Delta Electronics AFB04512HB Manuale

45 x 45 x 15 MM SERIES

AFB

DIMENSIONS DRAWING

P & Q CURVE (AT RATED VOLTAGE) MOUNTING PANEL CUTOUT

OUTLET SIDE INLET SIDE

http://www.deltaww.com

* Rib type only

* The max. air flow and the speed are measured in free air ; max. air pressure is measured at zero air flow.

* Noise is measured in anechoic chamber in free air, one meter from intake side.

* All readings are typical values at rated voltage.

* Specifications are subject to change without notice.

Bearing Type

Ball Bearings

Material

Impeller & Frame : Plastic(UL 94V-0)

Lead Wires :

UL 1007 AWG #24 OR Equivalent

Red Wire Positive(+)

Black Wire Negative(-)

Weight : 17 g (0.60 OZ)

New

Operating

Voltage

Range

MODEL Rated

Voltage

Maximum

Air Flow

Speed

Maximum

Air Pressure Noise

PART NO. FUNCTION VDC VDC Amp Watt R.P.M. CFM mmH O IN H O dB-A

AFB04512LB -R00 / -F00 12 5.0 to 13.8 0.09 1.08 4300 0.268 9.48 2.65 0.104 23.5

AFB04512MB -R00 / -F00 12 5.0 to 13.8 0.10 1.20 5300 0.328 11.59 4.07 0.160 29.0

AFB04512HB -R00 / -F00 12 5.0 to 13.8 0.14 1.68 6300 0.396 14.00 5.66 0.223 33.5

Air Flow

Air Pressure

0.08

0.04

0.12

0.36

0 4.0

00.12

8.0 12.0

0.24

2.0

1.0

3.0

20.016.0

0.48 0.60

0.24

0.16

0.20

6.0

4.0

5.0

AFB04512XB

(CFM)

(M /MIN)

(IN H O)

(mm H O)

UNIT: (INCH)

LABEL

(1.772 0.020)

(1.457 0.012)

37.0 0.3

45.0 0.5

(1.772 0.020)

45.0 0.5

(1.457 0.012)

37.0 0.3

(4- 0.126 0.012)

4- 3.2 0.3

(0.591 0.020)

15.0 0.5

(2-0.118 0.020)

2-3.0 0.3

335.0 10.0

(13.189 0.394)

10.0

(0.394)

(INCH)

UNIT:

( 1.850)

47.0

43.0

37.0

(1.457)

(1.693)

43.0

37.0

(1.693)

(1.457)

(4- 0.134)

4- 3.4

( 1.850)

47.0

43.0

37.0

(1.457)

(1.693)

43.0

37.0

(1.693)

(1.457)

(4- 0.134)

4- 3.4

Input

Power

Input

Current
