2.1 Product Features
☺23x Zoom lens
23x Optical zoom lens combined with an auto
focus system and digital zoom enables you to
get maximum 235x great pictures.
☺A low light function
Surveillance with optimum picture is possible
owing to digital-slow-shutter function and wide-
dynamic-range function.
zDigital-slow-shutter function is improving the
CCD sensitivity by electrically lengthening
exposure time so that it should be under
surveillance on the condition of 0.01 Lux in color.
zWide-dynamic-range function is possible to
look at object clearer in back light condition.
☺Various auto-surveillance functions
zPTZ trace
Realizes the registered manual operation for
about 120 seconds.
zAuto swing
Repeat pan and tilt between two preset positions.
zGroup sequence
Switches and checks a maximum of 64 preset
positions in order.
zTour sequence
Switches and checks a maximum of 6 group
sequences in order.
☺128 Preset position
A maximum of 128 preset positions can be
programmable. The preset function enables to
set where you want on monitor at any time.
☺Smart pan/tilt function
zIt should be rotated pan travel by 360° endless.
zPan and tilt speed compensation function in
proportion to depth of zoom.
☺Day & Night function with filter
zIt allows make surveillance in the night or low
illumination condition with IR cut filter system.
(0.1 Lux)
zIn the darkness, it should be changed to black
& white mode automatically.
zWith DSS control, it allows watch at 0.009 Lux.
☺4ch alarm inputs
It can be directly connected sensor and used
with presets owing to built-in 4-channel sensor
input terminals. It can be also operated together
other equipment owing to built-in alarm output.
(1-Relay normal output)
☺Auto flip function
The unit can be track the moving object
automatically until 180° in vertical by using
controller.
☺8 Privacy Masking Zones
For the privacy, it can be programmed masking
zone up to 8 locations on the OSD menu screen.
☺OSD (On Screen Display) Menu
Provides character information displayed on the
monitor, such as the camera ID address, camera
name, preset number, sequence status, and sets
various functions of camera easily on the OSD
menu screen.
☺For outdoor use function
With fan & heater it can be operated the dome
camera in hot or cold condition in automatically.
