HearPlus 317c

English

Operation

Making a call

Regular dialling

1. Pick up the handset.

2. Enter the desired number.

Dialling using correction function

If necessary, the telephone number entered can be altered

before it is connected.

1. Enter the required number. You can delete with .

2. Pick up the handset, the number is dialled.

To make a call using the headset, see separate description.

Redial function

Press one or more times to scroll between the 5 most

recently dialled numbers, which will be shown on the LCD

display. Pick up the handset to dial or press to cancel.

Memory

This telephone has 4 speed dial memories.

Once a number has been saved in a memory location, you

only need to press one button to make the call. Speed dial

numbers are marked A, B, C, and D.

Dialling/control using Speed Dial

1. Select required speed dial (A-D) by pressing on the

appropriate button.

2. The saved number is shown in the display.

3. Pick up the handset to dial or press to cancel.

English

Volume control

Thisproductcanadjustthesoundinanumberofways:

Normal volume control for the handset.

 Pressthebuttontoactivatepowerfulamplication.

Theamplicationisnormallydeactivatedatthe

end of each call to avoid harming people with

normal hearing. This safety function is adjustable,

see Technical Information.

Change frequency range/tone level and quality (on

the left side). PLEASE NOTE! Only works when

thepowerfulamplicationisactive.

Headset volume control.

Warning!

The handset volume can be turned up very loud. The

powerful amplication should only be used by people with

impaired hearing ability.

Caller ID

Caller ID allows you to see who is calling before you

answer a call or to see who has called in your absence. If

the number has been saved in the memory, the name is

shown instead.

Calls received are stored chronologically, with the

sequence number shown next to the telephone number.

When the memory is full, the oldest number will be deleted

automatically as the new call is logged. New numbers are

indicated by .

Please note!

You must subscribe to this service from your network

operator in order for this feature to function.

English

Retrieving and dialling incoming numbers

1. Press to scroll between the numbers of calls that have

been received.

2. Pick up the handset to dial or press to cancel.

Messages

Apartfromphonenumbers,thedisplaycanshow:

!!!!! No information received, e.g. an international call.

????? The call comes from a withheld number or a PBX.

Number not previously seen.

aMessage indication (sent from your network

operator)*.

*Message indication can be deleted manually by pressing

down for a few seconds in standby mode.

Deleting telephone numbers

1. Scroll to the required entry with .

2. Press down until the number disappears.

English

Connecting a headset

You can connect a headset to the socket on the

telephone’s left side. When a headset is connected the

headset buttons / are used to connect /disconnect

a telephone call (equivalent to lifting and putting down the

handset).

The volume in the headset can be adjusted, see previous

page.

Please note!

A neck loop/extra handset can be connected to this socket

instead of a headset.

DORO original headsets are tested and adapted for

this model. Other types and makes of headsets may be

used, though the function and sound quality cannot be

guaranteed. In the worst case, these could damage the

headset and telephone. This type of damage is not covered

by the telephone’s guarantee.

Hearing loop

The handset has a built-in hearing loop for those who wish

to use their hearing aids while using the telephone. Select

the T mode on your hearing aid to enable this feature.

English

Settings

Connection

1. Connect the telephone cord to a network wall socket and

to the T socket on the back of the telephone.

2. Connect the mains adapter to the mains power socket

and to the Ysocket on the back of the telephone.

3. Connect the curly cord to the handset and to the q

socket on the base of the telephone. (You will hear a click

when the modular plug is correctly in place).

4. Set the correct Flash time to 100 (see technical information

on page 7).

5. Lift the handset and listen for the dial tone.

Date/Time

1. Press down until H is shown.

2. Enter date (DD/MM).

3. Entertimeofday(HH:MM).

Press to cancel and return to standby mode.

Batteries

Four 1.5V type AAA batteries are needed so that caller ID,

memory etc will continue to function in the event of a power

cut. When the batteries have almost expired the 7

symbol will light up. Only use high quality batteries.

1. Check that the adapter is correctly inserted to avoid

losing saved information.

2. Unplug the telephone cable and remove the cover on the

base of the telephone.

3. Insert the batteries according to the markings for plus

and minus terminals.

