Continental Refrigerator SW60-24M Manuale utente

Utilizing Environmentally Safe, CFC-free R-134a Refrigerant

60" SANDWICH UNIT

REFRIGERATORS

Optional Features & Accessories

Standard Features

• Unique Air Flow Distribution Allows Pan Product to

Maintain 330–410F Being in Compliance with and Certified

Under the ‘98 NSF Standard For Preparation Units.

• Modern, State-of-the-Art Styling

• Performance Rated Refrigeration System Utilizing

Environmentally Safe R-134a Refrigerant

• Easily Serviceable Back Mounted Compressor

• 2" Non-CFC Polyurethane Foam Insulation

• Spring Loaded, Self Closing Door

• Magnetic Snap-In Gasket

• 5" Casters, two with brakes, two without brakes

• Heavy-Duty, Epoxy-Coated Steel Shelves

• Interior Hanging Thermometer

• Full Length Nylon Cutting Board

• Cabinet Construction Consisting of Stainless Steel Front

and Top, Aluminum End Panels, Case Back and Interior

• Non-Corrosive, Plasticized Fin Evaporator Coil

• Completely Enclosed, Vented and Removable Case Back

• Automatic, Energy Saving, Non-Electric Condensate

Disposal

• 1/6 Size Pans, 4" Deep

• 10 ft Cord and Plug Attached

SW60-24M

• Legs • Electric Condensate

• Remote Models R • Pan Opening Sizes

• Stainless Steel End Panels- • Stainless Steel Legs

SA Models • Additional Shelves

• Stainless Steel Interior & • Door Locks

Exterior-SS Models • Single Overshelf

• Stainless Steel Finished Back • Double Overself

in Lieu of Aluminum

• Stainless Steel Roll Out Drawers

in Lieu of Doors-D Models

• SW60-8

• SW60-12

• SW60-16

• SW60-8C

• SW60-12C

• SW60-16C

• SW60-12M

• SW60-18M

• SW60-24M

Models Available

SW60-16-D

(Shown w/optional drawers)

60SAND907

SPECIFICATIONS

DIMENSIONAL DATA

Net Capacity (cu. ft.) 17.0 17.0 17.0 17.0 17.0 17.0 17.0 17.0 17.0

Size Pans 8 12 16 8 12 16 12 18 24

Width, Overall (in.) 60 60 60 60 60 60 60 60 60

Depth,

(incl. Hdls.& Bumpers) (in.)

31 31 31 31 31 31 31 31 31

Depth, Body Only

(Less Door(s)(in.)

Depth, Cutting Board

(Std. Top)

12 12 12 19 19 19 10 10 10

Height, Overall

(incl. 5" Casters) (in.)

42 3/842 3/842 3/842 3/842 3/842 3/842 3/842 3/842 3/8

Shelf Area (sq. ft.) 8.1 8.1 8.1 8.1 8.1 8.1 8.1 8.1 8.1

No. of Shelves 2 2 2 2 2 2 2 2 2

No. of Doors 2 2 2 2 2 2 2 2 2

Condensing Unit Size (H.P.)

Refrigerant R134a R134a R134a R134a R134a R134a R134a R-134a R-134a

Cabinet Electrical

115/60/1 115/60/1 115/60/1 115/60/1 115/60/1 115/60/1 115/60/1 115/60/1 115/60/1

Amps 8.2 8.2 8.2 8.2 8.2 8.2 8.2 8.2 8.2

Fans 3 3 3 3 3 3 3 3 3

Interior Depth (in.) 20 20 20 20 20 20 20 20 20

Interior Height (in.) 26

Interior Width (in.) 56 56 56 56 56 56 56 56 56

Shipping Weight (lbs.) 309 311 315 315 315 315 319 322 330

Shipping Height (in.) 43

Shipping Length (in.) 68

Shipping Depth (in.) 46 46 46 46 46 46 46 46 46

SW60-8 SW60-12 SW60-16

60" SANDWICH UNIT REFRIGERATORS

A Division of National Refrigeration & A/C Products, Inc.

539 Dunksferry Road Bensalem, PA 19020

(800) 523-7138 Fax: (215) 244-9579

www.continentalrefrigerator.com

Standard Top Side View

FRONT VIEW C -Top Side View

SW60-8 SW60-12 SW60-16 SW60-8C SW60-12C SW60-16C SW60-12M SW60-18M SW60-24M

42 3/8

SW60-8C

SW60-18M

SW60-12M

SW60-16C

SW60-12C

M -Top Side View

SW60-24M
