Definitive Technology AW6500 Manuale utente

NEW CUSTOM LOUDSPEAKER

EXCITEMENT FROM DEFINITIVE

•New Reference Ceiling Speaker III and

Reference Surround Speaker III Ultimate

Home Theater Architectural Loudspeakers

•New All Weather Ultimate Performance

Outdoor Loudspeakers

•New Mythos Ten On-Wall L/C/R Loudspeaker

MYTHOS TEN

AW5500/6500

RCS III

DEFINITIVE TECHNOLOGY PRESENTS:

The Future of

High Performance

Loudspeakers

Legendary Mythos®Performance for Large Flat Panel TVs

Deﬁnitive Technology has done it again! The Mythos Ten is the newest member of the critically

acclaimed Mythos line of high performance loudspeakers. Mythos Ten is perfectly proportioned to

match 55" and larger ﬂat panel video displays and is the perfect center channel complement to the

astounding Mythos ST SuperTowers®for a truly state-of-the-art home theater system. Through the use

of advanced driver and enclosure technologies used in the top-of-the-line award-winning Mythos ST,

the Mythos Ten achieves a level of performance never before available in on-wall loudspeakers.

Each Mythos®Ten contains two high-deﬁnition Balanced Double Surround System (BDSS) 51/4"drivers

(patent pending) that arepressure-coupled to two 5" x 8" racetrack-shaped planar Low-Bass Radiators

for a total bass radiating surface greater than that of a 12" conventional woofer. The result is bass

extension and power unheard of in a slim on-wall loudspeaker. The bass roll-off of the

Mythos Ten is smooth and controlled, allowing it to seamlessly blend with a

powered subwoofer, such as Deﬁnitive’s SuperCubes, for audiophile-grade home

theater power and precision.

The two active 51/4"drivers surround a new generation Pure Aluminum dome tweeter,

the same used in Deﬁnitive’sMythos®ST SuperTowers®.This remarkable new tweeter

incorporates a new voice coil, new dome, new surround, and an acoustically con-

toured faceplate for unequaled high frequency extension, detail, and smoothness.

Mythos Series enclosures are hand-polished gloss Black or Silver aircraft-grade

extruded aluminum with proprietary damping technologies

that ensure total rigidity. All components are mounted on a

resonance-free PolyStone baffle. These rock-solid construction

technologies along with state-of-the-art drivers and tweeter

serve to deliver classic Deﬁnitive Technology sound quality:

wide soundstage, pinpoint imaging, high dynamic impact,

and superb realism.

MYTHOS TEN SPECIFICATIONS

Dimensions: 61/16"Wx43/8"Dx341/2" H

Driver Complement:

– Two 51/4"BDSS cast basket bass/mid drivers

– Two 5" x 8" pressure-driven low-bass radiators

–One 1" PureAluminum dome tweeter

Frequency Response: 31 Hz – 30 kHz

Nominal Impedance: Compatible with 4 – 8 ohm outputs

Recommended Ampliﬁcation: 10 – 300 Watts/channel

Sensitivity: 93 dB

Mounting Options: Stainless Steel wall mount bracket and

shelf leveling foot included

Available Finishes: polished Silver or gloss Black

MYTHOS TEN

Damped extruded

aluminum enclosure

inpolished Silver or

gloss Black

Racetrack Planar

Low-Bass Radiators

for extended

bass response

Balanced Double

Surround System

high deﬁnition drivers

with cast baskets

New 1" Pure Aluminum

dome tweeter

PolyStone

non-resonant baffle

Built-in-Ceiling Home Theater Sonic Perfection —

Two New Solutions!

Meet two hot additions to the critically acclaimed Reference line of built-in

home theater loudspeakers. The Reference Ceiling Speaker III (RCS III) and

Reference Surround Speaker III are more compact, less expensive versions of

the revolutionary RCS II and RSS II.

Like other models in the Reference Series, both new models use integrated

non-resonant sealed Medite enclosures to deliver the tight, detailed bass and

uncolored midrange of audiophile free-standing speakers. Six rotating dogleg

clamps and beefy wood screws make the RCS and RSS speakers easy to install

and provide secure, non-resonant mounting for ultimate audiophile perform-

ance free of vibrations and buzzes.

The RCS IIIs are in-ceiling front main, center, or surround speakers for built-in

home theater installations. They feature two 41/2"cast basket active drivers

and a Pure Aluminum tweeter on an angled baffle aimed at the listening area.

Proprietary Wave Launch (patent pending) baffle geometry and acoustic

treatment materials serve to create the illusion that the speakers are directly

in front of the listener rather than up in the ceiling. The active drivers are

pressure-coupled to two 51/4"racetrack-shaped Low-Bass Radiators for exceptional

bass and perfect blending with free-standing or built-in subwoofers.

The RSS III is a dedicated bipolar surround speaker that may be ceiling or wall

mounted in new or existing construction. Its bipolar array produces the ideal

balance of direct sound for pinpoint localization and ambient sound for

enveloping spaciousness. Each of the two arrays feature a 31/2"mid/bass driver

pressure-coupled to a 31/2"Low-Bass Radiator with a 1" Pure Aluminum dome

tweeter between the driver and radiator.

All models in the Reference Series share the same driver and tweeter technolo-

gies and can be mixed and matched to assemble a multi-channel system with

seamless channel-to-channel imaging. Add a Deﬁnitive in-wall subwoofer for a

complete audiophile-grade home theater system that is practically invisible!

RCS III &RSS III

“[The RCS IIs are] jaw-droppingly good

home theater speakers that just happen

to live in the ceiling…destined to shift

every paradigm there is regarding

ceiling speakers.”

–Chris Martens, The Perfect Vision

RCS III SPECIFICATIONS

Flange Dimensions: 111/2"Wx111/2" H

Cutout Dimensions: 103/8"Wx103/8"Hx57/8" D

Driver Complement:

–Two 41/2"bass/mid drivers

–Two 51/4"x41/8"pressure-driven low-bass radiators

–One 1" Pure Aluminum dome tweeter

Frequency Response: 30 Hz – 30 kHz,

Nominal Impedance: Compatible with 4 – 8 ohm outputs

Recommended Ampliﬁcation: 10 – 300 Watts/channel

Sensitivity: 92 dB

RSS III SPECIFICATIONS

Flange Dimensions: 97/16"Wx11" H

Cutout Dimensions: 85/16"Wx97/8" H x 37/8" D

Driver Complement:

–Two 31/2"bass/mid drivers

–Two 31/2"pressure-driven low-bass radiators

– Two 1" PureAluminum dome tweeters

Frequency Response: 40 Hz – 30 kHz

Nominal Impedance: Compatible with 4 – 8 ohm outputs

Recommended Ampliﬁcation: 10 – 300 Watts/channel

Sensitivity: 92 dB

RCS III

RSS III

Legendary Deﬁnitive Performance — Outdoors!

Now you can enjoy the incomparable sound of Deﬁnitive

Technology anywhere around your home with the ground-

breaking new AW5500 and AW6500 All-Weather loudspeakers.

These technology-packed wonders feature high excursion active

drivers pressure-coupled to racetrack-shaped Low-Bass Radiators

to give you more than double the bass output while maintaining

aweather-tight seal for ultimate placement ﬂexibility, reliability,

and performance.

With their fully sealed design, aluminum grilles, and rugged

PolyStone enclosures, the AWs can be fully exposed to the elements

and still reliably deliver their indoor speaker sound quality for years

of outdoor listening enjoyment. Their integrated galvanized steel

brackets and unique shape allow a full 360 degrees of rotation

allowing the listener to orient the active drivers towardthe listening

area. Pointing the active driver baffle towards the listener while the

Low-Bass Radiator side faces the wall or ground gives you the ideal

balance of clear mids, extended highs, and thunderous bass even

in the tough acoustic conditions of the great outdoors.

The AW5500 features a 51/4"active driver pressure-coupled to a

5" x 8" Low-Bass Radiator for a total bass radiating area greater

than that of an 8" conventional woofer,while the AW6500’s 61/2"

driver and 51/2"x10" Low-Bass Radiator exceeds the radiating

area of a 10" woofer — imagine all that bass from speakers small

enough to unobtrusively place anywhere. Both AW models

use Deﬁnitive’strademark PureAluminum dome tweeter

for unexcelled high frequency extension and detail.

Now you can have it all — the great sound of Deﬁnitive indoor

speakers on the patio, deck, garden, or in the sauna.

AW5500 SPECIFICATIONS

Dimensions (with wall bracket): 1211/16"Lx73/4" W x 83/16" D

Driver Complement:

–One 51/4"BDSS cast basket bass/mid driver

–One 5" x 8" pressure-driven Low-Bass Radiator

–One 1" PureAluminum dome tweeter

Inputs: Gold-plated 5-way binding posts

Frequency Response: 45 Hz – 30 kHz

Nominal Impedance: Compatible with 4 – 8 ohm outputs

Recommended Ampliﬁcation: 10 – 175 Watts/channel

Sensitivity: 91 dB

AW6500 SPECIFICATIONS

Dimensions (with wall bracket): 147/16" L x 87/8" W x 91/4" D

Driver Complement:

– One 61/2"BDSS cast basket bass/mid driver

– One 51/2"x10" pressure-driven Low-Bass Radiator

– One 1" Pure Aluminum dome tweeter

Inputs: Gold-plated 5-way binding posts

Frequency Response: 40 Hz – 30 kHz

Nominal Impedance: Compatible with 4 – 8 ohm outputs

Recommended Ampliﬁcation: 10 – 200 Watts/channel

Sensitivity: 92 dB

11433 Cronridge Drive, Owings Mills, Maryland 21117, U.S.A.

(410) 363-7148 • www.deﬁnitivetech.com

AW5500 &AW6500

New 1" Pure Aluminum

dome tweeter

Balanced Double

Surround System

high deﬁnition driver

with cast basket

Racetrack Planar Low-Bass

Radiator for exceptional

bass output

PolyStone non-resonant,

air and water-tight

enclosure

Drainage channels

(not pictured) prevent

water buildup around

input terminals

AW5500

AW6500
