DFI CA61 Manuale utente
CA61
Rev. B+
System Board
Users Manual
41730039
Copyright
This publication contains information that is protected by copyright. No
part of it may be reproduced in any form or by any means or used to
make any transformation/adaptation without the prior written permission
from the copyright holders.
This publication is provided for informational purposes only. The
manufacturer makes no representations or warranties with respect to
the contents or use of this manual and specifically disclaims any express
or implied warranties of merchantability or fitness for any particular purpose.
The user will assume the entire risk of the use or the results of the use of
this document.Further,the manufacturer reserves the right to revise this
publication and make changes to its contents at any time, without obligation
to notify any person or entity of such revisions or changes.
All Rights Reserved. © 2000
Trademarks
Microsoft®MS-DOS®, WindowsTM, Windows®95, Windows®98,
Windows®2000 and Windows NT®are registered trademarks of
Microsoft Corporation. Intel®,Pentium®IIIand CeleronTM are registered
trademarks of Intel Corporation.VIA Cyrix®IIIis a registered trademark
of VIA Technologies, Inc. Award is a registered trademark of Award
Software,Inc.Other trademarks and registered trademarks of products
appearing in this manual are the properties of their respective holders.
Caution:
Danger of explosion if battery incorrectly replaced.
Replace only with the same or equivalent type recommended by the
manufacturer.
Dispose of used batteries according to the battery manufacturers
instructions.
FCC and DOC Statement on Class B
This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC rules.
These limits are designed to provide reasonable protection against
harmful interference when the equipment is operated in a residential
installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with
the instruction manual, may cause harmful interference to radio
communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the
following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and the receiver.
Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
Consult the dealer or an experienced radio TV technician for
help.
Notice:
1. The changes or modifications not expressly approved by the
party responsible for compliance could void the user's authority
to operate the equipment.
2. Shielded interface cables must be used in order to comply with
the emission limits.
Table of Contents
Chapter 1 - Introduction
1.1 Features and Specifications ...................................................................
1.2 Package Checklist ........................................................................................
Chapter 2 - Hardware Installation
2.1 System Board Layout ...............................................................................
2.2 System Memory ..........................................................................................
2.3 Frequency Ratio Settings for Processors ....................................
2.4 Factory Testing Jumper ..............................................................................
2.5 Jumper Settings for Selecting the CPUs Front Side Bus......
2.6 Jumper Settings for Clearing CMOS Data ................................
2.7 Jumper Settings for Wake-On-Keyboard/Mouse.......................
2.8 Ports and Connectors ............................................................................
Chapter 3 - Award BIOS Setup Utility
3.1 The Basic Input/Output System .......................................................
3.1.1 Standard CMOS Setup ..........................................................
3.1.2 BIOS Features Setup................................................................
3.1.3 Chipset Features Setup ..........................................................
3.1.4 Power Management Setup ...................................................
3.1.5 PNP/PCI Configuration ..........................................................
3.1.6 Load Fail-Safe Settings .............................................................
3.1.7 Load Optimal Settings ............................................................
3.1.8 Integrated Peripherals ..............................................................
3.1.9 Supervisor Password ...............................................................
3.1.10 User Password .............................................................................
3.1.11 IDE HDD Auto Detection ..................................................
3.1.12 Save & Exit Setup ......................................................................
3.1.13 Exit Without Saving ....................................................................
6
10
31
31
34
38
40
44
46
46
46
51
51
52
53
53
11
12
14
15
16
17
18
19
61
61
63
54
57
59
60
Chapter 4 - Supported Softwares
4.1 Desktop Management Interface .........................................................
4.2 Hardware Doctor Utility ..........................................................................
4.3 VIA®Service Pack .......................................................................................
4.4 Drivers and Utilities Installation Notes ...........................................
Appendix A - System Error Messages
A.1 POST Beep.......................................................................................................................
A.2 Error Messages..............................................................................................................
Appendix B - Troubleshooting
B.1 Troubleshooting Checklist ......................................................................
