G586OPA

Rev. 0 +

System Board

User’s Manual

-D26250525-

No part of this document may be copied, reproduced in

any form or by any means or used to make any trans-

formation/adaptation without the prior written consent

of DFI, Inc.

DFI, Inc. makes no warranties with respect to this

documentation and disclaims any implied warranties of

merchantability, quality, or fitness for any particular

purpose. The information in this document is subject to

change without notice. DFI, Inc. reserves the right to

make revisions to this publication and to make changes

to any and/or all parts of its content, at any time,

without obligation to notify any person or entity of such

changes. Further, DFI, Inc. assumes no responsibility

for any errors that may appear in this document.

DFI is a registered trademark, and G586OPA is a

trademark of Diamond Flower, Inc. All other product

names mentioned are trademarks or registered trade-

marks of their respective companies.

vFCC Statement on Class B

This equipment has been tested and found to comply

with the limits for a Class B digital device, pursuant to

Part 15 of the FCC rules. These limits are designed to

provide reasonable protection against harmful interfer-

ence when the equipment is operated in a residential

installation. This equipment generates, uses and can

radiate radio frequency energy and, if not installed and

used in accordance with the instruction manual, may

cause harmful interference to radio communications.

However, there is no guarantee that interference will

not occur in a particular installation. If this equipment

does cause harmful interference to radio or television

reception, which can be determined by turning the

equipment off and on, the user is encouraged to try to

correct the interference by one or more of the following

measures:

•Reorient or relocate the receiving antenna.

•Increase the separation between the equipment and

the receiver.

•Connect the equipment into an outlet on a circuit

different from that to which the receiver is

connected.

•Consult the dealer or an experienced radio TV

technician for help.

Notice:

1. The changes or modifications not expressly

approved by the party responsible for compliance

could void the user's authority to operate the

equipment.

2. Shielded interface cables must be used in order to

comply with the emission limits.

v Table of Contentsv

Introduction ..............................................................................

Features and Specifications .........................................

Package Checklist ........................................................

Installation Overview ...............................................................

Preparing the Area ..............................................................

Handling the System Board ................................................

Tips in Handling the System Board ..............................

Hardware Installation...........................................................

Memory Installation .......................................................

Installing the Modules ............................................

Board Configuration ......................................................

Jumper Settings for Flash EPROM, PS/2 Mouse

and Display Type....................................................

Jumper Settings for Parallel Port ...........................

Cache Configuration .....................................................

Jumper Settings for Cache Memory ......................

CPU Installation ............................................................

Jumper Settings for CPU .......................................

Installing Upgrade CPUs .......................................

Built-in Ports ........................................................................

Serial Ports ...................................................................

Parallel Port ..................................................................

Floppy Disk Drive Connector ........................................

IDE Hard Disk Connector .............................................

PS/2 Mouse Port ...........................................................

Installing Expansion Cards ..................................................

Installing the System Board ................................................

1-1

1-2

1-5

2-1

2-2

2-3

2-6

2-7

2-8

2-11

2-13

2-14

2-17

2-18

2-21

2-26

2-27

2-28

2-30

2-31

2-34

2-35

2-36

3-1

3-2

3-5

3-7

3-8

3-9

3-16

3-17

3-18

3-19

3-20

4-1

5-1

A-1

B-1

C-1

D-1

E-1

F-1

G-1

Initial Setup Program ..............................................................

Award BIOS CMOS Setup Utilities .....................................

Standard CMOS Setup .................................................

BIOS Features Setup ....................................................

Chipset Features Setup ................................................

Power Management Setup ...........................................

PCI Configuration Setup ...............................................

Load BIOS Defaults ......................................................

Load Setup Defaults .....................................................

Password Setting ..........................................................

IDE HDD Auto Detection ..............................................

Save & Exit Setup .........................................................

Exit Without Saving .......................................................

IDE Device Drivers ..................................................................

Troubleshooting Checklist .....................................................

Appendix A:Types of Modules ..............................................

Appendix B:System Error Report .........................................

Appendix C:Memory & I/O Maps ..........................................

Appendix D:PCI I/O Pin Assignments ..................................

Appendix E:ISA I/O Pin Assignments ..................................

Appendix F:Connector Pin Assignments ............................

Appendix G:Award BIOS Hard Disk Table ...........................

