Datalogic DS8100A-3002 Manuale utente

DS8100A-3002

QUICK REFERENCE GUIDE

DS8100A-3002 QUICK GUIDE

DS8100A-3002

General View:

Figure A

Laser Beam Output Window

Figure B

Programming Keypad

Phase On LED (Yellow)

Power On LED (Green)

TX Data LED (Green)

Network LED (Red)

Encoder LED (Yellow)

LCD Display

Figure C

Lonworks 17-pin Male Connector

Lonworks 17-pin Female Connector

NOTE

For further details on product installation, see the complete Reference Manual available on the

configuration CD-ROM included with this product.

1 2

2 3 4 5 6

DS8100A-3002 QUICK GUIDE

Technical Features:

ELECTRICAL FEATURES

Supply Voltage 20 - 30 Vdc

Power Consumption 1.0 to 0.67 A; 20 W typical

1.5 to 1.0 A; 30 W Max. (including startup current)

Communication Interfaces Auxiliary Baud Rate

RS232 1200 to 115200

Other

Lonworks 1.25 Mb/s

OPTICAL FEATURES

Light Receiver Avalanche photodiode

Safety Class 630 to 680 nm

Wavelength Class 2-EN 60825-1; Class II-CDRH

Laser Control Security system to turn laser off in case of motor slow down

READING FEATURES

Scan Rate ≤1000 scans/s

Max. Resolution

Max. Read. Distance

Max. Read. Width

Max. Depth of Field

(see reading diagrams)

USER INTERFACE

LCD Display 2 lines by 20 characters LCD

Keypad 3 keys

LED Indicators Power ON (green)

Phase ON (yellow)

Encoder (yellow)

TX Data (green)

Network (red)

SOFTWARE FEATURES

Operating Modes PackTrack™

Config. Mode Genius™ utility program

Parameter Storage Non-volatile internal FLASH

Readable Codes Interleaved 2/5

Code 39 standard

Codabar

Code 128

EAN 128

Code 93 (standard & full ASCII)

EAN/UPC

Code Selection Up to 10 codes during one reading phase

ENVIRONMENTAL FEATURES

Operating Temperature 0° to +50 °C (+32 to +122 °F)

Storage Temperature 20° to +70 °C (-4° to +158 °F)

Humidity -90% non condensing

Vibration Resistance:

EN 60068-2-6

14 mm @ 2 to 10 Hz; 1.5 mm @ 13 to 55 Hz

2 g @ 70 to 200 Hz; 2 hours on each axis

Shock Resistance:

EN 60068-2-27

30 g; 11 ms

3 shocks on each axis

Protection Class

EN 60529

IP65*

PHYSICAL FEATURES

Dimensions mm (inch) 217 x 173 x 127 (8.54 x 6.79 x 4.98)

Weight 5 Kg (11 lbs.)

* IP65 cables and connectors required (CAB-850x or BTK-8500).

DS8100A-3002 QUICK GUIDE

Accessories:

