Comset CM770W-6 Manuale utente
CM770W-6 User Manual
1
www.comset.com.au
Dual Modem Dual-Band WiFi Gigabit Router
User Manual
CM770W-6
Comset: 37/ 125 Highbury Rd, Burwood VIC 3125, Australia
CM770W-6 User Manual
2
www.comset.com.au
Table of Contents
1 Product Introduction ··························································································································································5
1.1 Product overview············································································································· 5
1.2 Typical Application Diagram···································································································· 5
1.3 Features····································································································································· 6
2 Hardware Installation·························································································································································8
2.1 Overall Dimensions·················································································································· 9
2.2 Ports·········································································································································· 10
2.3 Powering up the CM770W-6································································································· 11
2.4 SIM/UIM cards ························································································································ 11
2.5 Terminal block ························································································································· 11
2.6 Grounding································································································································ 13
2.7 Power Supply·························································································································· 13
2.8 LED Description······················································································································ 13
3 Software configuration·····················································································································································15
3.1 Overview·································································································································· 15
3.2 How to log into the Router····································································································· 15
3.3 Router status··························································································································· 18
3.3.1 Status overview···················································································································· 18
3.3.2 Network status····················································································································· 20
3.3.3 Firewall status······················································································································ 23
3.3.4 Routes··································································································································· 24
3.3.5 System log···························································································································· 25
3.3.6 Kernel log······························································································································ 25
3.3.7 Reboot log···························································································································· 26
3.3.8 Realtime graphs··················································································································· 26
3.4 System Configuration············································································································· 27
3.4.1 Setup wizard ························································································································ 27
3.4.2 System·································································································································· 30
3.4.3 Password······························································································································ 32
3.4.4 NTP········································································································································ 33
3.4.5 Backup/Restore··················································································································· 34
3.4.6 Upgrade································································································································ 34
3.4.7 Reset····································································································································· 36
3.4.8 Reboot··································································································································· 37
3.5 Services configuration············································································································ 37
3.5.1 ICMP check·························································································································· 37
3.5.2 VRRP ···································································································································· 39
3.5.3 Failover (link backup)·········································································································· 40
3.5.4 DTU······································································································································· 42
3.5.5 SNMP···································································································································· 44
CM770W-6 User Manual
3
www.comset.com.au
3.5.6 GPS (optional) ····················································································································· 46
3.5.7 SMS······································································································································· 48
3.5.8 VPN······································································································································· 51
3.5.8.1 IPSEC································································································································ 51
3.5.8.2 PPTP·································································································································· 53
3.5.8.3 L2TP··································································································································· 56
3.5.8.4 OpenVPN·························································································································· 58
3.5.8.5 GRE tunnel························································································································ 60
3.5.9 DDNS···································································································································· 61
3.5.10 Connect Radio Module····································································································· 63
3.6 Network Configuration··········································································································· 65
3.6.1 Operation Mode··················································································································· 65
3.6.2 Mobile configuration············································································································ 66
3.6.3 SIM Switch···························································································································· 68
3.6.4 LAN settings························································································································· 69
3.6.5 Wired-WAN··························································································································· 74
3.6.6 WiFi Settings························································································································ 74
3.6.6.1 Wifi General configuration ······························································································ 75
3.6.6.2 WiFi Advanced Configuration························································································· 76
3.6.6.3 WiFi Interface Configuration··························································································· 77
3.6.6.4 WiFi AP client···················································································································· 78
3.6.7 Interfaces Overview············································································································ 81
3.6.8 Firewall·································································································································· 82
3.6.8.1 General Settings··············································································································· 82
3.6.8.2 Port Forwards··················································································································· 82
3.6.8.3 Traffic rules························································································································ 83
3.6.8.4 DMZ···································································································································· 88
3.6.8.5 Security······························································································································ 89
3.6.9 Static Routes························································································································ 90
3.6.10 Switch·································································································································· 91
3.6.11 DHCP and DNS················································································································· 92
3.6.12 Diagnostics························································································································· 94
3.6.13 Loopback Interface ··········································································································· 95
3.6.14 Dynamic Routing··············································································································· 95
3.6.15 QoS····································································································································· 97
CM770W-6 User Manual
4
www.comset.com.au
Copyright © COMSET 2018
Comset is a registered trademark of Comset. Other brands used in this manual are trademarks
of their registered holders.
