Denver BPS-354 Manuale utente

Instruction manual

BLUETOOTH SPEAKER

BLUETOOTH

CONNECTION

MP3 PLAYER

USB/MICRO SD

CARD READER

AUX IN

https://facebook.com/Denver.eu

BPS-354

Control Panel:

: Press and hold the button to

POWER ON/OFF.

2. MODE: Switches between different

modes.

3. LED: Press the button to select the LED

light mode; press and hold to turn off the

light.

4. VOLUME: Rotate the volume knob to

the left to decrease volume, and to the

right to increase volume.

5. PREV: Previous song.

6. NEXT: Next song.

7. PLAY: Press to play/pause playback.

8. USB: USB jack.

9. TF CARD: MicroSD card slot.

10. AUX: Aux Input.

11. MIC: Microphone input.

12. DC IN: Charging port.

Remote control:

1. On/Off Switch;

2. MODE: to switch between the modes;

3. MUTE: to mute;

: press to play/pause music.

5. EQ: to set the equalizer variants;

6. 0-9: to select a song directly;

7. RPT: to repeat the song;

：to select the previous song from

USB / MicroSD/ BT;

9. : to select the next song from

USB/MicroSD/ BT;

10. VOL+: to increase volume;

11. VOL-: to decrease volume;

12. Switch between USB and MicroSD

card.

1 2 3

FUNCTION DESCRIPTION

1. Charge the speaker

To charge the speaker’s built-in battery, connect power adaptor (not supplied) to the charging port.

The battery indicator LED will flash when charging, and will stop flashing when fully charged.

2. Bluetooth function

Power on the product then press MODE button to enter BT mode.

Put your mobile device (cell phones, computers, etc.) into BT pairing mode, search for BT

devices, and select the item name (Denver BPS-354) when it appears.

After the device has been paired successfully for the first time, it will connect automatically in

around 10 seconds to the device last connected when next time use. (Note: The product can

connect to only one Bluetooth device at a time.).

3. TWS Function

Power on two speakers and enter Bluetooth mode.

Turn off the Bluetooth function on your phone or other Bluetooth device. Press and hold the Play /

Pause button of either speaker, the display will show “ON” and the “bLUE” will be flashing. A different

beep will then be heard to signify that the two speakers have connected via Bluetooth.

Turn on Bluetooth on the mobile phone and search for “Denver BPS-354” and connect.

A beep will then be heard signifying that the mobile has connected to the speakers. You can now

enjoy music from the two speakers.

4. USB mode

1. Insert a USB device into the speaker's USB port.

2. Press MODE to switch to USB mode.

3. Press the PLAY / PAUSE button to play or pause the music.

5. Auxiliary input mode

1. Connect a 3.5 mm audio cable to the unit's auxiliary input.

2. Press MODE to switch to auxiliary input mode.

3. Use the controls of the connected device to select and play the audio.

6. MicroSD card mode

1. Insert a MicroSD card, MicroSD card mode will start automatically.

2. Press MODE to switch to MicroSD card input mode.

3. Press the PLAY / PAUSE button to play or pause the music.

Please notice - All products are subject to change without any notice. We take reservations for errors

and omissions in the manual.

Electric and electronic equipment and included batteries contains materials, components and

substances that can be hazardous to your health and the environment, if the waste material

(discarded electric and electronic equipment and batteries) is not handled correctly.

Electric and electronic equipment and batteries is marked with the crossed out trash can symbol,

seen above. This symbol signifies that electric and electronic equipment and batteries should not be

disposed of with other household waste, but should be disposed of separately.

As the end user it is important that you submit your used batteries to the appropriate and designated

facility. In this manner you make sure that the batteries are recycled in accordance with legislature

and will not harm the environment.

All cities have established collection points, where electric and electronic equipment and batteries

can either be submitted free of charge at recycling stations and other collection sites, or be collected

from the households. Additional information is available at the technical department of your city.

Hereby, Denver A/S declares that the radio equipment type BPS-354 is in compliance with Directive

2014/53/EU. The full text of the EU declaration of conformity is available at the following internet

address: denver.eu and then click the search ICON on topline of website. Write model number:

BPS-354. Now enter product page, and RED directive is found under downloads/other downloads.

Operating Frequency Range: 20Hz-20KHz

Max Output Power: 200W

DENVER A/S

Omega 5A, Soeften

DK-8382 Hinnerup

Denmark

www.facebook.com/denver.eu