NAME Description Part Number

PWO-480 Power and Connect System 480W 93ACC1767

FS-1 Frame Shaper (8 pcs) 93ACC1750

FBK-8100 Fast Bracket Kit (2 pcs) 93ACC1130

US-8100 Bracket Kit (10 pcs) 93ACC1140

GFC-80 90 Degree Mirror 93A251020

GFC-800 90 Degree Close Distance Mirror 93A201103

S30 Photocell Kit 93ACC1782

PH-1 Photocell Kit - PNP 93ACC1791

MEP-543 Photocell Kit - NPN 93ACC1728

OEK-2 Optical Encoder Kit (10 m cable + spring) 93ACC1770

OEK-1 Optical Encoder Kit + 10 m cable 93ACC1600

BTK-8100 Bus Terminator Kit (5 pcs) 93ACC1090

BTK-8500 IP65 Terminator Kit (2 pcs) 93A051286

PLL-8000 Optocoupled PLL device 93ACC1280

CAB-8100 10 wire shielded cable D 9.5 mm – 50 m 93ACC1120

CAB-8101 17-pin scanner/scanner connection cable 1.2 m 93A051020

CAB-8102 17-pin scanner/scanner connection cable 2.5 m 93A051030

CAB-8105 17-pin scanner/scanner connection cable 5 m 93A051040

CAB-8501 IP65 Cable Fam 8K 1,2 m 93A051283

CAB-8502 IP65 Cable Fam 8K 2,5 m 93A051284

CAB-8505 IP65 Cable Fam 8K 5 m 93A051285

Datalogic WebSentinel-005 Supervisor (up to 5 arrays) 93A101014

Datalogic WebSentinel-010 Supervisor (up to 10 arrays) 93A101015

Datalogic WebSentinel-020 Supervisor (up to 20 arrays) 93A101016

Datalogic WebSentinel-032 Supervisor (up to 32 arrays) 93A101017

Datalogic WebSentinel-064 Supervisor (up to 64 arrays) 93A101018

Datalogic WebSentinel-128 Supervisor (up to 128 arrays) 93A101019

Datalogic WebSentinel-256 Supervisor (up to 256 arrays) 93A101020

Electrical Connections:

Two 17-pin connectors provide access to the scanner’s local Lonworks network used for both input and output

connections to build a multi-sided or omni-station system.

17-pin Lonworks Connector Pinout

Pin Name Function

A1 GND Supply voltage (negative pin)

A2 VS Supply voltage 20 to 30 Vdc (positive pin)

Cable shield A - internally connected by

1 CHASSIS capacitor to chassis

2 n.c. Not connected

Cable shield B - internally connected by

3 CHASSIS capacitor to chassis

4 TXAUX Transmit data of auxiliary RS232

(referred to SGND)

5 SGND Signal ground (connected to GND)

6 RXAUX Receive data of auxiliary RS232

(referred to SGND)

7 VS_I/O Supply voltage of I/O circuit

8 Lon A+ Lonworks a line (positive pin)

9 Lon A- Lonworks a line (negative pin)

10 Lon B+ Lonworks b line (positive pin)

11 Lon B- Lonworks b line (negative pin)

12 SYS_I/O System signal

13 SYS_ENC_I/O System signal

14 Reserved Internally connected

15 Ref_I/O Reference voltage of I/O circuit

A1 A2

Female - Output

A1 A2

Male - Input

17-pin Local Lonworks Connectors

DS8100A-3002 QUICK GUIDE

Connectivity:

DS8100A-3002 Typical Layout

Conveyor

SC6000

Extended I/O

Host

HUB

ETHERNET

SC6000 AUX

CAB-SC6003

CAB-SC6013

Power/Net

VAC INPUT

CAB-SC6103

Cable

PWO

LONWORKS

ENCODER

PS Aux

CAB-850x

CAB-850x CAB-850x

CAB-850x

up to 3

scanners

per

branch

BTK8500

Bus Return

DX8200A-3002

DS8100A-3002

CAB-850x

up to 4

scanners per

branch

BTK8500

Bus Return

DX8200A-3002 DX8200A-3002

DS8100A-3002

CAB-850x

DS8100A-3002 QUICK GUIDE

Example of Redundant System Layout

AUX

CAB-SC6103

Extended I/O

ETHERNET

SC6000

CAB-SC6003

CAB-SC6013

Power/Net

VAC INPUT

PWO

LONWORKS

ENCODER

PS Aux

CAB-850x

BTK8500

CAB-850x

CAB-850x CAB-850x

Extended I/O

ETHERNET

SC6000

CAB-SC6003

CAB-SC6013

Power/Net

VAC INPUT

PWO

CAB-PWO 03

Redundancy

CAB-850x

CAB-850x CAB-850x BTK8500

DX8200A-3002

ENCODER

PS Aux

LONWORKS

Working

Controller

Protecting

Controller

to Host

DX8200A-3002

DX8200A-3002 DX8200A-3002 DS8100A-3002 DS8100A-3002

DS8100A-3002 DS8100A-3002

DS8100A-3002 QUICK GUIDE

Example of Redundant System

DS8100A-3002 QUICK GUIDE

Mechanical Installation:

