Coby CETW527 Manuale utente

CETW527

EN ... 01

...

User Manual Manual De Usuario

TWS Earbuds With Charging Case

Auriculares TWS con estuche de carga

User Manual Drop Card

Overview

CETW527 True Wireless Stereo Earbuds

Charging case for the CETW527

Microphone

Type C charging port

Case power indicator Charging Contact

Lid of charging case

Charging

Charging the charging case

EN 01

Left

Earbud

Right

Earbud

Type C

charging port

USB power

source

Flashing blue (Case power indicator)

Steady Blue (Case power indicator)

Charging

Fully charged

Multi-Function Button(MFB)

/Status LED indicator

Charging your earbuds

11 2

EN 02

Notes: To check the charging case’s remaining battery power,

take

the earbuds out of the charging case, then place the earbuds back in

the charging case.

If there is remaining battery power, the case power

indicator will glow blue and indicate the power level. If the case battery

power level is low, it will flash red.

( - Blue light)

Case power indicator

Power level

0~25%

25%~50%

50%~75%

75%~100%

When your earbuds battery is low, the earbuds status indicator will slowly

flash red (with a tone notication). Open the lid of the charging case, then

place the earbuds into the charging case and close the lid to start charging.

Earbuds

Tone notication

Steady red

Slowly flashing red

Off, LED light is off

Low battery

Charging

Fully charged

Off

To power them off manually, press and hold the Multi-Function Button(MFB)

on a single

earbud for 5 seconds.

Powering on/off

Your CETW527 Earbuds will power on automatically when taken out of

the charging case. You can also power them on manually by pressing and

holding the Multi-Function Button(MFB) on both earbuds for 5 seconds.

Your CETW527 Earbuds will power off automatically when placed back

in the charging case.

Powering on

Powering off

Power off tone notication

Flashing blue twice

Power on

tone notication

11 2

EN 02 EN 03

Alternating flashing

red and blue on

both earbuds

Pairing

1. True Wireless stereo connection

Take the earbuds out from the charging case, and bring the two earbuds

next to each other. When the Earbuds are turned on, it will automatically

enter True Wireless stereo pairing mode.

Connected tone notication

Enter True Wireless

stereo pairing mode

When True Wireless Stereo

connection is successful

(the right earbud is con-

nected to the left earbud).

Alternating flashing red and

blue on one earbud, being off

on the other earbud.

EN 04

Alternating flashing red

and blue on both earbuds

Being off on both earbuds

After a successful True Wireless stereo connection, your CETW527 will

automatically enter Bluetooth pairing mode with your media device.

Turn on Bluetooth in your device’s settings and search for “CETW527”, then

tap “CETW527” to connect.

2. Bluetooth connection with your device

The earbuds will automatically be paired with your last sucessfully

connected media device next time they are turned on.

Pairing mode

Connected to a device

(Successfully paired with

your media device).

Connected tone notication

CETW527

Alternating flashing red and

blue on one earbud, being off

on the other earbud.

EN 04 EN 05

Controls

Phone call mode

Music mode

Voice Assistant mode

Quickly press the MFB three times on the

right earbud.

Quickly press the MFB twice on either

earbud.

Press and hold the MFB for 2 seconds on

either earbud.

Press and hold the MFB for 2 seconds on

either earbud.

Press the MFB once on either earbud.

Quickly press the MFB twice on the left

earbud.

Quickly press the MFB twice on the right

earbud.

Quickly press the MFB three times on

the left earbud.

Volume down

Answer/End

a call

Reject a call

Exit

Activiate Siri /

other voice

assistant

Volume up

Play/Pause

Next track

track

EN 06

Troubleshooting

Problem Solution

Your earbuds aren’t

connecting to each

other. The Earbud LED

Indicators on both

earbuds are alternat-

ing between red and

blue lights.

First, reset the earbuds by taking out the

earbuds from the charging base and then

placing them back to check whether they

are connected to each other. If they are not,

open Bluetooth settings in your device and

tap “Forget device” on “CETW527”, then turn

off Bluetooth in your device to manually ini-

tiate the True Wire stereo connection. Please

allow up to 30 seconds to connect if you are

in a public area with interfering signals.

Your earbuds are

connected to each

other, but you cannot

connect to your

device (phone, laptop,

tablet etc.)

Ensure the earbuds are not currently con-

nected to another device. If they are, open

Bluetooth settings on those devices and tap

“Forget device” on “CETW527”. Conrm the

device you would like to pair with is Blue-

tooth enabled, please refer to that device’s

user manual to conrm.

There is no response

in the CETW527

earbuds.

Firstly, check whether the battery power in

earbuds are used up, if they are, charge the

earbuds. If they are not, reset the earbuds

by taking out the earbuds from the charging

base and then placing them back.

You can only hear

sound on one earbud.

Reset the earbuds by taking out the

earbuds from the charging base and then

placing them back.

EN 06 EN 07

Model Number CETW527

Model Name True Wireless Stereo Earbuds

With charge case

Power Input 5 V/1A (Charging case)

Charging time Up to 2 hours (Charging case)

Up to 1.5 hours (Earbuds)

Playtime (Earbuds) Up to 5 hours

Playtime (with charging case) Up to 12 hours

Battery Type Rechargeable Lithium-ion

Driver (full range) 10 mm × 2

Range 10m/33 ft

Bluetooth version V 5.3

Dimension (Charging case) 44 x 44 x 25 mm

1.73 x 1.73 x 0.98 inch

Weight (with charging case) 29.1 g/ 1.03 oz

Specications

Safety Precautions

1. Avoid dropping.

2. Do not disassemble this device.

3. Do not expose this device to rain or moisture or submerge in water.

Ideal temperatures are 0°C to 35°C.

Avoid extreme temperatures.

5. Keep the device away from excessive heat, such as sunshine, re or the like.

6. Do not use the device outdoors during thunderstorms.

7. Use original or certied cables.

Safety Statement

EN 08