4. Replace the battery cover and reconnect the telephone

cord.

English

Ring signal

Ring volume, melody and tone can be adjusted to ensure

you can hear the ring clearly. These are found underneath

thetelephone:

Ring volume

nRing melody

Ring tone

LCD Display

On the base of the telephone there is a switch /

to change the style of the LCD display. Choose the style

you are able to see more clearly.

Memory

Saving Speed Dial Numbers

1. Press down *until b123... is shown.

2. Enter the telephone number, including the area code.

3. Press down *until bABC... is shown.

4. Pressequivalentnumericaldigitkeyoneormoretimesfor

desiredname(thecharactersareprintedbelowthenumerical

keys).Space=1.

5. Press down *until bA-D is shown.

6. Select speed dial (A-D) by pressing on the appropriate

button.

7. ºis shown. The number is now saved.

If a pause is required in the telephone number, press .

The display shows P.

If a number needs changing, simply save the new number in

place of the old one.

You can go back/delete using .

Flashing light

Toalertyoutoincomingcalls,apowerfulashinglightcan

be activated when the telephone is ringing. The settings

can be found under the telephone.

Flashing light ON.

Flashing light OFF.

English

Socket for additional alert equipment

Extra equipment e.g. a vibrator for the ring signal can be

connected to the ((o)) socket on the back of the telephone.

Technical Information

Behind the battery cover on the underside of the telephone

youwillndseveralswitches.

These switches set technical parameters as detailed below.

Remove the small cover on the base of the telephone.

Key beep ( )

The sound that is heard when the buttons are pressed can

be switched off/on.

Microphone adaptation ( )

The microphone level may need to be adjusted for certain

people.

0is the standard setting for most countries.

+6 gives a somewhat higher sound and -6 gives a

somewhat lower sound.

Flash button time (100/300)

100 is the standard setting for most countries.

300 for France/Portugal.

600 for New Zealand.

Tone(♫) / Pulse(...)

Select dialling method.

The dial mode setting for UK must be Tone (Europe only).

Lockingthepowerfulamplication( )

Thepowerfulamplicationissettoswitchoffafterevery

call,thiscanbechangedsotheveryhighamplication

stays permanent switched on using the setting. This

setting should only be activated if all users have impaired

hearingandrequirepowerfulamplication.Thestandard

setting is .

English

Troubleshooting

Check that the telephone cord is undamaged and properly

plugged in. Disconnect any additional equipment, extension

cords and other phones. If the problem is resolved, the fault

is with some other equipment.

Test the equipment on a known working line (e.g. at a

neighbour’s house). If the equipment works there the fault is

probably with your telephone line. Please inform your network

operator.

Ifyouarestillexperiencingdifculties,contacttheplaceof

purchase.

Declaration of conformity

Doro hereby declares that the product Doro HearPlus 317c

conforms to the essential requirements and other relevant

regulations contained in the Directive 1999/5/EC (R&TTE),

2002/95/EC (ROHS).

A copy of the manufacturer’s declaration is available at

www.doro.com/dofc

English

Guarantee

This product is guaranteed for a period of 12 months

from the date of purchase. Proof of purchase is required

for any service or support required during the guarantee

period. This guarantee shall not apply to a fault caused

by an accident or a similar incident or damage, liquid

ingress, negligence, abnormal usage, not reasonably

maintained or any other circumstances on the purchaser’s

part. Furthermore, this guarantee shall not apply to a

fault caused by a thunderstorm or any other voltage

uctuations.Thisguaranteedoesnotinanywayaffectyour

statutory rights. (As a matter of precaution, we recommend

disconnecting the telephone during a thunderstorm.)

Ifyoucannotresolvethefaultusingthefaultndersection,

technicalsupportisavailablebyemailontech@doro-

uk.com -premium rate telephone number: 0905 895

0854, calls cost 50 pence per minute (prices correct at

the time of publication).

You can also contact us in writing (regarding any Spares or

Technicalquery):

Customer Services

Doro UK Ltd

1 High Street

Chalfont St Peter

Buckinghamshire

SL9 9QE.

Furthercontactdetailsareavailableonourwebsite:

www.doro-uk.com.