Introduction
1
6
1.1 Features and Specifications
1.1.1 Features
Chipset
• VIA82C693A and 82C596B (PC-133)
Processor
The system board is equipped with Socket 370 for installing an Intel
CeleronTM FCPGA/PPGA, Pentium®III FCPGA or VIA Cyrix®III
processor. The system board is also equipped with a switching
voltage regulator that supports 1.30V to 2.05V core voltage for
various processors.
• Pentium®III FCPGA: 133MHz FSB (533EB-733EB) or 100MHz
FSB (500E-700E) processor
• CeleronTM 66MHz FSB: FCPGA (566MHz-600MHz) or PPGA
(300A-533MHz) processor
• VIA CyrixIII processor
System Memory
• 16MB to 640MB using VCM (Virtual Channel Memory) or PC
SDRAM DIMM (unbuffered or registered)
• Three 168-pin DIMM sockets
• Uses x64 or x72 PC SDRAM, 3.3V
- PC-66 SDRAM DIMM for 66MHz FSB processors
- PC-100 SDRAM DIMM for 100MHz FSB processors
- PC-133 SDRAM DIMM for 133MHz FSB processors
• ECC supported (uses x72 PC SDRAM DIMM)
Chapter 1 - Introduction
DIMMs
2MBx64/x72
4MBx64/x72
8MBx64/x72
Memory Size
16MB
32MB
64MB
DIMMs
16MBx64/x72
32MBx64/x72
Memory Size
128MB
256MB
1
Introduction
7
Expansion Slots
The system board is equipped with 1 dedicated AGP slot, 3
dedicated PCI slots, 2 dedicated 16-bit ISA slot and 1 shared PCI/
ISA slot. All PCI and ISA slots are bus masters.
Desktop Management Interface (DMI)
The system board comes with a DMI 2.0 built into the BIOS. The
DMI utility in the BIOS automatically records various information
about your system configuration and stores these information in the
DMI pool, which is a part of the system board's Plug and Play
BIOS. DMI, along with the appropriately networked software, is
designed to make inventory, maintenance and troubleshooting of
computer systems easier. Refer to Chapter 4 for instructions on
using the DMI utility.
ATX double deck ports
2 USB ports
2 DB-9 serial ports
1 DB-25 parallel port
1 mini-DIN-6 PS/2 keyboard port
1 mini-DIN-6 PS/2 mouse port
Connectors
1 connector for IrDA interface
2 IDE connectors
1 floppy connector
1 20-pin ATX power supply connector
1 Wake-On-LAN connector
1 SB-LINK connector
2 fan connectors for CPU and chassis fans
Note:
If you are using more than one DIMM, make sure you insert
the same type of DIMMs into the DIMM sockets. Using
different types (VCM and PC SDRAM) of DIMMs may cause
problems.
Introduction
1
8
PCI Bus Master IDE Controller
Two PCI IDE interfaces support up to four IDE devices
Supports ATA/33 or ATA/66 hard drives
PIO Mode 3 and Mode 4 Enhanced IDE (data transfer rate up
to 16.6MB/sec.)
Bus mastering reduces CPU utilization during disk transfer
ATAPI CD-ROM, LS-120 and ZIP supported
IrDA Interface
The system board is equipped with an IrDA connector for wireless
connectivity between your computer and peripheral devices. It
supports peripheral devices that meet the IrDA or ASKIR standard.
USB Ports
The system board is equipped with two USB ports. USB allows
data exchange between your computer and a wide range of
simultaneously accessible external Plug and Play peripherals.
BIOS
Award BIOS, Windows95/98 Plug and Play compatible
Supports SCSI sequential boot-up
Flash EPROM for easy BIOS upgrades
Includes Symbios Logic SCSI BIOS
2MBit flash memory
1.1.2 System Health Monitor Functions
The system board is capable of monitoring the following system
health conditions.
