

(concept MM / MC (wood) mit kardanischer Lagerung)

Mit dem concept MM / MC (wood) haben Sie einen Plug & Play Plattenspieler erworben.

Aus Sicherheitsgründen wurde jedoch das Gegengewicht für den Tonarm separat verpackt.

1. Um das Gegengewicht zu montieren, drücken Sie dieses bitte mit etwas Druck, aber dennoch

vorsichtig auf das Tonarmrohr bis zu dem schwarzen Markierungsring (siehe Bild 1, 2 und 3).

Bitte halten Sie den Tonarm fest, wenn Sie das Gegengewicht montieren!

Abb. 1: Lieferzustand

(ohne Gegengewicht) Abb. 2: Montieren des Gegengewichts

Abb. 3: Endgültige Position des Gegengewichts

2. Bitte passen Sie die Auagekraft mithilfe der mitgelieferten Smart Stylus gauge an

Für clearaudio Moving Magnet Tonabnehmer (MM) ist die Auagekraft= 2,4 g

Für clearaudio Moving Coil Tonabnehmer (MC) ist die Auagekraft = 2,2 g

Bedienhinweise Smart Stylus gauge:

Bitte befolgen Sie folgende Hinweise, um die Auagekraft Ihres Tonabnehmers einzustellen.

✓



Auagekraft zu hoch! Auagekraft zu niedrig!

Diese Position der Nadel ent-

spricht einer Auagekraft von 20

mN 2,0g).

concept MM/MC Package

© clearaudio electronic GmbH, 2017/08 Made in Germany
