PC-686(CPCI)-LV

CompactPCI Single Board Computer

For socket 370 CPU (Celeron™, Pentium III™)

With LAN/VGA

User’s Manual

this document may be copied or reproduced in any form by any means

without prior written consent of CONTEC Co., Ltd.

CONTEC Co., Ltd. makes no commitment to update or keep current the

information contained in this document. The information in this

document is subject to change without notice.

All relevant issues have been considered in the preparation of this

document. Should you notice an omission or any questionable item in this

document, please feel free to notify CONTEC Co., Ltd.

Regardless of the foregoing statement, CONTEC assumes no responsibility

for any errors that may appear in this document nor for results obtained by

the user as a result of using this product.

Acknowledgments

IBM/AT and PS/2 are trademarks of International Business Machines

Corporation.

Award is a registered trademark of Award Software International, Inc.

Intel®,Celeron™and Pentium III™are registered trademarks of Intel

Corporation.

Microsoft Windows is a registered trademark of Microsoft Corporation.

All Other product names or trademarks are properties of their respective

owners.

Liability

The obligation of the warrantor is solely to repair or replace the product.

In no event will the warrantor be liable for any incidental or consequential

damages due to such defect or consequences that arise from inexperienced

usage, misuse, or malfunction of this device.

Limited One Year Warranty

CONTEC Industrial CPU board is warranted by CONTEC Co., Ltd. to be

free from defects in material and workmanship for up to one year from the

date of purchase by the original purchaser.

Repair will be free of charge only when this device is returned freight

prepaid with a copy of the original invoice and a Return Merchandise

Authorization to the distributor or the CONTEC group office from which it

was purchased.

This warranty is not applicable for scratches or normal wear, but only for

the electronic circuitry and original boards. The warranty is not

applicable if the device has been tampered with or damaged through abuse,

mistreatment, neglect, or unreasonable use, or if the original invoice is not

included, in which case repairs will be considered beyond the warranty

policy.

How to Obtain Service

For replacement or repair, return the device freight prepaid, with a copy of

the original invoice. Please obtain a Return Merchandise Authorization

Number (RMA) from our Sales Administration Department before

returning any product.

*No product will be accepted by CONTEC group without an RMA

number.

Caution about Battery

Danger of explosion if battery is incorrectly replaced.

Replace only with the same or equivalent type recommended by the

manufacturer.

Dispose of used batteries according to the manufacturer’s instructions.

