Continental Refrigerator SW72-12 Manuale utente

Utilizing Environmentally Safe, CFC-free R-134a Refrigerant

72" SANDWICH UNIT

REFRIGERATORS

Optional Features & Accessories

Standard Features

• Unique Air Flow Distribution Allows Pan Product to

Maintain 330–410F Being in Compliance with and Certified

Under the ‘98 NSF Standard For Preparation Units.

• Modern, State-of-the-Art Styling

• Performance Rated Refrigeration System Utilizing

Environmentally Safe R-134a Refrigerant

• Easily Serviceable Back Mounted Compressor

• 2" Non-CFC Polyurethane Foam Insulation

• Spring Loaded, Self Closing Door

• Magnetic Snap-In Gasket

• 5" Casters, two with brakes, two without brakes

• Heavy-Duty, Epoxy-Coated Steel Shelves

• Interior Hanging Thermometer

• Full Length Nylon Cutting Board

• Cabinet Construction Consisting of Stainless Steel Front

and Top, Aluminum End Panels, Case Back and Interior

• Non-Corrosive, Plasticized Fin Evaporator Coil

• Completely Enclosed, Vented and Removable Case Back

• Automatic, Energy Saving, Non-Electric Condensate

Disposal

• 1/6 Size Pans, 4" Deep

• 10 ft Cord and Plug Attached

SW72-18

• Legs • Electric Condensate

• Remote Models R • Pan Opening Sizes

• Stainless Steel End Panels- • Stainless Steel Legs

SA Models • Additional Shelves

• Stainless Steel Interior & • Door Locks

Exterior-SS Models • Single Overshelf

• Stainless Steel Finished Back • Double Overself

in Lieu of Aluminum

• Stainless Steel Roll Out Drawers

in Lieu of Doors-D Models

• SW72-12

• SW72-18

• SW72-12C

• SW72-18C

• SW72-18M

• SW72-27M

• SW72-30M

Models Available

SW72-30M

72SAND907

SPECIFICATIONS

DIMENSIONAL DATA

Net Capacity (cu. ft.) 20.6 20.6 20.6 20.6 20.6 20.6 20.6

Size Pans 12 18 12 18 18 27 30

Width, Overall (in.) 72 72 72 72 72 72 72

Depth,

(incl. Hdls.& Bumpers) (in.)

31 31 31 31 31 31 31

Depth, Body Only

(Less Door(s)(in.)

271/2271/2271/2271/2271/2271/2271/2

Depth, Cutting Board

(Std. Top)

12 12 19 19 10 10 10

Height, Overall

(incl. 5" Casters) (in.)

42 3/842 3/842 3/842 3/842 3/842 3/842 3/8

Shelf Area (sq. ft.) 10.2 10.2 10.2 10.2 10.2 10.2 10.2

No. of Shelves 3 3 3 3 3 3 3

No. of Doors 3 3 3 3 3 3 3

Condensing Unit Size (H.P.)

Refrigerant R134a R134a R134a R134a R134a R134a R134a

Cabinet Electrical

115/60/1 115/60/1 115/60/1 115/60/1 115/60/1 115/60/1 115/60/1

Amps 9.0 9.0 9.0 9.0 9.0 9.0 9.0

Fans 4 4 4 4 4 4 4

Interior Depth (in.) 20 20 20 20 20 20 20

Interior Height (in.) 26

Interior Width (in.) 68 68 68 68 68 68 68

Shipping Weight (lbs.) 385 389 398 398 398 414 420

Shipping Height (in.) 43

Shipping Length (in.) 80

Shipping Depth (in.) 46 46 46 46 46 46 46

SW72-12 SW72-18 SW72-12C

72" SANDWICH UNIT REFRIGERATORS

A Division of National Refrigeration & A/C Products, Inc.

539 Dunksferry Road Bensalem, PA 19020

(800) 523-7138 Fax: (215) 244-9579

www.continentalrefrigerator.com

Standard Top Side View

FRONT VIEW C -Top Side View

SW72-12 SW72-18 SW72-12C SW72-18C SW72-18M SW72-27M SW72-30M

42 3/8

SW72-18C

SW72-30M

SW72-27M

SW72-18M

M -Top Side View
