Custom Audio Electronics TPT 60 Manuale utente

TPT 60

User’s Manual

www.custom.it

TPT 60

whatsoever, whether it be on paper or through computer processes, is strictly prohibited.

Custom Engineering s.r.l. and the resource teams employed in the making of this manual

will not be held responsible for any problems arising as a result of improper use of this

manual, as they guarantee that the information contained in it has been subjected to

careful inspection.

Any suggestions regarding errors in its contents or possible improvements will be

greatly appreciated. The products are continuously checked and improved. For this

reason Custom Engineering s.r.l. reserves the right to modify the information

contained in this manual without prior notice.

COD. DOME - TPT60 REV. 1.10

Custom Engineering

Str. Berettine 2 - 43010 Fontevivo (PARMA) - Italy

Tel. : +39 0521-680111 - Fax : +39 0521-610701

http: www.custom.it Email : [email protected]

TPT 60

ytimrofnoCfonoitaralceD"EC"ytimrofnoCfonoitaralceD"EC" ytimrofnoCfonoitaralceD"EC" ytimrofnoCfonoitaralceD"EC"ytimrofnoCfonoitaralceD"EC"

41054NEdna22ediuGCEI/OSIsdradnatshtiwecnadroccanI41054NEdna22ediuGCEI/OSIsdradnatshtiwecnadroccanI 41054NEdna22ediuGCEI/OSIsdradnatshtiwecnadroccanI 41054NEdna22ediuGCEI/OSIsdradnatshtiwecnadroccanI41054NEdna22ediuGCEI/OSIsdradnatshtiwecnadroccanI :°N 6910210CD

:emans'rerutcafunaM.l.r.sgnireenignEmotsuC

:sserddas'rerutcafunaM2enittereBadartS )amraP(ovivetnoF ylatI

:tcudorpehttahtseralceD

:emantcudorPresnepsidtekciT

:epyttcudorPTPT

:ledoM06TPT

:sevitceridgniwollofehthtiwytimrofnocnisi

EEC/86/39;EEC/13/29;EEC/633/98evitceriDytilibitapmoCcitengamortcelE

:sdradnatsgniwollofehthtiwecnadroccanI

22055NE BssalC ehtgnirusaemfosdohtemdnastimiL ybdecudorpecnabrutsidoidarfoscitsiretcarahc tnempiuqeygolonhcetnoitamrofni

4991

1-28005NEytinummilareneG-ytilibitapmoccitengamortcelE laicremmoc,laitnediseR:1traP.stnemeriuqer .stnemnorivneyrtsudnithgildna

2991

2-4-00016NE.stsetytinummiegrahcsidcitatsortcelE egrahcsidriaVK8,egrahcsidtcatnocVK4

5991

4-4-00016NE.stsetytinummitsrub/tneisnarttsaflacirtcelE VK1CAsenilrewoPVK5.0senillangiS

5991

04105VNEsdleifcitengamortceledetaidarriycneuqerf-oidaR .tsetytinummI- MAzHK1%08,zHM0001-zHM08,m/V3

3991

6991yraunaJ

TPT 60

GENERAL INFORMATION REGARDING SAFETY

•Readandkeepthefollowinginstructions.

•Observeallwarningsandfollowallinstructionsattachedtotheprinter.

•Beforecleaningtheprinter, disconnect the feed cable.

•Cleantheprinter with a damp cloth.Donot use liquid or sprayproducts.

•Donotoperate the printer near towater.

•Donotplacetheprinteronunsteadysurfaces.It could fall and get seriously damaged.

•Donotplacetheprinteronsoftsurfacesorinpoorlyventilatedenvironments.

•Positiontheprinter in such away as to ensure thatthe cables connected toitwill not be damaged.

•Usethetypeofelectricitysupplymarkedontheprinterlabel.Inthe event of uncertainty,contactthe

seller.

•Ensurethattheprinter’selectricitysupply is grounded and thatitisprotected by a differentialswitch.

