COMMERCIAL WASHER

MODEL T-300/350/350SWD VENDED

C-SERIES CONTROL – 50Hz, (Lower Extr ct)

OPERATOR’S MANUAL

INSTALLATION & OPERATION

INSTRUCTIONS

Please read this information and retain for reference.

WARNING - HIS WASHER IS EQUIPPED WI H DEVICES AND FEA URES RELA ING O I S SAFE

OPERA ION. O AVOID INJURY OR ELEC RICAL SHOCK, DO NO PERFORM ANY SERVICING UNLESS

QUALIFIED O DO SO.

I IS HE RESPONSIBILI Y OF HE OWNER O CHECK HIS EQUIPMEN ON A FREQUEN

BASIS O ASSURE I S SAFE OPERA ION.

A machine should not be allowed to operate if any of the following occur:

- Excessively high water level.

- If machine is not connected to a properly grounded circuit.

- If the door does not remain securely locked during the entire cycle.

- Vibration or shaking from an inadequate mounting or foundation.

WARNING - FOR SAFETY

1. Always shut off power and water supply before servicing.

2. Do not overload the washer.

3. Do not open door when cylinder is in motion or it contains water.

4. Do not bypass any safety devices of this washer.

5. Do not use volatile or flammable substances in or near this washer.

6. Keep all panels in place. hey protect against shock and injury and add rigidity to the washer.

PREVENTIVE MAINTENANCE REQUIREMENTS

DAILY

- Check that the loading door remains securely locked and cannot be opened during an entire cycle.

- Clean the top, front, and sides of the cabinet to remove residue.

- Clean the soap dispenser and lid and check that all dispenser mounting screws are in place and tight.

- Check the loading door for leaks. Clean the door seal of all foreign matter.

- Leave the loading door open to aerate the washer when not in use.

QUARTERLY

- Make sure the washer is inoperative by switching off the main power supply.

- Check the V belts for wear and proper tension.

- Clean lint and other foreign matter from around motor.

- Check all water connections for leaks.

- Check the drain valve for leaking and that it opens properly.

- Wipe and clean the inside of the washer and check that all electrical components are free of moisture and

dust.

- Remove and clean water inlet hose filters. Replace if necessary.

- Check anchor bolts. Retighten if necessary.

IMPORTANT: Replace any and all panels that were removed to perform daily and/or quarterly

maintenance.

8514-302-001 REV B page 2

TABLE OF CONTENTS

Page

No.

Wash

er Specifications

Mounting Dimensions 3

Installation Instructions 7

Operating Instructions 22

Programming the Washer Control 24

Water Level Adjustment 42

Displayed W

asher Faults

Servicing and roubleshooting

Accessor

ies and Contact Information

WASHER SPECIFICATIONS

MODEL

300

10.5

(

LB.

)

WASHER

(Lower Extract Model

)

CAPACI Y

CYLINDER SIZE

ELEC RICAL

DRIVE SYS EM

WASH SPEED

IN ERMEDIA E

EX RAC

FINAL EX RAC

MACHINE CON ROL

WA ER INLE

DRAIN VALVE

10.5 kg/76.5L (23 LBS/2.7 CUBIC F .)

53cm DIA X 34cm DEEP (21” X 13 1/2”)

230 VAC, 50 HZ, 1 PHASE

SOF S AR REVERSING INVER ER DRIVE, 1 HP MO OR

55 RPM

449 RPM (60 G’S)

550 RPM (90 G’S)

PROGRAMMABLE COMPU ER

2 SOLENOID OPERA ED VALVES

FLOW RA E: 35L/MIN (9 GAL/MIN) EACH, 207-827 kPa

(30-120 PSI)

57mm (2 1/4”) DIAME ER

8514-302-001 REV B page 3

MODEL

EXPRESS

and

350SWD E

XPRESS

10.5

kg (

LB.

)

WASHER (Lower Extract Model)

CAPACI Y

CYLINDER SIZE

ELEC RICAL

DRIVE SYS EM

WASH SPEED

IN ERMEDIA E

EX RAC

FINAL EX RAC

MACHINE CON ROL

WA ER INLE

DRAIN VALVE

10.5 kg/76.5L (23 LBS/2.7 CUBIC F .)

53cm DIA. X 34cm DEEP (21” DIA X 13 1/2” DEEP)

230 VAC, 50 HZ, 1 PHASE

SOF S AR REVERSING INVER ER DRIVE, 1 HP MO OR

55 RPM

449 RPM (60 G’S)

777 RPM (180 G’S)

PROGRAMMABLE COMPU ER

2 SOLENOID OPERA ED VALVES

FLOW RA E: 35L/MIN (9 GAL/MIN) EACH, 207-827 kPa

(30-120 PSI)

57mm (2 1/4”) DIAME ER

8514-302-001 REV B page 4

8514-302-001 REV B page 5

8514-302-001 REV B page 6

8514-302-001 REV B page 7

INSTALLATION INSTRUCTIONS

For -350SWD models, this washer may have been purchased as part of a stacked

washer/dryer. In addition to these instructions, please also refer to the installation

instructions that accompany the dryer when installing this product.