PCI/ISASystemBoard

1-1 uIntroduction

vIntroduction

The G586OPA system board offers several advanced

features integrated into the system board. Its design is

based on the new Peripheral Component Interconnect

(PCI) local bus and Industry Standard Architecture

(ISA) standards.

The G586OPA supports a 320-pin Zero Insertion Force

(ZIF) CPU socket for PentiumTM processors running at

75MHz, 90MHz, 100MHz, 120MHz or 133MHz fre-

quency. This ZIF socket allows users to easily upgrade

their CPUs. It also supports a Flash EPROM for easy

BIOS upgrades. Flash EPROM is a memory chip for the

storage of BIOS which can be erased in bulk or modi-

fied using a software utility.

The G586OPA is equipped with three PCI slots, three

ISA slots and one shared PCI/ISA slot.

Equipped with two built-in PCI IDE connectors, the

G586OPA system board can control four drives and

supports fast Mode 3 hard drives and hard drives larger

than 528MB under DOS. The system board is also

equipped with two NS16550-compatible serial ports, an

ECP/EPP parallel port, a floppy disk drive controller,

and one mini-DIN-6 connector for the PS/2 mouse.

The G586OPA can support 2MB to 128MB of memory

using 256Kx36, 512Kx36, 1Mx36, 2Mx36, 4Mx36 and

8Mx36 72-pin SIM modules.

G586OPA

Features and Specifications

Introduction u1-2

Processor

•Intel PentiumTM 75/90/100/120/133MHz

Chipset

•OPTI: Viper chipset

82C556 -data buffer

82C557 -system controller

82C558 -Integrated Peripheral Controller

Energy Efficient Design

•Supports 3.3V CPUs

•Supports system power management

•Supports CPU stopped clock

Power Management

•Three power-saving stages: Doze, Standby and

Suspend

•Microsoft APM 1.1 supported

•EPA Energy Star compliant design

PCI IDE Interface

•Fast PCI local-bus interface

•Supports Mode 3 (enhanced IDE) hard drives

•Two IDE connectors to control four drives (e.g. two

HDDs, one tape drive and one CD-ROM)

•Uses NS PC87410 PCI IDE chip

Super I/O Interface

•Two NS16C550A-compatible serial ports

•PS/2 mouse port

•One parallel port with EPP and ECP support

•Supports 360KB, 720KB, 1.2MB, 1.44MB and

2.88MB floppy drives

•Uses NS PC87332VF super-I/O controller

PCI/ISASystemBoard

1-3 uIntroduction

BIOS

•Award Plug & Play BIOS

•Flash EPROM for easy BIOS upgrades

•Supports IDE HDDs larger than 528MB under DOS

(LBA mode only)

Architecture

•PCI/ISA

Cache Memory

•256K, 512K or 1MB direct map write-back or

write-through cache

•Uses 32Kx8, 64Kx8 or 128Kx8 SRAM

•Supports 3.3V or 3V/5V mixed mode SRAM

Memory Onboard

•Up to 128MB

•Four 72-pin SIMM sockets

•Supports single and/or double density SIMMs

•256Kx36, 512Kx36, 1Mx36, 2Mx36, 4Mx36 or

8Mx36 SIMMs

•Supports 60ns or 70ns fast page mode DRAM

Expansion Slots

•Three dedicated PCI slots

•One shared PCI/ISA slot

•Three dedicated 16-bit ISA slots

Due to the height of the heat sink, once the 3.3V

Pentium Upgrade Processor is in place, you cannot

install full-length add-in cards in slot connectors 1, 2

& 4 (ISA), and 1 & 2 (PCI). These slots are limited

to 2/3 length of add-in cards.

G586OPA

ZIF Socket

•320-pin ZIF socket (Intel Socket 5)

Board Dimensions

•33cm (12.87") x 22cm (8.58")

Baby AT form factor

Introduction u1-4

PCI/ISASystemBoard

1-5 uIntroduction

Package Checklist

The G586OPA package contains the following items:

•The G586OPA system board

•The G586OPA user’s manual

•Two IDE driver diskettes

•One 34-pin floppy disk drive cable

•Two 40-pin IDE hard disk cables

•One 25-pin printer port cable for chassis mounting

•One card-edge bracket with serial and mouse port

cables

If any of these items are missing or damaged, please

contact your dealer or sales representative for assistance.
