D-Link DHN-120 Manuale utente

DHN-120

Create a Network with

existing Phonelines and the

ease of USBConnectivity

10Mb HomePNA Adapter

The D-Link DHN-120 is an HomePNA 2.0 compliant 10Mb

Home Phoneline Network Adapter specifically designed to plug

into an available Universal Serial Bus USB port connecting to a

desktop or laptop PC running Microsoft Windows 98 or Windows

2000. It is a complete out of the box solution for that represents

the simplest way to add 10Mb HomePNA-compliant networking

to a computer.

The HomePNA2.0 specification outlines a transport method by

which sustainable data rates of 10 Megabits per second can be

achieved over normal in-homephoneline wiring. Additionally this

technology is backwards compatible with HomePNA 1.0 1 Mbps

products. The DHN-120 marries this technology to USB to

provide the fastest and most advanced out-of-the box home

networking solution.

The DHN-120 has three ports. The USB type B port allows the

unit to be located up to 15 feet away from a USB hub or USB

enabled computer. The two RJ-11’s can be used to connect to the

home phoneline, directly to another HomePNA device, or may be

used as a pass through for a telephone or modem.

Power for the DHN-120 is provided directly by the USB bus,

negating the need for an external power adapter. It can be plugged

into any USB host or hub port that provides 500mA of current as

defined in the USB specifications 1.0 and 1.1 as a high-powered

USB device. The DHN-120 supports USB’s energy saving

suspend and resume functions to minimize power consumption.

Diagnostic LEDs are mounted on the top of the device to provide

theuser with power stateand current Linkand Traffic statusfor the

LAN connection. Packaged with all necessary manuals, a 6-foot

USB ‘A’to ‘B’ cable, and a driver CD, the DHN-120 ensures that

the user is able to easily and quickly install and use the device

directly out of the box.

The D-Link DHN-120 is a complete out of

the box solution for that represents the

simplest way to add 10Mb HomePNA-

compliant networking to a computer

D-Link Systems, 53 Discovery Drive Irvine CA 92618 www.dlink.com

Specifications are subject to change without notice. D-Link is a registered trademark of D-Link Systems, Inc.

©

2000 D-Link Systems Inc. All rights reserved.

DHN-120 10Mb HomePNA Adapter