Table of Contents

PC-686 (CPCI)-LV User’s Manual i

Table of Contents

CHAPTER 1INTRODUCTION......................................................................... 1

1.1 Specification.......................................................................................... 1

1.2 Mechanical & Environmental ............................................................... 2

1.3 Check List ............................................................................................. 3

1.4 Description............................................................................................ 4

1.5 Power Management Features................................................................ 7

1.6 Power Requirements.............................................................................. 9

1.7 Connector & Jumper Location ............................................................ 10

1.8 Block Diagram .................................................................................... 11

CHAPTER 2HARDWARE INSTALLATIONS..................................................... 13

2.1 Installation procedure ......................................................................... 13

2.2 CPU Installation: ................................................................................ 14

2.3 Main Memory Installation: DIMM1, DIMM2, DIMM3....................... 15

2.4 RJ-45 LAN connector: CN1................................................................. 20

2.5 Serial Port connector: CN2.................................................................. 21

2.6 Parallel Port Connector: CN3.............................................................. 23

2.7 PS/2 Mouse & Keyboard stack Connector: CN4 .................................. 24

2.8 USB Connector: CN5 .......................................................................... 24

2.9 VGA Connector: CN6.......................................................................... 26

2.10 LCD Connector: CN7.......................................................................... 27

2.11 CPU FAN Connector: CN8 ................................................................. 28

2.12 Floppy Disk Connector: CN9............................................................... 29

2.13 External Battery Connector: CN10...................................................... 30

2.14 Primary IDE port Connector: CN11.................................................... 30

2.15 CompactPCI connector P2: CN12 ....................................................... 32

2.16 CompactPCI connector P1: CN13 ....................................................... 33

Table of Contents

ii PC-686 (CPCI)-LV User’s Manual

2.17 CompactPCI connector P3: CN14........................................................34

2.18 Reset button: S1 ...................................................................................34

2.19 LED Indicator......................................................................................34

CHAPTER 3 JUMPER SETTING ...................................................................35

3.1 Infrared (IrDA) port: JP1.....................................................................35

3.2 Watchdog Timer output selector: JP2...................................................35

3.3 CN16 RS-232C/RS-422/RS-485 Selector: JP3/JP5...............................36

3.4 RS-422/RS-485 Terminator: JP4..........................................................39

3.5 On board LAN selector: JP6.................................................................39

3.6 DISK ON CHIP Memory Add. Selector: JP7........................................40

3.7 Display Type Setting: JP8.....................................................................40

3.8 CPU frequency ration setting: JP9 .......................................................40

3.9 Clear CMOS Content: JP10 .................................................................41

3.10 External/Internal battery selector: JP11...............................................41

CHAPTER 4CPU BOARD RESOURCES .......................................................43

4.1. I/O MAP...............................................................................................43

4.2. MEMORY MAP...................................................................................44

4.3. DMA Channels.....................................................................................45

4.4. PCI Configuration Space Map .............................................................45

4.5. Interrupters..........................................................................................46

4.6. PCI Interrupters Routing Map .............................................................47

CHAPTER 5SOFTWARE UTILITIES ..............................................................49

5.1. Intel®440BX chipset Driver..................................................................49

5.2. Graphic Driver .....................................................................................50

5.3. LAN Driver ..........................................................................................53

5.4. Watchdog-Timer (WDT) Setting...........................................................54

5.5. Update new version BIOS.....................................................................55

Table of Contents

PC-686 (CPCI)-LV User’s Manual iii

5.6. Hardware Monitor............................................................................... 56

CHAPTER 6BIOS SETUP......................................................................... 65

6.1. Introduction ........................................................................................ 65

6.2. Main Menu.......................................................................................... 68

6.3. Standard CMOS Setup......................................................................... 70

6.4. BIOS Features Setup........................................................................... 72

6.5. Chipset Features Setup........................................................................ 76

6.6. Power Management Setup................................................................... 80

6.7. PnP/PCI Configuration....................................................................... 85

6.8. Defaults Menu..................................................................................... 88

6.9. Integrated Peripherals......................................................................... 89

6.10. Supervisor/User Password Setting .................................................... 92

6.11. Exit Selecting................................................................................... 93

6.12. POST Messages................................................................................ 94

6.13. POST Beep....................................................................................... 94

6.14. Error Messages ................................................................................ 95

6.15. POST Codes....................................................................................101

Table of Contents

iv PC-686 (CPCI)-LV User’s Manual

CHAPTER 1 –Introduction

PC-686 (CPCI)-LV User’s Manual 1

Chapter 1 Introduction

1.1 Specification

-Processor Socket: Socket 370

-Processor: Intel®Celeron™300MHz –566MHz; Pentium III™

(FSB:100MHz) 500MHz –700MHz

-Host Bus: CompactPCI Bus

for PICMG2.0 R2.1 Bus Master is supported till 4 Max.

-Chipset: Intel®440BX

-Cache Size: 128KB L2 cache is integrated in the Celeron™CPU

256KB L2 cache is integrated in the Pentium III™CPU

-Memory: Up to 768MB SDRAM

-Memory Sockets: Three 168-pin DIMM sockets for SDRAM in 8MB,

16MB, 32MB, 64MB, 128MB and 256MB configurations.