All washers must be installed in accordance with all local, state and national building,

electrical, plumbing and other codes in effect in the area.

WARNING - THESE INSTALLATION AND SERVICING

INSTRUCTIONS ARE FOR USE BY QUALIFIED PERSONNEL ONLY.

TO AVOID INJURY AND ELECTRICAL SHOCK DO NOT PERFORM

ANY SERVICING OTHER THAN THAT CONTAINED IN THE

OPERATING INSTRUCTIONS, UNLESS QUALIFIED.

FOUNDA ION REQUIREMEN S

T-300:

his machine is designed for use on or over bare concrete floor - not to be

used above combustible flooring, such as carpet or wood. he washer

must be securely bolted to a substantial concrete floor, or mounted upon

a suitable base that is securely bolted to a substantial concrete floor.

Grouting is highly recommended, especially to the concrete surface. See

Machine Grouting section for details.

T-350 nd T-350SWD:

his machine is designed for use on or over bare concrete floor - not to be

used above combustible flooring, such as carpet or wood. he washer

must be securely bolted nd grouted to a substantial concrete floor or

mounted nd grouted upon a suitable base that is securely bolted nd

grouted to a substantial concrete floor. See Machine Grouting section for

details.

CARE MUS BE AKEN WI H ALL FOUNDA ION WORK O ENSURE A

S ABLE UNI INS ALLA ION, ELIMINA ING POSSIBILI IES OF

EXCESSIVE VIBRA ION.

Allow a minimum 24 inches (610 mm) of clearance behind the rear of the

machine to provide access for motor service.

Installation on an isolated pad is NO recommended. Consult a structural

engineer for installations that will not be tied to a surrounding floor.

8514-302-001 REV B page 8

MOUN ING HEIGH

A concrete pedestal or steel-mounting base that elevates the machine

above the floor level is suggested to provide easy access to the loading

door.

Suggested Amount to Elevate Washer:

-300/350/350SWD: approximately 8 inches (203 mm)

Contact a Dexter laundry equipment distributor for recommended steel

mounting bases. Available steel mounting bases:

Washer Part Number Height

-300 9945-094-003 8” (203 mm) Single Base

-300 9945-094-004 8” (203 mm) Double Base

-350 9945-121-001 8” (203 mm) Single Base

-350 SWD 9945-151-001 6” (152 mm) Single Base

If an elevated concrete pedestal is desired, it should be embedded and

tied into the existing floor. DO NO install a pad on top of the existing

floor. Cut through existing floor as shown below. See Machine Mounting

Detail Figures for floor thickness and bolt sizes.

EXPANSION ANCHORS ARE NO RECOMMENDED FOR USE IN CONCRE E

PEDES ALS BECAUSE HE ANCHORS ARE OO CLOSE O AN EDGE,

CAUSING I O BREAK OU .

FOUNDA ION AND PAD OP IONS

All installations require reinforced concrete floors. Refer to appropriate

model Machine Mounting Detail Figures 1-1, 1-2 and 1-3 for minimum

floor thickness and minimum pad sizes. See mounting diagram for overall

washer dimensions.

Refer to appropriate model Figure 1-4 for side by side mounting

dimensions.

WASHER INS ALLA ION ON EXIS ING FLOOR:

8514-302-001 REV B page 9

WASHER INS ALLA ION ON NEW FLOOR:

NEW PAD IED O EXIS ING FLOOR:

If the existing floor is not reinforced concrete that meets the minimum

thickness requirements, DO NO install a pad on top of the existing floor.

he existing floor and the machine pad must be tied together as one

piece as follows:

1) Cut an opening through the existing floor that is wider and deeper

than the washer as shown below. See Machine Mounting Details for

dimensions.

2) Excavate to a depth that allows for 6” [152] minimum of

compacted fill plus the minimum required concrete thickness. Also

excavate 2” [51] under the existing floor so that the new concrete is

poured under the floor as well.

3) Back fill with clean fill dirt and compact dirt, making sure to allow

for the minimum thickness concrete pad to be poured.

4) Drill holes around the perimeter of the existing floor to install

reinforcing bars to tie the new pad to the existing floor. Drill 2-1/2”

[64] deep into the existing floor on 12” [305] centers around the entire

perimeter.

5) Clean holes and fill half-way with acrylic adhesive rated for

commercial-grade machine installations.

6) Use #4 (60 ksi) reinforcing bar to tie the new pad to the existing

floor. ie the bars together at intersections and use supports to hold

bars in the proper depth in the pad.

7) After adhesive has cured, pour 4000 psi concrete up to level with

the existing floor plus any extra elevated pedestal desired 4-10” [102-

254].

Concrete must be done in one pour so that the entire pad cures as one

piece.

8514-302-001 REV B page 10

NEW PAD IED O EXIS ING FLOOR (LEVEL WI H FLOOR):

NEW RAISED CONCRE E PEDES AL IED O EXIS ING FLOOR:
