DSP6011
6.5" 6W Ceiling Speaker
The DSP6011 is a surface mount ceiling speaker with a 70V/100V transformer built in. The 70V/100V
transmission is realized in a high-voltage, low-current mode, which makes longer distance transmission and
parallel connection of multiple loudspeakers possible.
It’s easy to install with strong clip, and made of high-quality engineering plastic, which is durable,
non-deformable and non-fading. It is an ideal choice for these places, such as schools, gymnasiums, square
halls, parks, parking lots, railway stations, airports, villa communities and mall supermarkets, etc.
6.5 inch Frameless
Aluminum Grille
70/100V, Rated Power:6W
Max. SPL:97±2dB
Freq. Resp.:110Hz - 15kHz
Sensitivity 90±2dB
Cutout size:Ø165-170mm
Three speaker line terminal, support different power
In-ceiling quick installation by spring clip
Model
DSP6011
RMS Power
6W
Power Input
70V/100V
Driver Unit
6.5 inch
Max.SPL
97±2dB
Sensitivity
90±2dB
Freq. Response
110Hz - 15kHz
Installation
Spring Clip
Dimension
Ø165-170mm
Net Weight
0.6kg
Description
Features
Specifications
[email protected] /www.dsppatech.com The specifications will be subject to change without prior notice.
Copyright © Guangzhou DSPPA Audio Co.,Ltd All rights served.
Freq. Response Distortion
(dB SPL、1W、1m) (THD< 1.5% 1W、1m、200Hz-10kHz)
Dimensions
Installation
1. Cut a Ø165mm - Ø170mm installation hole on ceiling as shown above.
2. Connect audio broadcasting wire to the terminals according to the table below.
Notice:“━” While broadcasting wire is quite long and with high impedance only.
3. Turn up the clamps of the speaker and insert them into the installation hole on ceiling and then release
them as shown below. Put on your gloves for safe is recommended .
4. Finally, examine whether it is steady.
Black---Blue
3W
6W
Black---White
6W
━
70V
100V
Line Voltage
Terminal
Power
