Cosatto NITTY GRITTY YO2 Manuale utente

Important: Keep these

instructions for future reference.

Important safety Information

General:

•The pushchair is suitable for children from birth up to a maximum user weight of 15kg.

•WARNING: Never leave your child unattended.

•WARNING: Ensure that all the locking devices are engaged

before use.

•WARNING: To avoid injury ensure that your child is kept away

when unfolding and folding this product.

•WARNING: Do not let your child play with this product.

•WARNING: This product is not suitable for running or skating.

•WARNING: Always use the restraint system.

•WARNING: Always use the crotch strap in combination with the

waist belt.

•WARNING: To avoid risk of injury from burning, do not place hot

beverage on cup holder.

•Do not use replacement parts or accessories other than those approved by Cosatto.

•A basket is provided for the carriage of 2kg of goods, evenly distributed.

•Any additional load attached to the handle or on the back of the backrest or on the

sides of the vehicle will aect the stability and safety of the vehicle.

•Do not use a platform with this product as it may render the product unsafe.

•Always apply the brake when placing or removing a child from vehicle.

•Never carry a second child on the product.

•This product complies with BS EN 1888:2012.

•Use the seat in the most reclined position for new born babies until they can sit up

unaided.

•Ensure your child wears a correctly tted and adjusted harness at all times. D-rings

are provided for the attachment of a separate safety harness approved to BS EN 13210

should this be required.

Visual language Key:

Refer to warning XX

Correct action

Lock

Unlock

Press and hold

Check

Continue to step XX

Repeat on other side

Incorrect action

Audible sound

Repeat action x times

General action arrow

Parts

1. Chassis

2. Rear wheel x2

3. Front wheel x2

4. Hood

5. Bumper bar

6. Footmu

7. Raincover

8. Raincover bag

9. Cup holder

Replacement Parts:

The replacement parts shown below are available for your product. For UK & Ireland

customers, order through our website: http://www.cosatto.com/service-centre/spares

For customer outside UK & Ireland, contact information for your local distributor can be

found on http://www.cosatto.com/stockists

If you require any further assistance, please contact us at cuddle@cosatto.com

S1: Foam handle

S2: Handle pip

S3: Hood fabric

S4: Hood frame

S5: Headhugger

S6: Chest pads (pair)

S7: Auto lock

S8: Elbow joint badge

S9: Rear wheel

S10: Basket

S11: Harness

S12: Bumper bar

S13: Bumper bar cover

S14: Footmu

S15: Raincover bag

S16: Cup holder

S17: Front wheel

S18: Raincover

S14

S15

S18

S17

S16

S10 S11

S12 S13

Care & Maintenance:

Your pushchair has been designed to meet comprehensive safety standards, and with

correct use and maintenance will give many years of trouble free performance.

The chassis is strong but will weaken should the back wheels be bumped down stairs or

kerbs. Continual impact will cause damage.

If your child wears hard shoes these might damage the soft fabric.

Store your pushchair in a dry, safe place.

Storing a damp pushchair will encourage mildew to form, so after exposure to damp

conditions, dry o with a soft cloth and allow to dry thoroughly before storing.

Do not leave the pushchair in sunlight for prolonged periods - some fabrics may fade.

Regularly inspect the locking devices, brakes, wheels, harness assembly, catches, seat

adjusters, joints and xtures to ensure they are secure and in full working order. They

should move freely at all times.

Cosatto products are designed to operate with minimum maintenance, however regular

lubrication of moving parts will extend the life of your pushchair and make opening and

folding easier.

Should parts of your pushchair become sti or dicult to operate, apply a light

application of a spray lubricant e.g. silicone. Do not use oil or grease.

Wheels are subject to wear and should be replaced if necessary.

Your pushchair should be serviced and reconditioned before using it for a second baby,

or after 18 months, whichever is the sooner.

Hood may be cleaned by sponging lightly using warm water and a mild detergent.

Refer to the wash care label on soft goods for cleaning instruction.

Plastic and metal parts may be sponged clean with warm water and a mild detergent.