-BIOS: Award BIOS, PnP support

Flash EEPROM (256KB) for BIOS update

Power management

Frequency / Voltage control

-Bus Speed: 66MHz/100MHz

-Super I/O: Winbond W83977TF chipset

-Parallel port: One high-speed parallel port, SPP/EPP/ECP mode

-Series Port: Two 16550 UART port, COM2 is RS-232C/RS-422/RS-485

configurable

-Enhanced IDE: One EIDE port, up to 2 IDE devices, support Ultra

DMA 33

-FDD Interface: Two floppy drives (360KB, 720KB, 1.2MB, 1.44MB,

2.88MB, LS-120)

-USB Interface: One stack connector support 2 USB ports

-Watchdog Timer: Software programmable 16 levels, Reset or NMI

(Jumper selectable)

CHAPTER 1 –Introduction

2PC-686 (CPCI)-LV User’s Manual

-Hardware Monitor: Winbond W83781D

-IrDA: One 1x6 Pin-header

-Keyboard connector: PS/2 keyboard connector

-Mouse connector: PS/2 Mouse connector

-VGA Connector: C&T 69000 Controller, 15 pin D-type VGA

Connector

-LCD: C&T 69000 Controller, 41pin VESA Connector (for OEM)

-LAN: Intel 82559 LAN controller, RJ-45 connector

-SSD: DIP socket supports DiskOnChip flash disks (2MB~144MB)

-RTC: battery backup by Lithium Battery (CR2032)

The coin type Lithium battery specification is shown in table

Specification CR2032

Nominal Voltage 3V

Nominal Capacity 220mAh

Nominal Weight 3.1g

1.2 Mechanical & Environmental

-POWER CONSUMPTION

(Pentium III 700MHz)

+5VDC @6.50A Max.

+12VDC @250mA Max.

+3.3VDC @4.00A Max.

(Celeron 566MHz)

+5VDC @4.50A Max.

+12VDC @250mA Max.

+3.3VDC @3.50A Max.

-OPTERATING TEMPERATURE: 0 ~ 60ºC.

-STORAGE TEMPPERATURE: - 40 ~ 80ºC.

-HUMIDITY: 10% to 90%

Indice

Altri manuali Contec Scheda madre

Contec

Contec AIO-121602AL-PCI Manuale utente

Contec

Contec SPI-8450-LLVA Manuale utente

Contec

Contec SPI-8451-LLVA Manuale utente

Contec

Contec Single Board Computer Half-size PICMG 1.3 with LAN, Audio, SATA... Manuale utente

Contec

Contec SCP-8550-LLV Manuale utente

Contec

Contec SIS-8601-LVA Manuale utente

Contec

Contec GCOM-2C2-PCI Manuale utente

Contec

Contec GMB-L3WHL200 Manuale utente

Contec

Contec EmCORE-i612VLS/C400 Manuale utente

Contec

Contec SLC-8550-LVA Manuale utente

Contec

Contec SPI-8150-LLVA Manuale utente

Contec

Contec GMB-C2165-LLVA Manuale utente

Contec

Contec SPI-Q6700-LLVA Manuale utente

Contec

Contec GMB-AQ675-LLVA Manuale utente

Contec

Contec GMB-C2160-LLVA Manuale utente

Contec

Contec GMB-Q7710-LLVA Manuale utente

Contec

Contec ITX-i7435/ATX Manuale utente

Contec

Contec GMB-AQ47000 Manuale utente

Contec

Contec SPI-8550-LLVAS Manuale utente

Contec

Contec SPI-6941-LV Manuale utente

Contec

Contec SBC Series Manuale utente

Manuali Scheda madre popolari di altre marche

DFI

DFI SD170 Manuale utente

ASROCK

ASROCK ROMED8-2T Manuale utente

Asus

Asus P2L97A Manuale utente

Winmate

Winmate IC70 Manuale utente

Asus

Asus MES-B Manuale utente

Grantech

Grantech SYS8F377VGGA-3OMN Manuale utente

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR Manuale utente

Gigabyte

Gigabyte GA-9IVDT Manuale utente

Texas Instruments

Texas Instruments ADS8372EVM Manuale utente

Commell

Commell MS-C73 Manuale utente

IBT Technologies

IBT Technologies MB860 Manuale utente

Nvidia

Nvidia TEGRA DG-04927-001_V01 Manuale utente

Biostar

Biostar M7VIT Bravo Istruzioni per l'uso e l'installazione

Intel

Intel D33217CK Manuale utente

Asus

Asus F1A55-M LX PLUS R2.0 Manuale utente

EPC

EPC EPC9147C Manuale utente

Asus

Asus EX-B760M-V5 D4 Manuale utente

EPOX

EPOX MU-8KHA0010 Manuale utente