•Iftheprinterisfed through an extension lead, ensure that the total absorption of the equipment

connectedtoitdoesnot exceed the maximum admissible current forthattypeofextension and that it

doesnot,inany event, exceed 15 amperes.

•Donot obstruct thevents.

•Donot put objects ofany kind inside theprinter as they couldcause a short circuitor damage parts

whichcouldaffectits performance.

•Donotspill liquids on theprinter.

•Donotcarryouttechnicaloperationsontheprinterwiththeexceptionofthescheduledmaintenance

operationsspecificallyindicated in the user’smanual.

•Disconnecttheprinterfrom the electricity supply andhaveit repaired by a specialized technician

shouldany of the following conditionsoccur:

A. Thefeedconnectorhas been damaged.

B. LIQUIDhaspenetratedtotheinsideoftheprinter;

C. Theprinterhas been exposed to rainorwater;

D. Theprinterisnotoperatingnormallydespitetheinstructionsintheuser’smanual having

beenfollowed.

E. The printer has been dropped and its case damaged.

F. Theperformance oftheprinteris poor.

G. Theprinterdoes not work.

TPT 60

DESCRIPTION

GENERAL FEATURES

The TPT60 is an extremely versatile receipt dispensing printer.

It is equipped with a thermal printing mechanism with a dedicated cutter for cutting the tickets, and uses

rolls of 60 mm paper. It has a 4-Kbytes print buffer and uses a RS232 serial interface or CENTRONICS

parallel interface for communication. It can print in 18,28 or 56 columns and in various modes.

The TPT60 printer consists of a stainless steel frame which houses the control card, the printing

mechanism and the paper roll.The Form Feed (FF) and Line Feed (LF) keys and three signal LEDs are

located in the upper part.If the Line Feed key is pressed, the paper continues to feed forward until

pressure on the key is released.

If the Form Feed is pressed, the paper feeds forward until the photocell (optional) detects a nick in the

paper. If there is no photocell, the paper feeds for a number of steps programmed in EEPROM.

GREEN LED : When the led is turned on, it means that printer power is on.

YELLOW LED :When the led is on it means printer status ok.

When the led is blinking it means paper end

RED LED : When the led is on it means near paper end

With the use of Flash memory technology, is possible :

• Program 5 graphic pages, and print them quickly;

• Print 7 different kinds of barcode;

• Updating of fonts or release filmware with Custom Eng. Software.

Microsoft Windows driver is available on request.

TPT 60

TECHNICAL SPECIFICATIONS

COLUMNS Font8x16 56 columns

Font16x24 28 columns

Font24x32 18 columns

GRAPHIC DOT 0.125mm

DOTS PER LINE 448

PRINTING SPEED 50mm/sec.

LINE BUFFER 56bytes

PRINT BUFFER 4096bytes

CHARACTER MATRIX 8x16,16x24or 24x32

PRINTING METHOD Thermal

CHARACTER SET ExtendedASCII

Arialstyle.Personalized fonts on request.