Never clean with abrasive, ammonia based, bleach based or spirit type cleaners.

Fitting & Operation information

Please refer to the following diagrams:

Wheels

Fitting

Removing

Pushchair

Opening

Release auto lock (1) then pull the handles upwards (2).

Press down on the locking lever (3) until a‘Click’ is heard and the release arm (4) is locked

in place.

Check the chassis has locked in place.

Brake

Applying

Releasing

Front wheel swivel lock

Applying

Releasing

Harness

Opening

Closing

Adjusting the strap length

Slide the strap adjustor to suitable length (1, 2 & 3).

Adjusting the shoulder strap position

Removing

Push shoulder strap retainer through backrest (1).

Push crotch strap retainer through seat (2).

Rotate“C” clip to expose its opening (3) and slide waist strap out of clip (4).

Retting is a reversal of this procedure.

Bumper bar

Fitting

Opening/Removing

Calf support

Opening

Hood

Fitting

Push the brackets onto the mounts on the chassis (1).

Attach the fabric fasteners to the inside of the seat unit (2).

Attach the fabric fasteners to the outside of the seat unit (3).

Fit the rear of the hood behind the backrest and attach the fabric fastener (4).

Attach the straps to the handle hinges (5).

Opening

Extending

Using the viewing window ap

Using the hood pocket

Closing

Removing

Removal is a reversal of step 16 .

Fabric removal

Using a ball point pen push in the button on the arm (1) then pull the arm out of the

hinge unit (2). The buttons are on the outside on the lower arms and the inside on the

upper arms. Pull the arms out of the hood fabric (3).

Retting

Backrest recline

Lowering

Raising

Basket

Removing

Footmu

Fitting

Open the harness 9and remove chest pad & headhugger (1).

Push the harness straps through the footmu (2).

Attach the footmu fabric fasteners to the rear of the backrest (3).

Ret headhugger & chest pads then close the harness.

Raincover

Fitting

Drinks holder

Fitting

Raincover

Fitting

Pushchair

Closing

Ensure backrest is in the upright position 26 .

Press down on the release arm (1) then pull the ring upwards (2).

Push the handles forwards (3) until the auto lock engages (4).

Importante: Guarde estas

instrucciones para futura consulta.

Información de seguridad importante

General:

•La sillita está indicada desde el nacimiento y para niños de un máximo de 15kg.

•ADVERTENCIA: Supervise al niño en todo momento.

•ADVERTENCIA: Asegúrese de que todos los dispositivos de

bloqueo estén conectados antes de usar.

•ADVERTENCIA: Para evitar lesiones, asegúrese de mantener

alejado al niño al plegar y desplegar este producto.

•ADVERTENCIA: No permita que el niño juegue con este producto.

•ADVERTENCIA: Este producto no está indicado para correr o patinar.

•ADVERTENCIA: Use siempre el sistema de retención.

•ADVERTENCIA: Use siempre la correa de entrepierna en

combinación con el cinturón.

•ADVERTENCIA: Para evitar el riesgo de quemaduras, no coloque

bebidas calientes en el portavasos.

•No use piezas de repuesto ni accesorios que no sean los aprobados por Cosatto.

•Se incluye una cesta para el transporte de 2 kg de productos, distribuidos

uniformemente.

•Cualquier carga adicional acoplada al mango, a la parte trasera del respaldo o a los

lados del vehículo afectará a su estabilidad y seguridad.

•No use una plataforma con este producto, ya que podría afectar a su seguridad.

•Accione siempre el freno al colocar o quitar al niño del vehículo.

•No lleve nunca a un segundo niño en el vehículo.

•Este producto cumple con la normativa BS EN 1888:2012.

•Use el asiento en la posición más reclinada (“acostada”) para recién nacidos hasta que

se puedan incorporar sin ayuda.

•Asegúrese de que el niño lleve un arnés correctamente equipado y ajustado en todo

momento. Las hebillas en forma de D del arnés existente se suministran para acoplar

un arnés de seguridad separado aprobado por la norma BS EN 13210 de ser necesario.
