Nitro Rollator

www.ActiveForever.com | 1-800-377-8033

Parts List

1. Handgrip

2. Adjustable tubing handgrip

3. Rear reflector on handgrip

4. Brake lever

5. Interlock button for handgrips

6. Back Rest

7. Seat

8. Bag

9. Front wheel

10. Brake adjust screw

11. Rear wheel

12. Safety bow

1

3

5

12

6

7

8

9

10

2

4

11

The Walking aid is suitable for a single user with limited mobility. The nitro is ideal for

indoor and outdoor use.

1. Bag

2. Back Rest

3. Operating Instructions

Introduction

7. Seat

8. Bag

9. Front wheel

10. Brake adjust screw

11. Rear wheel

12. Safety bow

Nitro Includes:

Unfolding the Nitro

Position the Nitro on its

wheels. Open the red

safety bow and lift up

(figure 1). Press both pipes

from the seat downwards

until they interlock (figure

2).

Height Adjustment

Press the red release buttons for handgrips below,

as shown in figure 3, and pull the handgrip upwards

at the same time. As the handle moves, release the

button. This automatically locks in the next possible

height. Repeat this process until the desired height

is reached.

12

3

Attaching the Carry Bag

Fold the Nitro and push the sliding block from bag into guiding sleeve on the Nitro.

Unfold the Nitro. (see figures 4-6).

Braking/Locking

Pull both brake levers upwards to apply the brakes

while the Nitro is moving (see figure 7). Always

brake slowly and steady.

Press both brake levers down to apply the locks

while the Nitro is stationary (see figure 8). Pull up

the brake levers and release to release the locks.

The effect of the brakes can be affected by

abrasion of the wheels.

Regularly test the brakes.

456

7

8

Adjustment of Brakes

To adjust the braking

strength, adjust the

brake by pressing

the screw housing

downwards (figure 9)

and then turn left or

right (figure 10).

Sitting

Position the Nitro on an even and solid surface. Lock

the brakes (parking position). The Nitro must stand

and must not slip. Sit straight up and do not lean

backwards. (See figure 11).

Folding/Transport/Storage

To fold, pull seat

upwards by the handle

on the seat plate as

shown in figure 12. The

Nitro can now be folded

complete and secured

by using the red safety

clasp as shown in figures

14 and 15.

9 10

11

12 13

14

Safety Instructions

• Use only as a walking aid!

• Use only on even and solid surfaces.

• Maximum user weight: 300 lbs.

• Regularly check the screws and fasteners on the Nitro and retighten if necessary.

• Use bag only for transport of objects and do not overload. Maximum load: 11 lbs.

• Do not expose the product to temperatures above 104°F for an extended period

of time, as this can cause the Nitro parts to overheat and burn the user.

• Please make sure the Rollator is fully opened, seat is down and the folding bar

under seat is locked in the down position.

• Be sure that both knobs are fully tightened and are at equal heights. Test

Rollator for stability before applying full weight to hand grips.

• Test the brake lever before operating the Rollator. When wheels are locked, lock

bar on rear wheels should prevent wheels from turning. When locks are released,

the wheels should turn freely.

• Always lock the brake lever before sitting and do not use seat when unit is on an

incline or uneven ground.

• Replace tires when significantly worn or damaged.

• Do not have anyone push you while you are seated on the Rollator. This is a

walking aid only and is not to be used as a transportation device.

Cleaning / Maintenance

Clean regularly by hand with a damp cloth. Do not use aggressive detergents.

Your Drive Medical product is warranted to be free of defects in materials

and workmanship for the lifetime of the original consumer purchaser.

This device was built to exacting standards and carefully inspected prior to

shipment. This Lifetime Limited Warranty is an expression of our confidence

in the materials and workmanship of our products and our assurance to the

consumer of years of dependable service.

This warranty does not cover device failure due to owner misuse or

negligence, or normal wear and tear. The warranty does not extend to

non-durable components, such as rubber accessories, casters, and grips,

which are subject to normal wear and need periodic replacement.

If you have a question about your Drive device or this warranty, please

contact an authorized Drive dealer.

lifetime limited

warranty
