D-MAX DCC-500D Manuale utente
USER MANUAL
Digital Day & Night
COLOR DOME CAMERA
The lightning flash with an arrowhead symbol, within an
equilateral triangle is intended to alert the user to the
presence of uninsulated dangerous voltage within the
product's enclosure that may be of sufficient magnitude to
constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle is
intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in the
literature accompanying the appliance.
INFORMATION - This equipment has been tested and found to
comply with limits for a Class A digital device, pursuant to part 15 of
the FCC Rules.
These limits are designed to provide reasonable protection against
CAUTION :
TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER(OR BACK),
NO USER SERVICEABLE PARTS INSIDE.
REFER WERVICING TO QUALIFIED
SERVICE PERSONNEL.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
2 3
1. Features 4
2. Components 6
3. Names and functions of parts 8
4. Camera operation
1) LENS (selection) 10
2) SHUTTER (condition and speed control) 10
3) WHITE BALANCE control 11
4) BACKLIGHT (Backlight Compensation) 12
5) AGC (Auto gain compensation) 14
6) DNR (Digital Noise Reduction) 14
7) SENS-UP 15
8) SPECIAL 17
9) EXIT 24
5. Troubleshooting 25
6. Specifications 27
harmful interference when the equipment is operated in a commercial
environment.
This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the instruction
manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause
harmful interference in which case the user will be required to correct
the interference at his own expense.
WARNING - Changes or modifications not expressly approved by the
manufacturer could void the user's authority to operate the equipment.
CAUTION : To prevent electric shock and risk of fire hazards : Do
NOT use power sources other than that specified.
Do NOT expose this appliance to rain or moisture.
This installation should be made by a qualified service person
and should conform to all local codes
Contents
High Sensitivity
The built-in high sensitivity SONY COLOR CCD enables a clear
image even in 0.3Lux(0.1Lux B/W) or as low as 0.002Lux with
SENS-UP.
DNR (Digital Noise Reduction)
The amount of low illuminance noise has been significantly
reduced, and the signal-to-noise ratio (S/N ratio) as well as
horizontal resolution have been improved, resulting in a clear and
sharp image display even in the dark.
Controlled by OSD Menu
The camera can be controlled by selecting text displayed on the
monitor screen.
Additional Functions
SENS-UP, MOTION DETECTION, MIRROR, SHARPNESS and
SYNC (INT/LL) functions are also available.
Horizontal Resolution 530 TVLines
Clear image quality has been achieved by employing a SONY
CCD with 410,000(effective) pixels, which provides a horizontal
resolution of 530 TV lines.
DAY & NIGHT
This camera has a function that automatically selects the mode
that is appropriate for daytime or night-time conditions. The
COLOR mode operates in daytime conditions to provide optimum
colors, and BW mode operates in nighttime conditions to enhance
the definition of the image.
Electronic IRIS
The electronic IRIS function enables continuous automatic control
of the shutter between 1/60~1/120,000 seconds.
PRIVACY Function
The PRIVACY function conceals the areas you do not wish to
appear on the screen.
4 5
1. Features
6 7
2. Precaution
Do not install the camera in
extreme temperature conditions.
Only use the camera nuder
conditions where temperatures
are between -10 and 50 . Be
especially careful to provide
ventilation when operating under
high temperatures.
Do not install the camera under
unstable lighting conditions.
Severe lighting change or flicker
can cause the camera to work
improperly.
Do not touch the front lens of the
camera.
It is one of the most important
parts of the camera. Be careful
not to be stained by finggerprint.
Do not drop the camera or
subject it to physical shocks.
It can cause malfunctions to
occur.
Never keep the camea face to
strong light directly.
It can damage the CCD.
Do not install or use the camera
in an environment where the
humidity is high
Only use the camera nuder
conditions where temperatures
are between -10 and 50 . Be
especially careful to provide
ventilation when operating under
high temperatures.
Do not expose the camera to
rain or spill beverage on it.
If it gets wet, wipe it dry immedi-
ately.
Lipuids can contain minerals that
corrode the electronic com-
ponents.
Do not expose the camera to
radioactivity.
if it is exposed to radioactivity, For
heated CCD, it Will be out of
order.
- SETUP button : Used for the menu display. This button can be
used to confirm settings after changing the value of the selected
function or current conditions.
