EXTRA WIDE DISPLAY

REFRIGERATORS

Standard Features

• Modern, State-of-the-Art Styling

• Performance Rated Refrigeration System Utilizing

Environmentally Safe R-134a Refrigerant

• 3" Non-CFC Polyurethane Foam Insulation

• Cam-Action Lift-Off Hinges

• Self-Closing Doors

• Magnetic Snap-In Door Gasket

• Cylinder Lock in Each Door

• Automatic Electric Condensate Evaporator

• 5" Casters

• Heavy-Duty, Epoxy-Coated Steel Shelves

• External Dial Thermometer

• Double-Pane, Tempered Hinged Glass Doors

• Fluorescent Interior lighting

Standard (S/S Front, Aluminum End Panels & Interior)

Suffix SA (S/S Exterior, Aluminum Interior)

Suffix SS (S/S Exterior & Interior)

• Legs

• Stainless Steel Case

Back

• Pan Slide Assemblies

• Increased Refrigeration

Systems

• Stainless Steel Shelves

• Digital Thermometer

• Rehinging of Doors

• Half Door

• Remote

• Pass-Thru

• Shallow Depth

Optional Features & Accessories

Operating with Environmentally Safe, CFC-free R-134a Refrigerant

2420.83

REFRIGERATORS

1RE-GD 2RE-GD

3RE-GD

MODEL MODEL MODEL MODEL

1RE-GD 1RX-GD 2RE-GD 3RE-GD

Reach-In Pass-Thru Reach-In Pass-Thru Reach-In Pass-Thru Reach-In Pass-Thru

DIMENSIONAL DATA

Net Capacity (cu. ft.) 21 21 30 30 50 50 73 73

Width, Overall (in.) 281/2281/2361/4361/457 57 851/2851/2

Depth, Overall (Incl. Hdls.) (in.) 351/239 351/239 351/239 351/239

Depth (Less Door(s) (in.) 32 32 32 32 32 32 32 32

Depth (Doors(s) Open 90°) (in.) 58 84 66 100 58 84 58 84

Clear Door Width (in.) 217/8217/8295/8295/8217/8217/8217/8217/8

Clear Full-Door Height (in.) 585/8585/8585/8585/8585/8585/8585/8585/8

Clear Half-Door Height (in.) 271/2271/2271/2271/2271/2271/2271/2271/2

Height, Overall

(Inc. 5" Casters)(in.)

821/4821/4821/4821/4821/4821/4853/4853/4

No. of Full Door(s) 1 2 1 2 2 4 3 6

No. of Half Door(s) 2 4 2 4 4 8 6 12

Shelves 4 4 4 4 8 8 12 12

Shelf Area (sq. ft.) 20.4 20.4 24.4 24.4 40.8 40.8 61.2 61.2

Tray Slide Capacity (Half) 12 ea. 12 ea. 12 ea. 12 ea. 12 ea. 12 ea. 12 ea. 12 ea.

Tray Slide Capacity (Full) 24 ea. 24 ea. 24 ea. 24 ea. 24 ea. 24 ea. 24 ea. 24 ea.

REFRIGERATION DATA

Condensing Unit Size (H.P.) 1/31/31/31/31/21/23/43/4

Capacity (BTU/Hr)* 2560 2560 2810 2810 4010 4010 5930 5930

ELECTRICAL DATA

Cabinet Specifications

115/60/1 115/60/1 115/60/1 115/60/1 115/60/1 115/60/1 115/208-230/60/1 115/208-230/60/1

Feed Wires (Incl. Ground) 3 3 3 3 3 3 4 4

Condensing Unit Specs.

115/60/1 115/60/1 115/60/1 115/60/1 115/60/1 115/60/1 208-230/60/1 208-230/60/1

Total Amperes 10.7 11.0 11.0 11.3 13.6 16.0 12.4 15.9

Cabinet Amperes 3.5 3.8 3.8 4.1 4.1 6.5 5.4 8.9

Defrost Amperes - - - - - - - -

Power Supply Cord yes yes yes yes yes yes no no

SHIPPING DATA

Height – crated (in.) 83 83 83 83 83 83 851/2851/2

Width – crated (in.) 315/8315/842 42 64 64 90 90

Depth – crated (in.) 42 42 42 42 42 42 42 42

Volume – crated (cu.ft.) 63 63 84 84 129 129 187 187

Weight Std – crated (lbs.) 315 360 430 435 530 610 740 855

Weight SS – crated (lbs.) 375 420 490 495 610 680 855 970

Weight Std – uncrated (lbs.) 215 250 330 335 360 430 530 635

Weight SS – uncrated (lbs.) 275 310 390 395 440 510 645 750

* Rating @ +25°F Evaporator, 90° Ambient

Note: All specifications subject to change without notice.

Note: If the cabinet is located directly against wall and/or under low ceiling,

a minimum clearance of 2" is required.

VLREGD305

SIDE VIEW 1RE-GD

FRONT VIEW

1RX-GD

FRONT VIEW

2RE-GD

FRONT VIEW

3RE-GD

FRONT VIEW

821/4"

281/2"

821/4"

361/4"

821/4"853/4"

851/2"

57"

32"

34"

351/2"

2420.83

REFRIGERATORS

A Division of National Refrigeration & A/C Products, Inc.

539 Dunksferry Road Bensalem, PA 19020

(800) 523-7138 Fax: (215) 244-9579

www.continentalrefrigerator.com

SPECIFICATIONS