DS8100A-3002 can be installed to operate in any position. There are 16 screw holes (M6 X 8) on the sides of the

scanner for mounting. The following diagrams give the overall dimensions of the reader standard model and

mounting bracket. They may be used for their installation:

127

[4.98]

173

[6.79]

217

[8.54]

[1.97]

[2.66]

45°

[1.84]

45°

[1.97]

[1.84]

[2.66]

M6 N°16

inch

164

[6.45]

[0.19]

100

[3.93]

[1.18]

[0.63]

100

[0.59]

R 15

[1.88]

[0.59]

R 15 N°4

[3.93]

[0.59]

164

[6.45]

[3.15]

[1.77]

17.5

[0.68]

8.5 N°4

[0.33]

DS8100A-3002 Overall Dimensions ST-163 Mounting Bracket Overall Dimensions

WARNING

When installing several scanners, take care to position them correctly so that no laser beam

enters the reading window perpendicularly and at the same level of the output beam of the

other scanners. This condition could occur more frequently for side mounted applications. If

these precautions are not followed, it may occur that the laser of the blinded scanner starts

blinking due to an internal circuit which temporarily turns the laser off when detecting a power

anomaly. To resolve this problem, it is sufficient to slightly change the inclination and position

of one of the two scanners involved.

inch

DS8100A-3002 QUICK GUIDE

Reading Diagrams:

Note: (0,0) is the center of the laser beam output window.

DS8100A-3002 – 0.50 mm/20 mils

CONDITIONS

Code = Interleaved 2/5 or Code 39

PCS = 0.90

“Pitch“ angle = 0°

“Skew“ angle = 10°

“Tilt“ angle = 0°

(in)

015 32 (in)

24 40

040 60 (cm)

-10

(cm)

80 100 120 140

48 56

160

-40

-30

-20

-60

-50

-12

-8

-4

-20

-16

-24

Safety Precautions:

Figure A

Laser Safety Label

Warning and Device Class Label

Identification Label

The scanner is classified as a Class 2 laser product according to EN60825-1 regulations and as a Class II laser

product according to CDRH regulations.

Disconnect the power supply when opening the device during maintenance or installation to avoid exposure to

hazardous laser light.

There is a safety device, which allows the laser to be switched on only if the motor is rotating above the threshold

for its correct scanning speed.

DS8100A-3002 QUICK GUIDE

The laser beam can be switched off through a software command (see also the Genius™ Help On-Line).

AVOID EXPOSURE

LASER LIGHT IS EMITTED

FROM THIS APERTURE

CAUTION-CLASS 3B

LASER LIGHT

WHEN OPEN

AVOID

EXPOSURE TO BEAM

AVOID EXPOSURE

LASER RADIATION IS EMITTED FROM THIS APERTURE

Laser Safety Label

LASER LIGHT

DO NOT STARE INTO BEAM

CLASS 2 LASER PRODUCT

MAXIMUM OUTPUT RADIATION 1 mW

EMITTED WAVELENGTH 630~680 nm

TO EN 60825-1:2001

Model No. Amp.

Serial No.

DATALOGIC S.P.A. Via Candini, 2

40012 Calderara di Reno - Bologna - Italy

Manufactured Volt

This product conforms to the applicable requirements

of 21CFR1040 at the date of manufacture.

Warning and Device Class Label Device Identification Label

The laser diodes used in this device are classified as Class 3B laser products according to EN 60825-1

regulations and as Class IIIb laser products according to CDRH regulations. Any violation of the optic parts in

particular can cause radiation up to the maximum level of the laser diode (30 mW at 630~680 nm).

Power Supply

This product is intended to be installed by Qualified Personnel only.

This scanner is intended to be supplied by either a UL Listed power supply marked 'Class 2' or 'LPS', output rated

20 - 30 V dc, minimum 1.5 A or by a UL Listed computer with LPS outputs.

