Linksys WCF54G - Wireless-G Compact Flash Card Manuale operativo

Model No.

Product Data

Wireless

WCF54G

Connect Your Pocket PC to Wireless Networks!

Wireless-G connectiv-

ity for most Pocket

PCs

On-screen manage-

ment utility for easy

setup and connections

Fits in a Compact-

Flash (CF) Type II slot

Built-in power

management saves

battery life

Experience the speed and convenience of wireless networking on your PDA. The Wireless-G CompactFlash Card

installs directly into your Pocket PC using a CompactFlash Type II slot. The user-friendly software makes it a snap to

set up, and you’re ready to share data, printers, or high-speed Internet access over your existing wireless network

at speeds up to 54Mbps. It's also compatible with Wireless-B (802.11b) wireless networks.

Use the Wireless CompactFlash Card to connect your PDA to wireless networks at the office, at home, or in any of

the growing number of public wireless hotspot venues springing up in coffee shops, airport lounges, hotels and

convention centers.

With the Wireless-G CompactFlash Card you'll get more of what you own a PDA for – information at your fingertips

with total mobility.

CompactFlash Card

Wireless-G

Model No.

Product Data

Model No.

Features

• Compatible with 802.11g

and 802.11b (2.4GHz) Stard-

ards

• Compatible with Microsoft

Pocket PC 2002 or Higher

• Operates in the 2.4Ghz fre-

quency spectrum with a data

rate of up to 54 Mbps

• Supports up to 128-bit WEP

Encryption Security

• Free Technical Support—24

Hours a Day, 7 Days a Week,

Toll-Free US Calls

Linksys

A Division of Cisco Systems, Inc.

18582 Teller Avenue

Irvine, CA 92612 USA

E-mail: [email protected]

[email protected]

Web: http://www.linksys.com

Linksys products are available in more than 50

countries, supported by 12 Linksys Regional Offices

throughout the world. For a complete list of local

Linksys Sales and Technical Support contacts, visit

our Worldwide Web Site at www.linksys.com.

WCF54G

Package Contents

• Wireless-G CompactFlash Card

• Setup Wizard CD-ROM with

Drivers and User Guide

• Quick Installation guide

• Registration Card

VPN Broadband Router

Wireless-G

Minimum Requirements

• Pocket PC with Type II CompactFlash

Slot

• Any ARM, SH3, or MIPS Based PDA

Running Pocket PC 2002 or Later

• Microsoft ActiveSync Utility 3.5 or Later

• A PC or Notebook with at Least a

200MHz CPU; 64MB RAM; CD-ROM

Drive; and Microsoft Windows 98SE,

Me, 2000, or XP

Specifications

Model Number WCF54G

Standards IEEE 802.11b, IEEE 802.11g,

Type II CompactFlash

LEDs Link, Power

Transmit Power 802.11g: 15dBm Typical @ Normal Temp Range

802.11b: 20dBm Typical @ Normal Temp Range

TX Peak 350mA @ 54Mbps

Rx Peak 270mA @ 54Mbps

Security Features WEP Encryption

WEP Key Bits 64, 128

Environmental

Dimensions 1.69" x 0.27" x 2.32"

W x H x D (43 mm x 6.9 mm x 5.9 mm)

Unit Weight .86 oz. (0.03 kg)

Certifications FCC

Operating Temp. 32ºF to 122ºF (0ºC to 50ºC)

Storage Temp. -4ºF to 158ºF (-20ºC to 70ºC)

Operating Humidity 5% to 95%, Non-Condensing

Storage Humidity 5% to 95%, Non-Condensing

WCF54G-DS-60609A BW

Specifications are subject to change without notice. Linksys is a registered trademark or trademark of Cisco Systems, Inc. and/or its affiliates in the U.S. and certain other countries. Copyright © 2004
