Linksys EG1032 Manuale utente

Instant Gigabit

Network Adapter

(32-bit)

nprecedented speed is now available over

your existing network cabling! Built to run

the fastest video, publishing, and database

network applications, the Instant Gigabit Network

Adapter is a high performance network adapter for

PCI local bus computers. Boasting an incredible

maximum data throughput of 2000 megabits-per-

second in full duplex mode, it includes a

10BaseT/100BaseTX/1000BaseTX port, which

means that you can begin integrating Gigabit

now—even if you don't plan on upgrading to a

1000Mbps network right away.

The Instant Gigabit Network Adapter is Windows

Plug-and-Play compatible. The card also runs on

most operating systems, including Windows 2000.

Wake-On-LAN support is built in—you can wake up

your workstations from anywhere on the network!

Built-in support for the widest range of PCI mother-

boards, networking hardware, and software means

you don't have to worry about compatibility.

• High-Speed Performance

• Automatically Adjusts to Full or Half Duplex at

10/100/1000 Mbps

• Wake-On-LAN and Plug-and-Play Compatible

• Runs with Virtually All Major Network Operating

Systems

• Bus Mastering Architecture Supports 1000Mbps

Speeds

• Diagnostic LEDs For Easy Troubleshooting

• Easy to Install and Use

• VLAN Support

• IEEE 802.ab Flow Control Supported

• IEEE 802.1q Priority Queuing Support

• 33 Mhz, 32-bit PCI v2.2

• Free Technical Support - 24 Hours a Day,

7 Days a Week for North America Only

• One Year Limited Warranty

•Easy to Use Plug-and-Play 10/100/1000

PCI Network Card

• Full Duplex Capability at Speeds Up To

2000Mbps

•Connects to Both 10Mbps, 100Mbps, and

1000 Mbps Fast Ethernet Networks

•Power On Your PC From Anywhere on the

Network with Wake-On-Lan Management

• Works With Most Operating Systems

• Free Technical Support - 24 Hours a Day,

7 Days a Week for North America Only

•One Year Limited Warranty

Instant Gigabit Network Adapter (32-Bit)

(EG1032)

Unprecedented Gigabit Performance in a

Managed PCI Card for Desktop Computers

Features

Benefits

11000000MMbbppssSSppeeeeddiinnYYoouurr

1100//110000EEnnvviirroonnmmeenntt

Instant Gigabit Series

Package Contents

Instant Gigabit®Network Adapter

(32-bit)

• One Instant Gigabit®Network

Adapter

• One Driver Disk

• One User Guide and Registration

Card

The Instant Gigabit Network

Adapter’s Wake-on-Lan feature is

optional. In order to use the feature,

the card must be properly connected

to a PCI motherboard that supports

WOL event management. If your

motherboard does not support

Wake-on-Lan, the card will operate

as a normal Instant Gigabit Network

Adapter..

WOL

Wake-On-LAN Compatible

Linksys

17401 Armstrong Ave.

Irvine, CA 92614 USA

Information (800) 546-5797

Technical Support (800) 326-7114

(949) 261-1288

Fax (949) 261-8868

World Wide Web http://www.linksys.com

Email [email protected]

[email protected]

China

Tech Support (10) 6432 1920

Sales (10) 6432 1923

Fax (10) 6437 6891

Japan

Telephone (03) 5259-5139

Fax (03) 5259-5117

Philippines

Telephone (632) 638 5580

Fax (632) 635 6772

Singapore

Telephone 552-8998

Fax 552-1024

Thailand

Telephone 717-0770

Fax 717-0738

United Kingdom

Tech Support 0870 7393939

Sales 01245 352403

Fax 0870 7393938

Specifications

Model EG1032

Standards IEEE 802.3, IEEE 802.3u,IEEE 802.3ab, IEEE

802.3ad, IEEE 802.1p, IEEE802.1Q, PCI 2.1,

PCI 2.2,ACPI

Protocol CSMA/CD

Ports: 1 Straight-Through 10BaseT/100BaseTX/

1000BaseT RJ-45 Port (Auto-Senses Speed

and Duplex)

Cabling Type: 10BaseT: UTP/STP Category 3 or better

100BaseTX: UTP/STP Category 5 or better

1000BaseT: UTP/STP Category 5E or better

Topology: Star

Speed: Full Duplex: 20Mbps,200Mbps or 2000Mbps

Half Duplex: 10Mbps,100Mbps or 1000Mbps

WOL Support: Remote Wake-Up

Power Management Event (PME)

Bus Type: 32-Bit PCI

LEDs: Link/Activity, 1000Mbps

Environmental

Dimensions: 5” x 6.8” x .75”(127mm x 173mm x 19mm)

Unit Weight: 3.2 oz. (9.065 Kg)

Power: 5W Maximum

Certifications: FCC Class B

CE Mark, Commercial

UL and CSA Listed

Operating Temp.: 32ºF to 122ºF (0ºC to 49ºC)

Storage Temp.: -4ºF to 158ºF (-20ºC to 70ºC)

Operating Hum.: 10% to 85% Non-Condensing

Storage Hum.: 5% to 90% Non-Condensing