DS8100A-3002 must be supplied by a Class II Power Supply Unit conforming to the EN 60950 safety regulation.

Patents:

This product is covered by one or more of the following patents.

U.S. patents: Re. 36,251; 5,483,051; 5,992,740; 6,177,979 B1; 6,347,740 B1; 6,394,352 B1; 6,443,360 B1;

6,527,184 B1; 6,629,639 B2; 6,688,524 B1; 6,742,710 B2; 7,161,685 B1; 5,028,772; 5,124,538; 5,466,921;

5,548,107; 6,206,289 B1; 6,669,091 B2; 7,000,838 B2.

European patents: 652,530 B1; 789,315 B1; 851,376 B1; 926,615 B1; 959,426 B9; 1,363,228 B1.

Japanese patents: 3,793,585; 4,033,958.

Additional patents pending.

Altri manuali per DS8100A-3002

Indice

Altri manuali Datalogic Lettore di codici a barre

Datalogic

Datalogic QuickScan QD2590 Manuale di installazione e funzionamento

Datalogic

Datalogic QuickScan 21 Series Manuale utente

Datalogic

Datalogic Touch 90 pro Manuale di installazione e funzionamento

Datalogic

Datalogic Gryphon GFE4400 Guida rapida alla configurazione

Datalogic

Datalogic Gryphon I GD44XX Manuale utente

Datalogic

Datalogic DX8200A Manuale utente

Datalogic

Datalogic GRYPHON BT SH3500 Manuale utente

Datalogic

Datalogic DS2100 Manuale utente

Datalogic

Datalogic Gryphon I GD44XX Manuale di installazione e funzionamento

Datalogic

Datalogic PowerScan M8500 Manuale utente

Datalogic

Datalogic PowerScan Retail PBT9501-RT Manuale utente

Datalogic

Datalogic Cobalto C05300 Manuale di installazione e funzionamento

Datalogic

Datalogic Magellan 2200VS/2300HS Manuale di installazione e funzionamento

Datalogic

Datalogic Quickscan I Manuale utente

Datalogic

Datalogic Magellan 2300HS Manuale utente

Datalogic

Datalogic Gryphon GD4200 Manuale di installazione e funzionamento

Datalogic

Datalogic DX8200A Manuale utente

Datalogic

Datalogic Gryphon I GD44 Series Manuale utente

Datalogic

Datalogic Hand-Held Devices II Foglio di istruzioni

Datalogic

Datalogic PowerScan PD9530 Manuale utente

Datalogic

Datalogic MAGELLAN 3200VSI Manuale utente

Datalogic

Datalogic PowerScan PD8530 Manuale utente

Datalogic

Datalogic FireScan D111 Series Manuale utente

Datalogic

Datalogic Heron HD3130 Manuale di installazione e funzionamento

Manuali Lettore di codici a barre popolari di altre marche

POSMicro

POSMicro Datalogic PowerScan D7100 Manuale utente

Marson

Marson MT780 Guida rapida alla configurazione

NCR

NCR RealPOS Manuale utente

Motorola

Motorola SE3300 Guida rapida alla configurazione

Element

Element P130BT Manuale utente

Motorola

Motorola Symbol LS3008 Manuale di installazione e funzionamento

Meec tools

Meec tools OBD-II / VAG Manuale utente

SICK

SICK CLP 100 Manuale utente

Royal Tag SA

Royal Tag SA I-Read Manuale utente

Welch Allyn

Welch Allyn IMAGETEAM 3800 Manuale utente

Meteor

Meteor 8310 Manuale utente

Denso

Denso BHT-500B Manuale utente

Motorola

Motorola MP6000 Istruzioni di montaggio

Newland

Newland NLS-HR15-BT Manuale utente

ARTDEV

ARTDEV AS-1310 Manuale utente

Aopos

Aopos AS290 Manuale utente

ENS

ENS 367-5455 Manuale utente

Atid

Atid AT188N Plus Manuale utente
