Compact USB 2.0 10/100

Network Adapter

Now you can connect to any 10/100 Ethernet network

without having to open your PC. And with the power

of USB 2.0, you’ll connect at the full speed your net-

work supports. The Compact USB 2.0 10/100 Network

Adapter from Linksys works with any USB 1.1 or 2.0

equipped desktop or notebook PC, running any version of

Windows that supports USB.

This tiny, Plug-and-Play compatible device attaches directly

to a USB port on your PC or hub via a standard USB Type A

connector. Simply connect a Category 5 Ethernet network

cabletotheCompactUSB2.010/100NetworkAdapter’sRJ-

45 port, install the included device driver, and you’re net-

worked.

The Compact USB 2.0 10/100 Network Adapter is bus-pow-

ered, drawing power from the host PC so it requires no

external power cord. It features easy-to-read LEDs, a com-

pact design, a 1-year limited warranty,and free world-class

technical support.

• One Type A, Male USB Connector

• One RJ-45, 10/100 Port for Network Connectivity

• Powered by Host PC so No External Power Supply is

Needed

• Compact Design—Perfect for Use with Notebook PCs

• RJ-45 Network Port Connects to Any 10/100Mbps

Hub or Switch

• Backward Compatible with USB 1.0/1.1 Ports

• Plug-and-Play Compatible with Windows 98,

Millennium, 2000, and XP for Easy Installation

•Connects at a Full 100Mbps via USB 2.0,up

to 8 Times Faster than a USB 1.1 Adapter

•Compact Size for Greater Flexibility

•Also Compatible with USB 1.1 Desktop and

Notebook Computers

•Plug-and-Play Compatible with Windows

98, Millennium, 2000, and XP

•Free Technical Support—24 Hours a Day,

7 Days a Week, Toll-Free US Calls

•1-Year Limited Warranty

Compact USB 2.0 10/100 Network Adapter

Model Number: USB200M

Connect to Any 10/100 Network at Full Speed

via USB 2.0

Features

Benefits

NNeettwwoorrkkaattMMaaxxiimmuummSSppeeeedd

wwiitthhUUSSBBCCoonnvveenniieennccee

Instant EtherFast®Series

Package Contents

Compact USB 2.0 10/100

Network Adapter

• One Compact USB 2.0 10/100 Network

Adapter

• One Driver Installation CD with User Guide

Included

• One USB Coupler

• One Quick Installation guide

• One Registration Card

DS-USB200M-092602NC JL

Linksys

World Headquarters:

17401 Armstrong Ave.

Irvine, CA 92614 USA

E-mail: [email protected]

[email protected]

Web: http://www.linksys.com

Linksys products are available in more than 50

countries, supported by 12 Linksys Regional

Offices throughout the world. For a complete

list of local Linksys Sales and Technical

Support contacts,visit ourWorldwideWeb Site

www.linksys.com

One PC with the following:

• 200MHz or Faster Processor

• 64MB RAM Recommended

• Available USB Port (USB 2.0 for maximum

throughput)

• CD-ROM Drive

• Windows 98, Millennium, 2000, or XP

Minimum Requirements

Specifications

Model Number USB200M

Standards IEEE 802.3, IEEE 802.3u

USB 1.0, 1.1, and 2.0

Ports One USB Type A, Male Connector

One RJ-45 Port

Speeds (Mbps)

USB 1.5 (Low Speed), 12 (Full Speed),

up to 480 (High Speed)

Ethernet 10 or 100 (Half Duplex)

20 or 200 (Full Duplex)

Cabling Category 5 Ethernet Network Cable

USB Cable

LEDs 100/ACT, F/H (Full or Half Duplex), 10/ACT

Environmental

Dimensions 0.98" x 0.49" x 3.46"

(25 mm x 12.4 mm x 87.8 mm)

Unit Weight 2.4 oz. (0.068 kg)

Power Input 3.3V low power consumption

Certifications FCC Class B, CE Mark,VCCI

Operating Temp. 32ºF to 158ºF (0ºC to 70ºC )

Storage Temp. 32ºF to 158ºF (0ºC to 70ºC)

Operating Humidity 10% to 90%, Non-Condensing

Storage Humidity 10% to 90%, Non-Condensing
