Continental Refrigerator 1RE Manuale utente

2420.83

EXTRA-WIDE

REFRIGERATORS

Utilizing Environmentally Safe, CFC-free R-134a Refrigerant

Standard Features

• Modern, State-of-the-Art Styling

• Performance Rated Refrigeration System

Utilizing Environmentally Safe R-134a

Refrigerant

• 3" Non-CFC Polyurethane Foam Insulation

• Chrome Plated Flow Line Handles

• Cam-Action Lift-Off Hinges

• Self-Closing Doors

• Automatic Interior Lighting

• Magnetic Snap-In Door Gasket

• Cylinder Lock In Each Door

• Automatic Electric Condensate Evaporator

• 5" Casters

• Heavy-Duty, Epoxy-Coated Steel Shelves

• External Dial Thermometer

Standard (S/S Front, Aluminum End Panels &

Interior)

Suffix SA (S/S Exterior, Aluminum Interior)

Suffix SS (S/S Exterior & Interior)

Optional Features & Accessories

REFRIGERATORS

• Stainless Steel or

Black Legs

• Digital Thermometer

• Rehinging of Doors

• Stainless Steel Case

Back

• Half Door Model

• Pan Slide Assemblies

• Remote Model

• Increased

Refrigeration Systems

• Pass-Thru Model

• Shallow Depth Model

• Stainless Steel

Shelves

• Hinged Glass Door

1RX

2RE

1RE

3RE

2420.83

REFRIGERATORS

RE305

A Division of National Refrigeration & A/C Products, Inc.

539 Dunksferry Road Bensalem, PA 19020

(800) 523-7138 Fax: (215) 244-9579

www.continentalrefrigerator.com

1RE 1RX 2RE 3RE

One Section One Section Extra-Wide Two Section Three Section

CHARACTERISTICS Reach-In Pass-Thru Reach-In Pass-Thru Reach-In Pass-Thru Reach-In Pass-Thru

DIMENSIONAL DATA

Net Capacity (cu.ft.) 21 21 30 30 50 50 73 73

Width, Overall (in.) 281/2281/2361/4361/457 57 851/2851/2

Depth, Overall (Incl. Hdls.) (in.) 351/239 351/239 351/239 351/239

Depth (Less Door(s)) (in.) 32 32 32 32 32 32 32 32

Depth (Door(s) Open 90°) (in.) 58 84 66 100 58 84 58 84

Clear Door Width (in.) 217/8217/8295/8295/8217/8217/8217/8217/8

Clear Full-Door Height (in.) 585/8585/8585/8585/8585/8585/8585/8585/8

Clear Half-Door Height (in.) 271/2271/2271/2271/2271/2271/2271/2271/2

Height, Overall (Incl. 5" Casters) (in.) 821/4821/4821/4821/4821/4821/4821/4821/4

Full Door(s) 12122436

Half Door(s) 242448612

Shelves 33336699

Shelf Area (sq. ft.) 20.4 20.4 24.4 24.4 40.8 40.8 61.2 61.2

Tray Slide Capacity (Half) 11 ea. 11 ea. 11 ea. 11 ea. 11 ea. 11 ea. 11 ea. 11 ea.

Tray Slide Capacity (Full) 24 ea. 24 ea. 24 ea. 24 ea. 24 ea. 24 ea. 24 ea. 24 ea.

REFRIGERATION DATA

Condensing Unit Size (H.P.) 1/41/41/41/41/31/31/21/2

Capacity (BTU/Hr)* 1940 1940 2190 2190 2560 2560 4010 4010

ELECTRICAL DATA

Cabinet Specifications

115/60/1 115/60/1 115/60/1 115/60/1 115/60/1 115/60/1 115/60/1 115/60/1

Feed Wires (Incl. Ground) 33333333

Condensing Unit Specs.

115/60/1 115/60/1 115/60/1 115/60/1 115/60/1 115/60/1 115/60/1 115/60/1

Total Amperes 6.9 7.2 7.1 7.4 9.1 9.8 12.4 13.4

Cabinet Amperes 1.6 1.9 1.8 2.1 1.9 2.6 2.9 3.9

Defrost Amperes --------

Power Supply Cord yes yes yes yes yes yes yes yes

SHIPPING DATA

Height – crated (in.) 851/2851/2851/2851/2851/2851/2851/2851/2

Width – crated (in.) 315/8315/842 42 64 64 90 90

Depth – crated (in.) 42 42 42 42 42 42 42 42

Volume – crated (cu. ft.) 63 63 87 87 129 129 181 181

Weight Std – crated (lbs.) 330 360 430 435 560 620 785 875

Weight SS – crated (lbs.) 390 420 490 495 640 690 890 990

Weight Std – uncrated (lbs.) 230 260 330 335 390 450 575 735

Weight SS – uncrated (lbs.) 290 320 390 395 470 530 690 780

*Rating @ +25°F Evaporator, 90° Ambient

Note: If the cabinet is located directly against wall and/or under low

ceiling, a minimum clearance of 2" is required.

Note: All specifications subject to change without notice.

SPECIFICATIONS

SIDE VIEW

1RE FRONT VIEW

3RE FRONT VIEW

1RX FRONT VIEW

2RE FRONT VIEW

85 1/2