Monitors processor/system temperature and processor overheat
alarm
Monitors 1.5V/3.3V/±5V/±12V/VCORE voltages and failure
alarm
Monitors processor/chassis fan speed and failure alarm
Automatic processor/chassis fan control
Read back capability that displays temperature, voltage and fan
speed
1
Introduction
9
1.1.3 Intelligence
Automatic CPU/Chassis Fan Off
The CPU and chassis fans will automatically turn off once the
system enters the Suspend mode.
Dual Function Power Button
Depending on the setting in the BIOS setup, this switch will allow
the system to enter the Soft-Off or Suspend mode.
External Modem Ring-on
The Modem Ring-on feature allows the system that is in the
Suspend mode or Soft Power Off mode to wake-up/power-on to
respond to incoming calls.
Note:
This feature supports external modem only.
RTC Timer to Power-on the System
The RTC installed on the system board allows your system to
automatically power-on on the set date and time.
Wake-On-LAN Ready
The Wake-On-LAN function allows the network to remotely wake
up a Soft Power Down (Soft-Off) PC.Your LAN card must support
the remote wakeup function.
Important:
The 5VSB power source of your power supply must support
≥
720mA (minimum).
Wake-On-Keyboard/Wake-On-Mouse
This function allows you to use the keyboard or PS/2 mouse to
power-on the system. Refer to Jumper Settings for Wake-On-
Keyboard/Wake-On-Mouse in chapter 2 and Keyboard/Mouse
Power On in the Integrated Peripherals setup of the Award BIOS
in chapter 3 for more information.
Introduction
1
10
Important:
The power button will not function once a keyboard
password has been set in the KB Power On Password
field of the Integrated Peripherals setup. You must type
the correct password to power-on the system.
The 5VSB power source of your power supply must
support
≥
720mA (minimum).
ACPI
The system board is designed to meet the ACPI (Advanced
Configuration and Power Interface) specification. ACPI has energy
saving features that enable PCs to implement Power Management
and Plug-and-Play with operating systems that support OS Direct
Power Management.
Virus Protection
Most viruses today destroy data stored in hard drives. The system
board is designed to protect the boot sector and partition table of
your hard disk drive.
1.2 Package Checklist
The system board package contains the following items:
þThe system board
þA users manual
þOne IDE cable for ATA/33 or ATA/66 hard disk drives
þOne 34-pin floppy disk drive cable
þOne CD
If any of these items are missing or damaged, please contact your
dealer or sales representative for assistance.
Altri manuali per CA61
1
Questo manuale è adatto per i seguenti modelli
1
Indice
Altri manuali DFI Scheda madre
DFI
DFI PE10-SA/RAMA Manuale utente
DFI
DFI EL620-C Manuale utente
DFI
DFI GIC88-B Manuale utente
DFI
DFI CD70-SC Manuale utente
DFI
DFI CMS631-Q470E/H420E Manuale utente
DFI
DFI P2XBL DE+ Manuale utente
DFI
DFI AZ30-EC Manuale utente
DFI
DFI G7L330-B Manuale utente
DFI
DFI 915GM-MGF Manuale utente
DFI
DFI HD620 Series Manuale utente
DFI
DFI LanParty UT X38 Series Manuale utente
DFI
DFI G486VPA Manuale utente
DFI
DFI CS631-C246 Manuale utente
DFI
DFI 586STE Manuale utente
DFI
DFI CL630-CRM Manuale utente
DFI
DFI CS331-C246 Manuale utente
DFI
DFI G586VPM Manuale utente
DFI
DFI AM75-TC Manuale utente
DFI
DFI Infinity NF series Manuale utente
DFI
DFI CM64-AL Manuale utente
Manuali Scheda madre popolari di altre marche
Gigabyte
Gigabyte GA-9IVDT Manuale utente
Texas Instruments
Texas Instruments ADS8372EVM Manuale utente
Commell
Commell MS-C73 Manuale utente
IBT Technologies
IBT Technologies MB860 Manuale utente
Nvidia
Nvidia TEGRA DG-04927-001_V01 Manuale utente
Biostar
Biostar M7VIT Bravo Istruzioni per l'uso e l'installazione
