oppertech
Wireless Bluetooth Speaker
Instruction manual
Model WS-701A
Quick Start Guide
Speaker overview: top
Speaker overview: back
Page 1
Speaker overview: front
Connecting with a smartphone by Onetouch (NFC)
Making a call/Receiving a call
AUX input
Battery status on iPhone et iPad
Connecting with a Bluetooth device
Charging your speaker
Listening to music
2014.Coppertech
All
rights
resrved
N°4132945
www.coppertech.fr
[email protected] 231
rue
Saint-Honoré
75001
P
aris
France
Spesifications
NFC
Using SIRI
Play/Pause
Previous track Next track
Volume
up
Volume
down
Charging LED indicator
On/O
switch
Line-in
audio jack
Micro USB charging port
Bluetooth LED indicator
Speaker 1 Speaker 2
Bluetooth compliant.............................................Bluetooth 3.0
Dimensions..............................................................6 cm x 16,3 cm x 4,3cm
Weight........................................................................0,330 kg
Speaker driver.........................................................stereo, 40MM, 4Ohm
Speaker output......................................................5W*2
Operating Frequency Range............................2.4GHz-2.48GHz
Battery capacity....................................................1000mAh
Battery life ..............................................................Up to 10 hours(depending
on the volume and audio content)
Battery charging time..........................................4-5 hours
Operating temperatures....................................0ºC to 45ºC
Bluetooth transmission distance....................Up to 10 meters, measured
in open space. Walls and structures may aect range of device.
Battery Charging voltage..................................5V(1A)
Working voltage...................................................3.3--5V
Interface..................................................................Bluetooth, 3.5MM audio
line-in & line-out jack, Micro USB charging port
To obtain optimum power capacity, the speaker should be charged
using the provided USB cable in your packaging box. To charge the
unit plug the USB cable to the USB port on the back of the speaker.
Charging starts when the unit that is turned o is connected and the
charging LED indicator lights up in red. Charging is completed in
about 4-5 hours and the indicator goes o.
Turn on yourspeaker by switching the button on the back of the
unit to "On", the LED lights should alternate between shining red and
blue. This signal means that the speaker is in "pairing mode”.
Perform the pairing procedure on the Bluetooth device to detect this
speaker. When a list of detected devices appears on the display of the
Bluetooth device, select “WS701A”. Once paired successfully, the
Bluetooth LED indicator lights will turn blue and blink twice every
3 seconds.
If using a device that is NFC (Near Field Communication) enabled,
turn on NFC, then simply touch the speaker on the right side where
the NFC chip lies to make a connection.
Start playback on the Bluetooth device, and adjust the volume.
Set the volume at an appropriate level on the connected device,
and adjust the volume with the VOL –/+ buttons on the unit.
To switch to the previous or next song simply press the Previous and
Next button on the speaker. This will switch to the previous/next
song in the playlist of the Bluetooth device. Press the Play/Pause
button on the speaker to start or pause songs.
You can use the WS-701A as a portable speakerphone for incoming
calls when connected wirelessly via Bluetooth. To answer a call, press
the TALK button and talk as you would with your device if it was on
“speakerphone”The built in microphone will pick up your voice just
like a phone. To end a call, press the TALK button again. To refuse a
call, double press the TALK button . You can re-dial the last number
called by double pressing the TALK button
When the speaker is connected to an iPhone/iPad via Bluetooth,
press and hold the TALK button for 3 seconds to activate the Siri
function on iPhone/iPad. Then talk to the speaker after hearing the
“Siri ” sound. Please note that iPhone/iPad may not be able to
recognize human speech when the speaker is being used in a noisy
environment. Siri may not work if iPhone/iPad is not connected to
the internet. When the Siri conversation is nished, the speaker will
continue playing audio.
To play audio using the audio cable, plug the cable from the audio
device to the“IN” jack on the back of the speaker.
When the speaker is connected to iPhone/iPad via Bluetooth, the
battery status of the speaker can be displayed on the top of the
iPhone/iPad screen, after the Bluetooth symbol. Please note that the
battery status icon can be vertical or horizontal, depending on the
Bluetooth device and its operation system.
-
Coppertech
+
Talk/Siri
IN
ON OFF
