Cornelius MillenniumII 4000 Manuale utente

FEATURES:

MillEnniUM ii 4000

4 Flavor Post-Mix

Juice DisPenser

CATG8677-1111 Juice

• Four product selections plus chilled water

• For use with closed container (BIB) juice packaging

• Unique mixing valve and nozzle provide a quality

drink on every dispense, over a wide range of

juice/drink concentrates

• Large capacity ice bank increases draw capacity,

consistently pouring a cold drink

• Solid state ice bank control

• Easy-to-adjust brixing system controls and maintains

a consistant ﬁnished drink

• Available with new contemporary cabinet design

which is a blend of attractive black plastic and

sturdy stainless steel

• Completely self contained pumping system.

No additional pumps or air supply needed.

• Lighted merchandiser is standard

• Push button or programmable portion controlled

dispensing available

For more information or to place an order, contact your sales representative or authorized distributor.

OUTSIDE THE U.S.A.

Ph: 763.488.8200

Email: [email protected]

IN THE U.S.A.

Ph: 800.238.3600

Fax: 800.258.0255

101 Broadway Street West

Osseo, MN 55369

www.cornelius.com

DESCRIPTION . . . . . . . . . . . . . . . . Millenium II 4000:

115 V / 60 Hz,

1 Phase / 6.1 Amps

Millenium II 4002:

220 V / 50 Hz,

1 Phase / 3 Amps

REFRIGERATION. . . . . . . . . . . . . . 1/3 HP, Hermitically sealed

system (198.4 g) 5.5 oz

R-134A refrigerant

ICE BANK ................... 14 lb

INITIAL PULLDOWN . . . . . . . . . . . 4 hr 30 min

DISPENSER DIMENSIONS . . . . . . 32"H x 14.7"W x 26.2"D

(815 mm x 375 mm x 665 mm)

WEIGHT . . . . . . . . . . . . . . . . . . . . . Operating 175 lb (79.4 kg)

Shipping 110 lb (50 kg)

RECOMMENDED CLEARANCE . . Side: 6" (16 cm)

Top: 18" (46 cm)

WATER CONNECTION . . . . . . . . . 0.645" (0.95 cm) SAE male

ﬂare ﬁtting on dispenser

WATER SUPPLY REQUIREMENTS. . 100 psi (6.8 bar) max

static pressure

20 psi (1.4 bar) min

dynamic pressure

AGENCY LISTINGS . . . . . . . . . . . .

StainleSS Steel Part number DeScriPtion

621056514 Millennium 4 Flavor PB 115 V / 60 Hz

621056515 Millennium 4 Flavor PC 115 V / 60 Hz

621056523 Millennium 4 Flavor PB 230 V / 50 Hz

621056524 Millennium 4 Flavor PC 230 V / 50 Hz

Contact customer service for drawings and dimensions.

TECHniCAl SPECiFiCATiOnS:
