Delta Electronics AC Motor Drive VFD-G Manuale utente

Preface

Thank you for choosing DELTA’s VFD-G Series for plastic molding and air compressors machinery.

The VFD-G Series is manufactured with high-quality components and materials and incorporates the

latest microprocessor technology available.

This manual is to be used for the installation, parameter setting, troubleshooting, and daily

maintenance of the AC motor drive. To guarantee safe operation of the equipment, read the following

safety guidelines before connecting power to the AC motor drive. Keep this operating manual at hand

and distribute to all users for reference.

To ensure the safety of operators and equipment, only qualified personnel familiar with AC motor

drive are to do installation, start-up and maintenance. Always read this manual thoroughly before

using VFD-G series AC Motor Drive, especially the WARNING, DANGER and CAUTION notes.

Failure to comply may result in personal injury and equipment damage. If you have any questions,

please contact your dealer.

PLEASE READ PRIOR TO INSTALLATION FOR SAFETY.

DANGER!

1. AC input power must be disconnected before any wiring to the AC motor drive is made.

2. A charge may still remain in the DC-link capacitors with hazardous voltages, even if the power

has been turned off. To prevent personal injury, please ensure that power has been turned off

before opening the AC motor drive and wait ten minutes for the capacitors to discharge to safe

voltage levels.

3. Never reassemble internal components or wiring.

4. The AC motor drive may be destroyed beyond repair if incorrect cables are connected to the

input/output terminals. Never connect the AC motor drive output terminals U/T1, V/T2, and

W/T3 directly to the AC mains circuit power supply.

5. Ground the VFD-G using the ground terminal. The grounding method must comply with the

laws of the country where the AC motor drive is to be installed. Refer to the Basic Wiring

Diagram.

6. VFD-G series is used only to control variable speed of 3-phase induction motors, NOT for 1-

phase motors or other purpose.

7. VFD-G series shall NOT be used for life support equipment or any life safety situation.

WARNING!

1. DO NOT use Hi-pot test for internal components. The semi-conductor used in the AC motor

drive is easily damaged by high-pressure.

2. There are highly sensitive MOS components on the printed circuit boards. These components

are especially sensitive to static electricity. To prevent damage to these components, do not

touch these components or the circuit boards with metal objects or your bare hands.

3. Only qualified persons are allowed to install, wire and maintain AC motor drives.

CAUTION!

1. Some parameter settings will cause the motor to run immediately after applying power.

2. DO NOT install the AC motor drive in a place subjected to high temperature, direct sunlight,

high humidity, excessive vibration, corrosive gases or liquids, or airborne dust or metallic

particles.

3. Only use AC motor drives within specification. Failure to comply may result in fire, explosion or

electric shock.

4. To prevent personal injury, please keep children and unqualified people away from the

equipment.

5. When the motor cable between the AC motor drive and motor is too long, the layer insulation of

the motor may be damaged. Please use a frequency inverter duty motor or add an AC output

reactor to prevent damage to the motor. Refer to appendix B Reactor for details.

6. The rated voltage for the AC motor drive must be ≤480V for 460V models and the mains

supply current capacity must be ≤5000A RMS (≤10000A RMS for the ≥40hp (30kW) models).

Table of Contents

Preface ............................................................................................................. i

Table of Contents .......................................................................................... iii

Chapter 1 Introduction ................................................................................ 1-3

1.1 Receiving and Inspection ................................................................... 1-3

1.1.1 Nameplate Information................................................................ 1-3

1.1.2 Model Explanation ...................................................................... 1-3

1.1.3 Series Number Explanation ........................................................ 1-3

1.1.4 Drive Frames .............................................................................. 1-3

1.2 Appearances ...................................................................................... 1-3

1.3 Remove Instructions........................................................................... 1-3

1.3.1 Remove Keypad ......................................................................... 1-3

1.3.2 Remove Front Cover................................................................... 1-3

1.4 Lifting.................................................................................................. 1-3

1.5 Preparation for Installation and Wiring ............................................... 1-3

1.5.1 Ambient Conditions..................................................................... 1-3

1.5.2 Minimum Mounting Clearances................................................... 1-3

1.6 Dimensions......................................................................................... 1-3

Chapter 2 Installation and Wiring .............................................................. 2-3

2.1 Wiring ................................................................................................. 2-3

2.2 External Wiring ................................................................................... 2-3

2.3 Main Circuit Connection......................................................................2-3

2.4 Control Terminals ...............................................................................2-3

2.5 Specification for main circuit terminals and control terminals..............2-3

2.6 Wiring Explanation for Analog Input Terminal.....................................2-3

Chapter 3 Keypad and Start Up ..................................................................3-3

3.1 Digital Keypad VFD-PU01 ..................................................................3-3

3.1.1 Description of the Digital Keypad ................................................ 3-3

3.1.2 How to Operate the Digital Keypad VFD-PU01 ........................... 3-3

3.1.3 VFD-PU01 Dimensions ............................................................... 3-3

3.1.4 Reference Table for the LED Display of the Digital Keypad ........ 3-3

3.2 Operation Method ...............................................................................3-3

3.3 Trial Run .............................................................................................3-3

Chapter 4 Parameters..................................................................................4-3

4.1 Summary of Parameter Settings.........................................................4-3

4.2 Parameter Settings for Applications....................................................4-3

4.3 Description of Parameter Settings ......................................................4-3

Chapter 5 Troubleshooting .........................................................................5-3

5.1 Over Current (OC) ..............................................................................5-3

5.2 Ground Fault.......................................................................................5-3

5.3 Over Voltage (OV) ..............................................................................5-3

5.4 Low Voltage (Lv).................................................................................5-3

5.5 Over Heat (OH)...................................................................................5-3

5.6 Overload .............................................................................................5-3

5.7 Keypad Display is Abnormal ...............................................................5-3

5.8 Phase Loss (PHL)...............................................................................5-3

5.9 Motor cannot Run............................................................................... 5-3

5.10 Motor Speed cannot be Changed..................................................... 5-3

5.11 Motor Stalls during Acceleration....................................................... 5-3

5.12 The Motor does not Run as Expected .............................................. 5-3

5.13 Electromagnetic/Induction Noise ...................................................... 5-3

5.14 Environmental Condition .................................................................. 5-3

5.15 Affecting Other Machines ................................................................. 5-3

Chapter 6 Fault Code Information and Maintenance................................ 6-3

6.1 Fault Code Information....................................................................... 6-3

6.1.1 Common Problems and Solutions............................................... 6-3

6.1.2 Reset .......................................................................................... 6-3

6.2 Maintenance and Inspections............................................................. 6-3

Appendix A Specifications ........................................................................ A-3

Appendix B Accessories ........................................................................... B-3

B.1 All Brake Resistors & Brake Units Used in AC Motor Drives..............B-3

B.2 Non-fuse Circuit Breaker Chart ..........................................................B-3

B.3 Fuse Specification Chart ....................................................................B-3

B.4 AC Reactor ........................................................................................B-3

B.4.1 AC Input Reactor Recommended Value..................................... B-3

B.4.2 AC Output Reactor Recommended Value.................................. B-3

B.4.3 Applications ................................................................................ B-3

B.5 Zero Phase Reactor (RF220X00A) ....................................................B-3

B.6 PU06..................................................................................................B-3

B.6.1 Description of the Digital Keypad VFD-PU06 .............................B-3

B.6.2 Explanation of Display Message.................................................B-3

B.6.3 PU06 Operation Flow Chart........................................................B-3

Appendix C How to Select the Right AC Motor Drive .............................. C-3

C.1 Capacity Formulas ............................................................................ C-3

C.2 General Precaution ........................................................................... C-3

C.3 How to Choose a Suitable Motor....................................................... C-3

Revision July 2008, EG03, SW V1.06 1-1

Chapter 1 Introduction

1.1 Receiving and Inspection

This VFD-G AC motor drive has gone through rigorous quality control tests at the factory before

shipment. After receiving the AC motor drive, please check for the following:

Check to make sure that the package includes an AC motor drive, the User Manual/Quick Start

and CD, dust covers and rubber bushings.

Inspect the unit to assure it was not damaged during shipment.

Make sure that the part number indicated on the nameplate corresponds with the part number of

your order.

1.1.1 Nameplate Information

Example for 10HP/7.5kW 3-phase 460V AC drive

MODE : VFD075F43A-G

INPUT : 3PH 380-480V 50/60Hz 19.0A

OUTPUT : 3PH 0-480V 18A 14kVA 10HP

Freq. Range : 0.1~120.00Hz

ENCLOSURE: TYPE 1

075F43AG4T5010001

AC Drive Model

Input Spec.

Output Spec.

Output Frequency Range

Bar Code

Enclosure type

Serial Number

1.1.2 Model Explanation

VFD AG-

Version Type

Input Voltage

43:Three phase 460V

Applicable motor capacity

Series

Name

VFD-G series

055:7.5HP(5.5kW) 075:10HP(7.5kW) 110:15HP(11kW)

150:20HP(15kW) 185:25HP(18.5kW) 220:30HP(22kW)

300:40HP(30kW) 370:50HP(37kW) 450:60HP(45kW)

550:75HP(55kW) 750:100HP(75kW) 900:125HP(90kW)

1100:150HP(110kW) 1320:175HP(132kW) 1600:215HP(160kW)

1850:250HP(185kW) 2200:300HP(220kW)