- UP & DOWN buttons : Used for selecting items by moving the
cursor up or down on the menu screen.
- LEFT & RIGHT buttons : Used when changing item values, by
moving the cursor to the left or right on the menu screen.
1) Names of Parts
2) OSD PCB
8 9
3. Names and Functions of Parts
POWER
VIDEO
SETUP RIGHT
UP LEFT
DOWN
RIGHT button.
- FLK : Please select 'FLK' mode when
flickering occurs on the screen, due to an
imbalance between illumination and
frequency. (NTSC Model : 1/100, PAL
Model : 1/120)
- ESC : Auto control of the shutter speed
can be achieved. When ESC mode is on, the speed is controlled
automatically according to the brightness of the screen.
- MANUAL : The shutter speed can be controlled manually.
3) WHITE BALANCE
The screen color can be adjusted by using the WHITE BALANCE
function.
-Please position the arrow to point to
'WHITE BAL' on the SETUP menu by
using the UP and DOWN buttons
-Please select the mode you wish to
operate by pressing the LEFT or RIGHT
button.
1) LENS
This function is used to adjust the brightness of the screen.
- Please select the type of the manual lens.
The lens brightness can be adjusted in
ESC mode, when you select the
manual mode
2) SHUTTER
Auto or manual control can be selected.
- When the SETUP menu is on the screen, please position the
arrow to point to 'SHUTTER' by using the UP and DOWN buttons.
- Please select the ESC shutter mode by pressing the LEFT or
10 11
4. Camera operation
SETUP
LENS MNUAL
SHUTTER ESC
WHITE BAL ATM
BACKLIGHT OFF
AGC LOW
DNR LOW
SENS-UP OFF
SPECIAL
EXIT
LENS
brightness 50
Press Set to Return
SETUP
LENS MNUAL
SHUTTER ESC
WHITE BAL ATM
BACKLIGHT OFF
AGC LOW
DNR LOW
SENS-UP OFF
SPECIAL
EXIT
SETUP
LENS MNUAL
SHUTTER ESC
WHITE BAL ATM
BACKLIGHT OFF
AGC LOW
DNR LOW
SENS-UP OFF
SPECIAL
EXIT
-Please position the arrow to point to
'BACKLIGHT' on the SETUP menu by
using the UP and DOWN buttons.
-Please select the mode you wish to
operate by pressing the LEFT or RIGHT
button.
HIGH : The gain increases from 0dB up to 42dB.
MIDDLE : The gain increases from 0dB up to 30dB.
LOW : The gain increases from 0dB up to 18dB.
OFF : BACKLIGHT function does not operate.
Please select one of the 3 modes below.
- ATW(Auto Tracking White Balance) : This mode can be used
within the color temperature range 1,800 K ~ 10,500 K (eg,
fluorescent light, outdoor, sodium vapor lamp or inside tunnels)
- AWC(Auto White Balance Control) : Please press the SETUP
button while the camera is directed at a piece of white paper to
obtain the optimum state under current illumination. If the
environment including the light source is changed you have to
adjust the white balance again.
- MANUAL : The manual adjustment mode enables finer
adjustment.
Please select ATW or AWC first. Please change to manual
adjustment mode and press the SETUP button. Please set the
appropriate color temperature, and then increase or decrease the
red and blue color values while monitoring the color changes on
the object.
4) BACKLIGHT
When there is a strong backlight behind the object, clear images of
the background as well as the object can still be obtained by using
the backlight function.
12 13
SETUP
LENS MNUAL
SHUTTER ESC
WHITE BAL ATM
BACKLIGHT OFF
AGC LOW
DNR LOW
SENS-UP OFF
SPECIAL
EXIT
-Please position the arrow to point to
'DNR' on the SETUP menu by using the
UP and DOWN buttons.
-Please select the mode you wish to
operate by pressing the LEFT or RIGHT
button.
OFF : There is no reduction in noise level.
LOW : There is a small reduction in noise level with almost no
ghost image.
MIDDLE : The most effective mode. There is a sufficient reduction
in noise levels without causing much ghost imaging.
HIGH : The level of noise is reduced greatly, however there is an
increase in ghost imaging.
7) SENS UP
SENS UP helps maintain a bright, clear screen image by
automatically detecting changes in the level of light in low light level
conditions
- Please position the arrow to point to 'SENS UP' on the SETUP
menu by using the UP and DOWN buttons.