Specifications are subject to change without notice. No part of this manual may be reproduced
without the consent of Comset. All rights reserved.
WARNING: Keep at least a 20 cm distance between the user’s body and the modem
router device.
Address：37/ 125 Highbury Road, Burwood VIC 3125, Australia
Web：
http://www.comset.com.au
Phone: +61 3 9001 9720
Fax: +61 3 9888 7100
CM770W-6 User Manual
5
www.comset.com.au
Chapter 1
1 Product Introduction
1.1 Product overview
The Comset CM770W-6 is a premium grade modem router with two built-in 4G LTE CAT 6
modems that allow backup redundancy (hot swap) between modem 1 and modem 2 to ensure
internet continuity for mission critical applications. With four Gigabit Ethernet ports and
concurrent 2.4GHz and 5GHz dual band WiFi, the CM770W-6 provides a powerful and rapidly
deployable internet solution to commercial customers and small to medium businesses.
The Comset CM770W-6 is an innovative router powered by a Dual Core CPU. It features dual SIM
card slots for backup redundancy, 4 x Gigabit LAN ports for fast wired connections, 1 Gigabit
WAN/LAN port for automatic failover between NBN/ADSL and 4G LTE, as well as a GPIO with four
digital input/output ports. Other features include VPN IPSEC, PPTP (Server and Client), L2TP
and OpenVPN to establish a secure connection over the 3G/4G network.
The innovative design, easy integration and rich built-in features make the CM770W-6 the router
of choice for a wide range of business and commercial applications, including SOHO, SMB,
industrial automation, building automation, security, surveillance, transportation, health, mining
and environmental monitoring.
1.2 Typical Application Diagram
The Comset CM770W-6 3G/4G/4GX Router is suitable for a wide range of machine-to-machine
applications (M2M). A good example is the connection of IP Cameras and M2M devices back
to a server over a secure 4G connection using a secure VPN IPSEC tunnel.
CM770W-6 User Manual
6
www.comset.com.au
1.3 Features
The CM770W-6 supports the following:
Multi-band LTE CAT 6 4G/4GX, DC-HSPA+, HSPA+, HSPA, UMTS
Load balancing between 4G LTE Modem-1, 4G LTE Modem-2 and fixed WAN ADSL/NBN
4 x Gigabit Ethernet LAN RJ45 ports & 1 x Gigabit Ethernet WAN/LAN RJ45 port
Dual-band, dual concurrent WiFi (802.11 a/b/g/n/ac, 2.4Ghz + 5Ghz)
USB3.0 port and Micro SD slot
LTE Advanced with SIM-based auto-carrier selection
9 x SMA standard detachable antennas included: 4 x magnetic base cellular antennas, 4 x
rubber dual band WiFi antennas and 1 x GPS antenna (CM770W-6G model)
Optimised EMC design
TR-069, Web management, SMS control, SSH/Telnet/Command, SNMP
Always on-line: On-line detection and automatic redial
Built-in transient and reverse polarity voltage protection, over-current and over-voltage
protection
CM770W-6 User Manual
7
www.comset.com.au
Wide range power input (5-40VDC)
Dual power input / power failover
Smart power management
Inbuilt GPS/GNSS (CM770W-6G model)
2 x Serial ports
4 x Digital Input ports, that can also be used as Digital Output ports
User friendly set-up wizard for easy configuration and setup
Network traffic real-time graphs
Network Diagnostic Tools (Ping, Traceroute and NSLookup)
Secure guest WiFi to passengers
Advanced security, VPN, and stateful firewall to protect sensitive data
Robust Metal Case
Desktop, Wall-mount and Din-rail mount
CM770W-6 User Manual
8
www.comset.com.au
Chapter 2
2 Hardware Installation
1. Overall Dimensions
2. Accessories
3. Installation
CM770W-6 User Manual
9
www.comset.com.au
2.1 Overall Dimensions
CM770W-6 User Manual
10
www.comset.com.au
2.2 Ports
LAN1-LAN4: LAN RJ45 10/100/1000 Ethernet ports
WAN: WAN RJ45 10/100/1000 Ethernet port
RESET: System reset button
DC: DC power socket. DC5~40V
USB: USB3.0 host port
COM: Serial DB9 port
VCC: DC wire positive pole. DC5~40V
GND: DC wire ground
GND: Serial ground
RX: Serial receive
TX: Serial transmit
RST: Reset
