Delta Electronics BFB1012H Manuale

97 x 94 x 33 MM SERIES

BFB

DIMENSIONS DRAWING

Bearing Type

Ball Bearings

Material

Impeller & Frame : Plastic (UL 94V-0)

Lead Wires :

UL 1007 AWG #24 O Equivalent

Red Wire Positive (+)

Black Wire Negative (-)

Weight : 160g (5.64 oz)

Operating

Voltage

Range

MODEL Rated

Voltage

Maximum

Air Flow

Speed

Maximum

Air Pressure

Noise

FUNCTION VDC VDC Amp Watt R.P.M. 3

m /min CFM mmH

2O IN H2

O dB-A

P & Q CURVE (AT RATED VOLTAGE)

111

58.9

( 2.319)

( 1.787)

45.4

(1.260 0.012)

32.0 0.3

(2- 0.177 0.012)

2- 4.5 0.3

(1.535 0.012)

39.0 0.3

(3.827)

97.2

(3.717)

(1.260 0.012)(2.047 0.020)

94.4

32.0 0.3 52.0 0.5

(1.535 0.012)

(1.969 0.020)

39.0 0.3

50.0 0.5

(12.795 0.394)

(0.394)

325.0 10.0

10.0

(2.280 0.020)

(2.122)

2-2.0 0.5

(2-0.079 0.020)

57.9 0.5

53.9

(1.299 0.020)

33.0 0.5

(1.154) (0.073 0.020)

(0.073 0.020)

1.85 0.5 1.85 0.5

29.3

(INCH)

UNIT:

PART NO.

BFB1012L -R00 / -F00 12 4.0 to 13.8 0.32 3.84 2700 0.540 19.07 12.70 0.500 45.0

BFB1024L -R00 / -F00 24 7.0 to 27.6 0.16 3.84

BFB1012M -R00 / -F00 12 4.0 to 13.8 0.57 6.84 3200 0.640 22.60 19.00 0.748 49.0

BFB1024M -R00 / -F00 24 7.0 to 27.6 0.26 6.24

BFB1012H -R00 / -F00 12 4.0 to 13.8 0.80 9.60 3600 0.720 25.43 25.40 1.000 52.0

BFB1024H -R00 / -F00 24 7.0 to 27.6 0.40 9.60

BFB1012HH -R00 / -F00 12 4.0 to 13.2 1.10 13.20 4000 0.800 28.25 33.00 1.299 55.0

BFB1024HH -R00 / -F00 24 7.0 to 27.6 0.55 13.20

* Function type is optional.

* The max. air flow and the speed are measured in free air ; max. air pressure is measured at zero air flow.

* Noise is measured in anechoic chamber in free air, one meter from intake side.

* All readings are typical values at rated voltage.

* Specifications are subject to change without notice.

(M /MIN)

(IN H O)

(mm H O)

1.44

1.20

0.96

0.72

0.48

0.24

Air Pressure

32.024.016.08.00

Air Flow

(CFM)

BFB1012/24X

0 0.2 0.4 0.80.6 1.0

36.0

30.0

24.0

12.0

6.0

18.0

http://www.deltaww.com

Input

Power

Input

Current

97 x 94 x 33 MM SERIES

BFB

DIMENSIONS DRAWING

Bearing Type

Ball Bearings

Material

Impeller & Frame : Plastic (UL 94V-0)

Lead Wires :

UL 1007 AWG #24 OR Equivalent

Red Wire Positive (+)

Black Wire Negative (-)

Weight : 166g (5.85 oz)

* Function type is optional.

* The max. air flow and the speed are measured in free air ; max. air pressure is measured at zero air flow.

* Noise is measured in anechoic chamber in free air, one meter from intake side.

* All readings are typical values at rated voltage.

* Specifications are subject to change without notice.

P & Q CURVE (AT RATED VOLTAGE)

UNIT: (INCH)

Operating

Voltage

Range

MODEL Rated

Voltage

Maximum

Air Flow

Speed

Maximum

Air Pressure

Noise

PART NO.

REV.

FUNCTION

VDC VDC Amp Watt R.P.M. 3

m /min CFM mmH

2O IN H2

O dB-A

BFB1012L -A R00/F00 12 4.0 to 13.2 0.37 4.44 2700 0.656 23.17 14.85 0.585 49.5

BFB1012M -A R00/F00 12 4.0 to 13.2 0.55 6.60 3200 0.777 27.44 22.68 0.893 52.5

112

(mm H O)

(IN H O)

2.88

2.4

1.92

1.44

0.96

0.48

Air Pressure

48.036.024.012.00

Air Flow

(CFM)

(M /MIN)

BFB1012X/24-A

0 0.3 0.6 1.20.9 1.5

72.0

60.0

48.0

24.0

12.0

36.0 L

http://www.deltaww.com

Input

Power

Input

Current

97 x 94 x 33 MM SERIES

BFB

DIMENSIONS DRAWING

Bearing Type

Ball Bearings

Material

Impeller & Frame : Plastic (UL 94V-0)

Lead Wires :

UL 1007 AWG #24 OR Equivalent

Red Wire Positive (+)

Black Wire Negative (-)

Weight : 180g (6.35 oz)

* Function type is optional.

* The max. air flow and the speed are measured in free air ; max. air pressure is measured at zero air flow.

* Noise is measured in anechoic chamber in free air, one meter from intake side.

* All readings are typical values at rated voltage.

* Specifications are subject to change without notice.

P & Q CURVE (AT RATED VOLTAGE)

UNIT: (INCH)

Operating

Voltage

Range

MODEL Rated

Voltage

Maximum

Air Flow

Speed

Maximum

Air Pressure

Noise

PART NO.

REV.

FUNCTION

VDC VDC Amp Watt R.P.M. 3

m /min CFM mmH

2O IN H2

O dB-A

BFB1012HH -A R00/F00 12 7.0 to 13.2 1.25 15.00 4000 0.971 34.28 39.70 1.564 57.0

BFB1012VH -A R00/F00 12 7.0 to 13.2 1.50 18.00 4500 1.075 37.97 49.58 1.952 60.0

BFB1012SH -A R00/F00 12 7.0 to 12.6 2.00 24.00 5000 1.179 41.65 64.23 2.529 63.0

BFB1012EH -A R00/F00 12 7.0 to 12.6 2.45 29.40 5300 1.302 46.00 71.48 2.814 64.0

113

(IN H O)

(mm H O)

Air Flow

0.3

12.0

Air Pressure

12.0

0.48

36.0

24.0

48.0

0.96

1.44

1.92

0.9

36.0

0.6

24.0

1.2

48.0

(M /MIN)

(CFM)

72.0

2.88 BFB1012/24X-A

60.0

2.4

1.5

http://www.deltaww.com

Input

Power

Input

Current