INTERFACE Serial RS232

ParallelCENTRONICS

POWER SUPPLY Single 24 Vdc

ABSORPTION

Mediumcurrent 1.25 A

Currentonstandby 38 mA

Peakcurrent 60 mA

ENVIRONMENTAL CONDITIONS

Operatingtemperature 0°C - +50°C

Operatinghumidity 35% - 85%

Storagetemperature /humidity -35°C - +65°C / 10%-90%

Overall Dimensions

DESCRIPTION

TPT 60

NEAR PAPER

END

LINE FEED

KEY

FAST FEED

KEY

GREEN LED

STATUS

POWER-ON

YELLOW LED

STEPPING MOTOR

CONNECTOR

RED LED PAPER CONTROL

CONNECTOR

CONNECTOR FOR RS232

SERIAL INTERFACE

POWER SUPPLY

CONNECTOR

CONNECTOR FOR

EXTERNAL SENSORS

CUTTER

CONNECTOR

PRINTING HEAD CONNECTOR

NEAR PAPER

END

LINE FEED

KEY

FAST FEED

KEY

GREEN LED

STATUS

POWER-ON

YELLOW LED

STEPPING MOTOR

CONNECTOR

RED LED PAPER CONTROL

CONNECTOR

CONNECTOR FOR

CENTRONICS PARALLEL

INTERFACE

POWER SUPPLY

CONNECTOR

CONNECTOR FOR

EXTERNAL SENSORS

CUTTER

CONNECTOR

PRINTING HEAD CONNECTOR

CONNECTIONS

CONNECTORS LAYOUT

N.B. The square pads indicate the pin 1 of connectors.

SERIAL VERSION PARALLEL VERSION

TPT 60

REAR

N.B. The square pads indicate

the pin 1 of connectors.

SERIALPORT

N.B. The square pads indicate

the pin 1 of connectors.

PARALLEL PORT

J5POWER SUPPLY

NO. SIGNAL FUNCTION

1GND GND

2VCC Power 24 Vcc

J7SERIAL PORT

NO. SIGNAL FUNCTION

2TX RS-232 data output

3RX RS-232 data input

5GND GND

8RTS Request to send

CONNECTIONS

TPT 60

J7 PARALLEL PORT

NO. SIGNAL FUNCTION

1STROBE Strobe input

2D0 Data input bit 0

3D1 Data input bit 1

4D2 Data input bit 2

5D3 Data input bit 3

6D4 Data input bit 4

7D5 Data input bit 5

8D6 Data input bit 6

9D7 Data input bit 7

10 ACK Acknoledge

11 BUSY Busy

12 PE Paper End

13 VCC VCC

15 VCC VCC

16 RESET Printer reset

17 GND GND

19 GND GND

20 GND GND

21 GND GND

22 GND GND

23 GND GND

24 GND GND

25 GND GND

J1 HEAD CONNECTOR

NO. SIGNAL FUNCTION NO. SIGNAL FUNCTION

1COM Thermal head common 2COM Thermal head common

3COM Thermal head common 4GND GND

5GND GND 6GND GND

7SI Serial data input 8SO Serial data input

9CLOCK Synchronous data clock 10 GND GND

11 LATCH Data latch 12 GND GND

13 STR5 Strobe 5 14 VDD Thermal head power (+5v)

15 STR3 Strobe 3 16 STR4 Strobe 4

17 STR1 Strobe 1 18 STR2 Strobe 2

19 TM Thermistor 20 TM Thermistor

21 GND GND 22 GND GND

23 GND GND 24 COM Thermal head common

25 COM Thermalhead common 26 COM Thermal headcommon

CONNECTIONS

TPT 60

J4 MOTOR CONNECTOR

NO. SIGNAL FUNCTION COLOUR

1Φ 1 Phase 1 Black

2Φ2 Phase 2 Yellow

3Φ3 Phase 3 Brown

4Φ4 Phase 4 Orange

5COM Common Red

6COM Common Red

J6 SENSOR CONNECTOR

NO. SIGNAL FUNCTION COLOUR

1Collector Paper end detection 1: Penetrative type Red

2Emitter Paper end detection 1: Penetrative type Yellow

3Anode Paper end detection 1: Penetrative type Blue

4Cathode Paper end detection 1: Penetrative type Green

5Emitter Paper end detection 2 Yellow

6Cathode Paper end detection 2 Green

7Anode Paper end detection 2 Blue

8Collector Paper end detection 2 Red

9Switch Head open detection switch White

10 Switch Head open detection switch White

11 Switch Head up detection switch White

12 Switch Head up detection switch White

J2 CUTTER CONNECTOR

NO. SIGNAL COLOUR

1MOTOR + RED

2MOTOR - BLACK

3SWITCH WHITE

4SWITCH WHITE

CONNECTIONS