- Please select the mode you wish to operate by pressing the
5) AGC (AUTO GAIN CONTROL)
-Please position the arrow to point to
'AGC' on the SETUP menu by using the
UP and DOWN buttons.
-Please select the mode you wish to
operate by pressing the LEFT or RIGHT
button. As the level of gain increases, the
screen gets brighter and the level of
noise also increases.
HIGH : The gain increases or decreases within the range of 6dB ~
42dB.
MIDDLE : The gain increases or decreases within the range of
6dB ~ 30dB.
LOW : The gain increases or decreases within the range of 6dB ~
18dB.
OFF : The gain is fixed at 6dB.
6) DNR
The background noise in the low light level decreases
automatically as the level of gain changes.
14 15
SETUP
LENS MNUAL
SHUTTER ESC
WHITE BAL ATM
BACKLIGHT OFF
AGC LOW
DNR LOW
SENS-UP OFF
SPECIAL
EXIT
SETUP
LENS MNUAL
SHUTTER ESC
WHITE BAL ATM
BACKLIGHT OFF
AGC LOW
DNR LOW
SENS-UP OFF
SPECIAL
EXIT
8) SPECIAL -Please position the arrow to point to
'SPECIAL' on the SETUP menu by using
the UP and DOWN buttons.
-Please select the mode you wish to
operate by pressing the UP or DOWN
button
CAMERA ID : If the ID is input, the camera ID appears on the
monitor.
-Please position the arrow to point to
'CAMERA ID' by using the UP or DOWN
button.
- Please select 'ON' by pressing the LEFT
or RIGHT button.
LEFT or RIGHT button.
- Please press the SETUP button when all
the settings are complete.
- The maximum storage magnification in
low light level movement situations can
be adjusted by pressing the SETUP
button in 'AUTO' mode.(X2~X128)
- As the magnification increases, the screen gets brighter; however
the after image also increases
- If storage magnification is increased while SENS UP is operating,
it may cause noise, and spots may appear; however this is
normal.
AUTO : Low light level auto mode
OFF : The function does not operate
16 17
SETUP
LENS MNUAL
SHUTTER ESC
WHITE BAL ATM
BACKLIGHT OFF
AGC LOW
DNR LOW
SENS-UP OFF
SPECIAL
EXIT
SETUP
LENS MNUAL
SHUTTER ESC
WHITE BAL ATM
BACKLIGHT OFF
AGC LOW
DNR LOW
SENS-UP OFF
SPECIAL
EXIT
SETUP
CAMERA ID OFF
COLOR ON
SYNC INT
MOTION DET OFF
PRIVACY OFF
MIRROR OFF
SHARPNESS ON
RESET
RETURN
When SHUTTER is in the manual mode, SENS UP does not
operate.
When AGC is turned off, SENS UP does not operate.
Note
Altri manuali per DCC-500D
1
Indice
Altri manuali D-MAX Telecamera di sicurezza
D-MAX
D-MAX DCC-600F Manuale utente
D-MAX
D-MAX DMS-200 Manuale utente
D-MAX
D-MAX DSC-Se5 Manuale utente
D-MAX
D-MAX DWC-540PV Manuale utente
D-MAX
D-MAX DCC-601DV Manuale utente
D-MAX
D-MAX DSC-230SI Manuale utente
D-MAX
D-MAX DWC-540DV Manuale utente
D-MAX
D-MAX DCC 600d Series Manuale utente
D-MAX
D-MAX DCC-520D series Manuale utente
D-MAX
D-MAX DCC-500DV Manuale utente
D-MAX
D-MAX DCC-500D Manuale utente
D-MAX
D-MAX DCC-580D Series Manuale utente
D-MAX
D-MAX 600 TVL Manuale utente
D-MAX
D-MAX DMC-20SEC Manuale utente
D-MAX
D-MAX DCC-520DV Manuale utente
D-MAX
D-MAX DSC-2000Si Manuale utente
D-MAX
D-MAX Superior Speed Dome Manuale operativo
D-MAX
D-MAX DWC-548DV Manuale utente
D-MAX
D-MAX DCC-700d Series Manuale utente
D-MAX
D-MAX DSC-300SE Manuale utente
